CG-810V - Coffee maker FAGOR - Free user manual and instructions
Find the device manual for free CG-810V FAGOR in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Drip coffee maker |
| Brand | FAGOR |
| Model | CG-810V |
| Power | 1100 W |
| Voltage | 230 V ~ 50 Hz |
| Water tank capacity | 1.2 L |
| Number of cups | 10 cups of 120 cm³ |
| Filter type | Permanent filter (reusable) + compatible with 1x4 cone disposable filters |
| Housing material | Plastic |
| Carafe material | Glass |
| Hot plate | Yes, keeps warm |
| Illuminated switch | Yes, with operation indicator |
| Anti-drip valve | Yes, allows pouring a cup before cycle end |
| Water level indicator | Yes, visual on tank |
| Functions | Drip coffee preparation, keep warm |
| Care and cleaning | Clean removable parts with soapy water; exterior with a damp cloth. Do not immerse. |
| Recommended descaling | Every 4 weeks with white vinegar or descaling product |
| Safety | Manual stop via switch; do not use without water; glass carafe handle with care |
| Power cord length | Approximately 0.8 m (estimated) |
| Weight | Approximately 1.5 kg (estimated) |
| Dimensions (L × P × H) | Approximately 25 × 20 × 30 cm (estimated) |
Frequently Asked Questions - CG-810V FAGOR
How to use the coffee maker for the first time?
Before first use, clean all removable parts (filter holder, filter, carafe, lid) with warm soapy water. Rinse and dry. Then, run the coffee maker twice without coffee, with water only, to clean the inside. Follow the coffee preparation steps described in the manual.
How much coffee to grind?
We recommend one level tablespoon of ground coffee per cup. Adjust to taste after a few uses.
Why is the coffee not flowing into the carafe?
Check that the carafe lid is properly positioned and that it opens the nozzle valve at the bottom of the filter holder. If the valve remains closed, water cannot pass through.
Can I use disposable paper filters?
Yes, you can use disposable cone filters size 1x4 for this model. The included permanent filter is also reusable.
How to descale the coffee maker?
Fill the carafe with one part white vinegar to three parts water. Pour into the tank and run a cycle. Repeat 2 to 3 times depending on scale. Then run 2 to 3 cycles with clear water to remove residues. Descale every 4 weeks.
Can I remove the carafe during brewing?
Yes, thanks to the anti-drip valve, you can remove the carafe to pour a cup before the cycle ends. Replace it immediately afterward to prevent the filter from overflowing. Wait until at least two cups have passed before removing it.
How to clean the coffee maker?
Turn off and unplug the appliance, let it cool. Clean the filter holder, filter, carafe and its lid with warm soapy water. The exterior can be cleaned with a damp cloth. Do not use abrasive products and never immerse the appliance body.
What to do if the coffee maker no longer heats?
Check that the switch is on and the outlet works. If the problem persists, contact an authorized technical service center. Do not attempt to repair yourself.
Can I leave water in the tank after use?
It is best to empty the tank after each use to prevent scale buildup and water stagnation. Let the coffee maker cool before cleaning.
What is the maximum water capacity?
The tank has a capacity of 1.2 liters, allowing you to prepare up to 10 cups of 120 ml. Do not exceed the indicated maximum level.
