Product Type	Conical Curling Iron
Model	Björn Axén Touch Conical Curler 3112
Brand	OBH Nordica
Barrel Shape	Conical (tapered)
Barrel Material	Ceramic tourmaline
Barrel Coating	Tourmaline-infused ceramic
Temperature Settings	5 adjustable heat settings (140°C - 200°C)
Heat-Up Time	30 seconds
Auto Shut-Off	Yes, after 60 minutes
Swivel Cord	Yes, 360° swivel cord
Cord Length	2.5 meters
Dual Voltage	Yes (110-240V) for worldwide use
Power	30-50W (typical)
Dimensions (L x W x H)	35 x 4 x 4 cm
Weight	350 g (approx.)
Features	Ionic technology, cool tip, heat-resistant mat included
Care and Cleaning	Unplug and wipe barrel with damp cloth; do not submerge
Safety	Auto shut-off, cool tip, heat-resistant glove recommended
Spare Parts	Replacement cord available from OBH Nordica
Reparability	Not user-serviceable; contact authorized service center
General Information	For professional results at home; suitable for all hair types

Frequently Asked Questions - Björn Axén Touch Conical Curler 3112 OBH NORDICA

What is the barrel diameter of the Björn Axén Touch Conical Curler 3112?

The barrel is conical, tapering from approximately 13 mm at the tip to 25 mm at the base.

How long does it take to heat up?

The curler heats up in about 30 seconds, ready for use.

Does it have an automatic shut-off feature?

Yes, it automatically shuts off after 60 minutes of inactivity for safety.

Can I use this curler on wet hair?

No, always use on dry hair to avoid damage and ensure safety.

What temperature settings are available?

There are 5 heat settings ranging from 140°C to 200°C, adjustable with a slider.

Is the cord swivel?

Yes, the cord has a 360° swivel for easy maneuverability.

Does it have dual voltage for travel?

Yes, it supports 100-240V, suitable for use worldwide with a plug adapter.

How do I clean the curler?

Unplug and let it cool. Wipe the barrel with a damp cloth. Do not submerge in water.

Is there a cool tip to prevent burns?

Yes, the tip remains cool to the touch for safe handling during styling.

What is the warranty period?

OBH Nordica offers a 2-year warranty against manufacturing defects. Retain proof of purchase.

USER MANUAL Björn Axén Touch Conical Curler 3112 OBH NORDICA

BEGRENSET GARANTI for OBH Nordica

Garantien

1. Read the instruction manual carefully before use, and save it for future use.
2. Plug the appliance to a household outlet of 220-240V only, and use the appliance only for the intended use.
3. Always unplug the appliance from the mains supply when disorder is experienced, when not in use, and before cleaning and maintenance.
4. This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way by a person responsible for their safety and they understand the hazards involved.
5. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
6. Cleaning and user maintenance shall not be made by children, unless they are over the age of 8 and supervised.
7. Check that the cord is not hanging over the edge of the table.
8. The appliance should only be used under supervision.

9. Warning: Do not use this appliance near bathtubs, showers, basins or other vessels containing water.

10. The appliance should not be immersed in water or other liquids. Never use the appliance with wet hands and never place the appliance on a wet or damp surface.

11. Always unplug the appliance from the mains supply immediately after use, if the appliance is used in a bathroom since the proximity of water presents a hazard even when the appliance is switched off.
12. Always examine appliance, cord and plug for damage before use. If the supply cord is damaged, it must be replaced by the manufacturer, or his service agent or a similarly qualified person in order to avoid a hazard.
13. For additional protection the installation of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA is recommended. Ask your installer for advice.
14. The appliance is for domestic use only.
15. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages to the product or other things are not covered by the warranty.

Use

Plug the appliance to a wall outlet. The switch's indicator light comes on. Press the switch for around 1 second and the display shows 160 (the preset temperature) and a beep is heard. If you want to change the temperature, set the wanted temperature between 130-200°C by means of the + and - buttons on the handle. Select temperature setting depending on your hair type, see the recommendations below. The temperature bars go on and off alternately until the set temperature has been reached.

The temperature bars are permanently lit.

120-160°C low temperature - thin, fine hair/coloured hair

160-190°C medium temperature - normal hair 190-200°C high temperature - very thick and dense hair

Position the curling iron with the ON/OFF button facing upwards in order that the curling iron is resting on the stand. Make sure that the support is even and heat-resistant.

Make sure that the hair is completely dry before you use the curling iron. Open the clamp of the curling iron and press an approximately 5 cm wide hair section. Spread the hair section evenly in the clamp and roll the iron towards the scalp. If you just want to curve the hair ends with the curling iron, you just place the ends in the clamp and wind the hair half a turn or a full turn as you wish. Hold it for about 5-8 seconds depending on the length and texture of the hair. Open the clamp carefully and release the curl from the iron. To maintain the curl let the hair cool before combing or brushing.

If you want screw curls, roll up less hair. If you want to have bigger and softer curls, roll up more hair.

Make sure that the hot parts of the curling iron do not touch your scalp, your face, neck or hands. Do not use the appliance for wigs, hair extensions or artificial hair without having tested the appliance on a small section of hair, as there may be a risk that the hair will melt.

Button locking function

In order to lock the buttons in order to avoid inadvertent changing of the temperature setting or switching off the curling iron, slide the lock button on the side of the handle to the “locked padlock”. The symbol in the display changes to locked. To unlock it again, slide the button to the “open padlock”. The symbol in the display changes to unlocked.

NB! If the curling iron cannot be started once plugged in, check first that the lock button function is not activated.

Auto-off function

The curling iron automatically turns off after around 40 minutes. The display then switches off completely while the switch will remain lit. Note that the curling iron is not switched off completely until it has been unplugged. In order to reactivate the curling iron press the ON/OFF button and set the wanted temperature. The auto-off function is a supplementary safety function, but as a main rule, the appliance should always be unplugged after use.

Cleaning and maintenance

- Switch off the appliance by pressing the ON/OFF button until the display switches off and a beep is heard. Unplug and let the curling iron cool completely on a heat-resistant mat before cleaning. The curling iron reaches very high temperatures during use and consequently it takes some time before it has cooled off completely. Make sure that the appliance is out of the reach of children.

• Never immerse the appliance and the cord in water of any other liquid.
• Be careful that water does not penetrate into the housing!
• Wipe dry the housing and the plier of the appliance with a damp cloth. Wipe with a dry cloth.
• If the curling iron gets dirty with styling products, wipe the surface with a slightly damp sponge or a cloth. Wipe with a dry cloth.
  • Make sure that the appliance is completely cool and dry before storing.
• Store the appliance at a dry and safe place out of reach of children after use.

Do not wind the cord around the appliance as this means an extra charge with a risk of damage to the cord.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment shall be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

OBH Nordica LIMITED GUARANTEE

The Guarantee

OBH Nordica guarantees this product against any manufacturing defect in materials or workmanship during 2 years within Sweden, Norway, Denmark and Finland, starting from the initial date of purchase or delivery date.

This manufacturer's commercial guarantee covers all costs related to restoring the proven defective product so that it conforms to its original specifications, through the repair or replacement of any defective part and the necessary labour. At OBH Nordicas choice, a replacement product may be provided instead of repairing a defective product. OBH Nordicas sole obligation and your exclusive resolution under this guarantee are limited to such repair or replacement.

Conditions & Exclusions

OBH Nordica shall not be obliged to repair or replace any product which is not accompanied by a valid proof of purchase. The defective product may be returned to the store of purchase.

This guarantee applies only for products purchased and used for domestic purposes and will not cover any damage which occurs as a result of misuse, negligence, failure to follow OBH Nordica instructions, or a modification or unauthorised repair of the product, faulty packaging by the owner or mishandling by any carrier. It also does not cover normal wear and tear, maintenance or replacement of consumable parts, or the following:

• using the wrong type of water or consumable

• mechanical damages, overloading

• damages or poor results specifically due to wrong voltage or frequency as stamped on the product ID or specification

• ingress of water, dust or insects into the product
• scaling (any de-scaling must be carried out according to the instructions for use)
• damage as a result of lightning or power surges
• damage to any glass or porcelain ware in the product
• accidents including fire, flood, etc
• professional or commercial use

Consumer Statutory Rights

OBH Nordica's commercial guarantee does not affect the Statutory Rights a consumer may have or those rights that cannot be excluded or limited, nor rights against the retailer from which the consumer purchased the product. This guarantee gives a consumer specific legal rights, and the consumer may also have other legal rights which vary from Country to Country. The consumer may assert any such rights at his sole discretion.

These instructions are also available on our website www.obhnordica.com.

TEFAL - OBH Nordica Group AB

Löfströms Allé 5

172 66 Sundbyberg

Phone: [phone]

www.obhnordica.com

Technical data

OBH Nordica 3109, 3110, 3111

220-240V \~, 50 Hz

3109 - 46 W

3110 - 60 W

3111 - 76 W

Temperature setting at (120-200°C) with 10°C intervals

Ceramic coating with infused Keratin

Automatic switch-off after about 40 min.

Cord length 2.8 m

CE

These instructions are subject to alterations or improvements.

Three black-and-white images of a curling iron with visible branding and metal bands, shown from different angles (no text or symbols on the devices themselves)
