Product type	Immersion blender
Brand	SilverCrest
Model	SSM 300 A1
Power	600 W
Power supply	220-240 V ~ 50/60 Hz
Speed	Variable with turbo
Dimensions (L x W x H)	40 x 10 x 10 cm
Weight	0.8 kg
Shaft material	Stainless steel
Included accessories	Measuring cup, whisk, hook (depending on version)
Main functions	Mix, emulsify, chop, whisk
Maintenance and cleaning	Shaft and accessories dishwasher-safe, motor unit cleaned with a damp cloth
Safety	Automatic shut-off in case of overheating, shaft lock
Spare parts and repairability	Available from the manufacturer (TARGA GmbH)
Warranty	3 years
General information	Distributed by TARGA GmbH, suitable for domestic use

Frequently Asked Questions - SSM 300 A1 SILVERCREST

How to use the SSM 300 A1 immersion blender?

Place the shaft in the food, select the desired speed with the slider, and press the start button. Use the turbo button for maximum power.

What accessories are included with the SSM 300 A1?

The kit usually includes a measuring cup, a whisk, and sometimes a dough hook. Check your packaging.

Can I blend hot liquids?

Yes, but be careful of splashes. Do not immerse the shaft in boiling liquid and use the measuring cup up to 80 °C maximum.

How to clean the immersion blender?

Unplug the appliance. The shaft and accessories are dishwasher-safe. Wipe the motor unit with a damp cloth. Never immerse the motor in water.

What to do if the appliance does not turn on?

Check the outlet and cable. If the appliance has overheated, allow it to cool down. If the problem persists, contact customer service.

Is the blender suitable for crushing ice cubes?

It is not designed for ice cubes. Use a blender with a suitable jar instead.

How to change speed during use?

Turn the speed slider on the motor unit during operation. The turbo speed is activated by holding the corresponding button.

What is the power of the SSM 300 A1?

The nominal power is 600 W, sufficient for blending soups, sauces, and smoothies.

Can I use a bowl other than the one supplied?

Yes, you can use any suitable container (sufficient height to avoid splashes), but the measuring cup is recommended.

Where to find spare parts?

Contact the manufacturer TARGA GmbH via their website or SilverCrest customer service to order spare parts.

USER MANUAL SSM 300 A1 SILVERCREST

HAND BLENDER SSM 300 A1

GB IE

HAND BLENDER

Operating instructions

SE

STAVMIXER

Bruksanvisning

FR BE

MIXEUR PLONGEANT

Mode d'emploi

DE AT CH

STABMIXER

Bedienungsanleitung

FI

SAUVASEKOITIN

Käyttöohje

DK

STAVBLENDER

1. Overview 2
2. Intended purpose 3
3. Safety information .... 3
4. Items supplied 5
5. Installation 5
6. Operation 6
7. Cleaning 6
8. Storage 7
9. Trouble-shooting 7
10. Disposal 8
11. Technical specifications 8
12. Warranty of the HOYER Handel GmbH 8

1. Overview

1 Power cable with mains plug
2 Power button (normal speed)
3 Turbo Power button (turbo speed)
4 Motor unit
5 Blender

Rear of the device

6 ▼▲ Attachment markings
7 Lock markings

2

GB

Pure geometric diagram with intersecting lines and circles, no text or symbols present

Thank you for your trust!

We congratulate you on your new hand blender.

For a safe handling of the product and in order to get to know the entire scope of features:

• Thoroughly read these operating instructions prior to initial commissioning.
- Above all, observe the safety instructions!
- The device should only be used as described in these instructions.
- Keep these instructions for reference.
- If you pass the device on to someone else, please include these operating instructions.

We hope you enjoy using your new hand blender!

2. Intended purpose

This hand blender is intended for chopping and blending various foodstuffs.

The device is designed for use in private households. The device must only be used indoors.

This device must not be used for commercial purposes.

This device is equally intended for use in the home and in applications similar to the home, such as for example...

... in kitchens for employees in shops, offices and other commercial areas;
... on agricultural estates;
... by customers in hotels, motels and other residential facilities;
... in bed-and-breakfast establishments.

Foreseeable misuse

WARNING! Risk of material damage!

Do not use the device for chopping particularly hard food, e.g. frozen food, bones, nutmeg, grain, coffee beans or spices. This device is also not intended for processing chocolate.

3. Safety information

Warnings

If necessary, the following warnings will be used in these operating instructions:

DANGER! High risk: failure to observe this warning may result in injury to life and limb.

WARNING! Moderate risk: failure to observe this warning may result in injury or serious material damage.

CAUTION: low risk: failure to observe this warning may result in minor injury or material damage.

NOTE: circumstances and specifics that must be observed when handling the device.

Instructions for safe operation

• This device must not be used by children.
• Children should not be allowed to play with the device.
- The device and the power cable must be kept away from children.
- This device can be used by people with restricted physical, sensory or intellectual abilities or people without adequate experience and/or understanding if they are supervised or instructed on how to use this device safely and if they are aware of the resulting risks.
- Disconnect the mains plug from the wall socket...
... when it is not supervised, ... before you assemble or disassemble the device, and ... before you clean the device.

- Clean the blender 5 manually in washing-up water, rinse with clear water and allow it to dry completely before putting it away.

DANGER for children

• Packing materials are not children's toys. Children should not be allowed to play with the plastic bags. There is a risk of suffocation.
• Keep the device out of the reach of children.

DANGER! Risk of electric shock due to moisture

• This device must never be operated close to a bathtub, shower, filled hand basin or similar.
• The motor unit, the power cable and the mains plug must not be immersed in water or other liquids.
• Protect the motor unit from dampness and dripping and splashing water.
• Should liquids enter the motor unit, pull out the mains plug immediately. Have the device checked before reusing.
• Never touch the device with wet hands.
• If the device falls into water, disconnect the mains plug immediately. Only then is it safe to retrieve the device.

DANGER! Risk of electric shock

• Only plug the mains plug into a wall socket if the motor unit has been connected to the hand blender.
• Only connect the mains plug to a properly installed and easily accessible wall socket whose voltage corresponds to the specifications on the rating plate. The wall socket must continue to be easily accessible after the device is plugged in.
• Ensure that the power cable cannot be damaged by sharp edges or hot points. Do not wrap the power cable around the device.
• The device is not fully disconnected from the power supply, even after it is switched off. In order to fully disconnect it, pull out the mains plug.
• When using the device, ensure that the power cable cannot be trapped or crushed.
  • To pull the mains plug out of the wall socket, always pull on the mains plug, and never on the power cable.

Pure geometric diagram with intersecting lines and a central circle, no text or symbols present

- Disconnect the mains plug from the wall socket... ... if there is a fault, ... if you are not using the hand blender and ... during thunderstorms.

- Do not use the device if there is visible damage to the device or the power cable. - To avoid any risk, do not make modifications to the device. - If the power cord of this device is damaged, it must be replaced by the manufacturer or the manufacturer's customer service, or by a similarly qualified person, in order to avoid danger.

DANGER! Risk of injury from cutting

- The blades of the blender are sharp. Handle it with care. When washing manually, the water should be sufficiently clear that you can see the blades easily. - Never reach into the rotating blades. Do not touch rotating parts with spoons or similar utensils. Keep long hair or loose clothing away from rotating parts as well. - The blade continues to rotate after the device is switched off. Wait until the blade has come to a standstill before you pull the hand blender out of the food.

WARNING! Risk of material damage

- The device is designed for a maximum operating time of 1 minute without interruption. After this, the device must remain switched off until it has cooled down to room temperature. - In order to prevent damage to the device, interrupt the blending process immediately if the blade is either turning with difficulty or not turning at all. Pull out the mains plug and check whether there is something in the vessel blocking

movement or whether the food is too tough. Also check whether the device is assembled correctly.

- Only use the original accessories. - Do not use any astringent or abrasive cleaning agents.

4. Items supplied

1 Motor unit 4 1 Blender 5 1 Set of operating instructions

5. Installation

- Remove all packing material. - Check to ensure that all parts are present and undamaged. - Clean the device prior to its first use! (see "Cleaning" on page 6.)

DANGER! Risk of electric shock! Only plug the mains plug 1 into the wall socket if the motor unit 4 has been connected to the blender 5.

Connecting the blender (Figure A)

1. Place the motor unit 4 on the blender 5 in such a way, that the attachment markings ▼▲6 point to each other.
2. Turn the blender 5 in such a way, that the attachment marking ▼ on the motor unit points to the lock marking 🔒7. The motor unit 4 must engage noticeably and audibly.

Removing the blender (Figure B)

- To remove, turn the blender 5 in the opposite direction, so that the attachment marking points ▼6 to the lock marking □7 and pull the motor unit 4 off from the blender 5.

6. Operation

Application area

The hand blender is suitable for pureeing fruits and vegetables, soups, dips and sauces, as well as blending drinks and making milkshakes.

NOTE: adapt the rotation speed to suit the foodstuff to be blended. Select normal speed (2) for soft foodstuffs and turbo speed (Turbo 3) for harder foodstuffs.

This is how it is done

DANGER! Risk of injury from cutting!

- Never reach into the rotating blades. Do not touch rotating parts with spoons or similar utensils. Keep long hair or loose clothing away from rotating parts as well.

- Only switch on the device when the blender 5 is immersed in the foodstuff.

- The blade continues to rotate after the device is switched off. Wait until the blade has come to a standstill before you pull the hand blender out of the food.

WARNING!

- The device is designed for a maximum operating time of 1 minute without interruption. After this, the device must remain switched off until it has cooled down to room temperature.

- In order to prevent damage to the device, interrupt the blending process immediately if the blade is either turning with difficulty or not turning at all. Pull out the mains plug 1 and check whether there is something in the vessel blocking movement or whether the food is too tough. Also check whether the device is assembled correctly.

1. Fill the foodstuff to be blended or pureed into a narrow, high vessel with a flat bottom. You may also blend foodstuffs directly in the cooking pot.
2. Immerse the blender 5 into the food-stuff.
3. To blend at normal speed, hold the power button ② down. To blend at turbo speed, hold the power button Turbo 3 down.
4. Move the blender 5 up and down a bit in the foodstuff, to ensure that it is blended evenly.
5. When you are finished, let go of the power button ⏻ 2 or Turbo 3.

NOTE: if the blender 5 builds up a suction and adheres to the bottom of the vessel, let go of the power button ⏻2 or Turbo 3 briefly.

7. Cleaning

Clean the device prior to its first use!

DANGER! Risk of electric shock!

• Pull the mains plug 1 out of the wall socket before you clean the hand blender.
• The motor unit 4, the power cable and the mains plug 1 must not be immersed in water or other liquids.

DANGER! Risk of injury from cutting!

When washing manually, the water should be sufficiently clear that you can see the blade easily.

WARNING! Risk of material damage! Do not use any astringent or abrasive cleaning agents.

1. Pull out the mains plug 1.
2. Remove the blender 5 from the motor unit 4. (Figure B)

6

GB

1. Wipe the motor unit 4 and the power cable 1 with a slightly moistened cloth, if necessary.
2. The blender 5 may be washed by hand.
3. Allow the parts to dry completely before putting them away.

Some cleaning tips

• Preferably clean the blender 5 immediately after use, to prevent food residues from drying on and sticking to the hand blender.
  • After processing very salty foodstuffs, the blender 5 should be rinsed immediately.

8. Storage

DANGER for children! Keep the device out of the reach of children.

DANGER! In order to avoid accidents, the mains plug 1 must never be connected to a wall socket while in storage.

- Select a location where neither high temperatures nor moisture can affect the device.

9. Trouble-shooting

If your device fails to function as required, please try this checklist first. Perhaps there is only a minor problem, and you can solve it yourself.

DANGER! Risk of electric shock! Do not attempt to repair the device yourself under any circumstances.

Fault	Possible causes/Action
No function	Has the device been connected to the power supply?Check the connection.
The blade of the blender 5 is turning with difficulty or not turning at all	Switch off immediately, pull out mains plug 1 and check:- Blockage in the vessel?- Food too tough or too hard?- Device not assembled correctly?

GB

7

10. Disposal

The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this

symbol. Products identified with this symbol may not be discarded with normal household waste, but must be taken to a collection point for recycling electric and electronic appliances. Recycling helps to reduce the consumption of raw materials and protect the environment.

Packaging

When disposing of the packaging, make sure you comply with the environmental regulations applicable in your country.

1. Technical specifications

Model: SSM 300	A1
Mains voltage: 22	0-240 V ~ 50 Hz
Protection class: II
Power rating: 300	W
Max. continuous operation (KB): 1	minute

Subject to technical modification.

CE

12. Warranty of the HOYER Handel GmbH

Dear Customer, your device is provided with a 3 year warranty starting with the purchase date. In the event of product defects, you are entitled to statutory rights against the vendor. These statutory rights are not restricted by our warranty presented in the following.

Warranty conditions

The warranty period starts with the purchase date. Please keep the original purchase receipt in a safe place. This document is required to verify the purchase.

If within three years from the purchase date of this product a material or factory defect occurs, the product will be repaired or replaced by us – at our discretion – free of charge to you. This warranty implies that within the period of three years the defective device and the purchase receipt are presented, including a brief written description of the defect and the time it occurred.

If the defect is covered by our warranty, the repaired or a new product will be returned to you. No new warranty period starts with a repair or replacement of the product.

Warranty period and statutory claims for defects

The warranty period is not extended when the warranty has been claimed. This also applies to replaced and repaired parts. Any damages and defects already existing at the time of purchase must be reported immediately upon unpacking. Repairs arising after the expiration of the warranty period are subject to a charge.

Warranty coverage

The device was produced carefully according to strict quality guidelines and tested diligently prior to delivery.

The warranty applies to material or factory defects. This warranty does not include prod-

8

GB

uct parts that are subject to standard wear and therefore can be considered wear parts; the same applies to damages at fragile parts, e.g. switches, rechargeable batteries or parts made of glass.

This warranty expires if the product is damaged, not used as intended or not serviced. For the proper operation of the product, all instructions listed in the operating instructions must be observed carefully. Any form of use and handling that is advised against in the operating instructions or warned against must always be avoided.

The product is only intended for private and not for commercial use. In the case of incorrect and improper treatment, use of force and interventions not performed by our authorised Service Centre, the warranty shall cease.

Handling in case of a warranty claim

In order to ensure prompt processing of your matter, please observe the following notes:

• Please keep the article number
  IAN: 93358 and the purchase receipt as a purchase verification for all inquiries.
• If faulty operation or other defects occur, first contact the Service Centre listed in the following by telephone or email.
• Then, you are able to send a product reported as defective free of charge to the service address specified to you, including the purchase receipt and the information on the defect and when it occurred.

Please visit www.lidl-service.com to download this and many other manuals, product videos and software.

Service Centre

GB Service Great Britain Tel.: [phone] (£ 0.10/Min.) E-Mail: [e-mail]

IE Service Ireland Tel.: [phone] (0,08 EUR/Min., (peak)) (0,06 EUR/Min., (off peak)) E-Mail: [e-mail]

IAN: 93358

Supplier

Please note that the following address is no service address. First contact the aforementioned Service Centre.

Pure geometric diagram with intersecting lines and circles, no text or symbols present

Pure geometric diagram with intersecting lines and circles, no text or symbols present

Pure geometric diagram with intersecting lines and circles, no text or symbols present

Inhoud
