WFB-1 - Electric Blanket / Heating Pad WILFA - Free user manual and instructions

Product Type	Electric Blanket / Heating Pad
Brand	Wilfa
Model	WFB-1
Power Supply	220-240 V ~ 50 Hz
Heat Output	Approx. 160 W
Control Type	Detachable control unit with sliding switch and display
Heat Levels	L, 1, 2, 3, H (5 levels)
Auto Shut-off	After 3 hours
Material	Microfiber fleece (outer layers)
Washability	Hand wash at up to 30°C (control unit removed)
Safety Features	Overheat protection, thermal link, auto shut-off
Usage	Indoor use only; not for hospitals
What's Included	1 heating blanket with control unit, 1 instruction manual
Certification	CE, WEEE compliant
Warranty	2 years from date of purchase

Frequently Asked Questions - WFB-1 WILFA

How do I turn on the Wilfa WFB-1 electric blanket?

Press the On/Off button on the control unit. Then use the heat button to select your desired temperature level (L, 1, 2, 3, H). The selected level will appear on the display.

Can I wash the heating blanket?

Yes, the blanket can be hand washed at up to 30°C. Always unplug the control unit before washing. Never immerse the control unit in water. Allow the blanket to dry completely before reconnecting the control unit.

Does the blanket have an auto shut-off feature?

Yes, as an extra safety feature, the heating blanket will turn off automatically after 3 hours. To restart, simply press the On/Off button again.

Can children use this electric blanket?

The blanket should not be used by small children or persons insensitive to heat. Children may use it only if the controls have been pre-set by a parent or guardian, and they are adequately instructed. Supervision is required.

What should I do if the blanket is damaged?

Do not use if you notice wear or damage. Do not repair yourself. Contact an authorized dealer or qualified personnel for repairs. If the power cord is damaged, it must be replaced by the manufacturer or a qualified person.

Can I use the blanket with a timer or extension cord?

The manual does not recommend using a timer or extension cord. The blanket should be plugged directly into a mains outlet. Never cover the control unit or lead while in use.

How should I store the electric blanket?

Allow the blanket to cool down before folding. Store in a clean, dry place. Do not place items on top of it during storage to avoid creasing.

Is the blanket suitable for hospital use?

No, the device is intended for private household use only and is not to be used in hospitals.

What does the indicator light on the control unit show?

The indicator light confirms that the blanket is powered on. It is located on the control unit and illuminates when the blanket is in operation.

How long is the warranty period?

The warranty period is 2 years from the date of purchase. A copy of the receipt or invoice is required for warranty claims.

USER MANUAL WFB-1 WILFA

Folded brown fabric with a medical thermometer device placed beside it (no visible text or symbols)

Modell :WFB-1

NO BRUKSANVISNING

SE BRUKSANVISNING

DK BRUGSANVISNING

FI KÄYTTÖOHJE

GB INSTRUCTION MANUAL

NO Sikkerhetsinstrukser

Please ensure that polybag packing is kept away from reach of children! Risk of suffocation!

Please ensure that polybag packing is kept away from reach of children! Risk of suffocation!

Please ensure that polybag packing is kept away from reach of children! Risk of suffocation!

ADVARSEL

Please ensure that polybag packing is kept away from reach of children! Risk of suffocation!

Käyttö

GB Safety instructions

Read the instruction manual carefully

before using this device, especially the

safety instructions. Keep the instruction manual for future use.

If you give this device to another person,

it is vital that you also include these usage instructions.

Do not pierce the heating blanket!

Do not use the heating blanket when folded!

Only use the heating blanket indoors!

Do not use bleach!

Do not dry clean!

The electric blanket may be hand washed according to the instructions on the label.

Important instructions. Retain for future use.

- Before connecting the appliance to your power supply, please ensure that the supply voltage stated on the rating plate is compatible with your mains supply.

- Check the heating blanket carefully before each use.

- Do not operate the heating blanket if you notice wear or damage to the blanket, switch or wires.

- Only use the heating blanket for the purpose described in these operating instructions.

- The heating blanket should not be used by small children or persons who are disabled, in need of care or insensitive to heat.

• Children must be supervised when using the blanket.

- The heating blanket may not be operated while folded, creased or wrapped around the mattress.

- During use, the control switch and lead must not be placed on or under the heating blanket or be otherwise covered in any way.

- No safety pins or other pointed or sharp objects should be attached to or pierce the heating blanket.

• Never leave the heating blanket unattended while switched on.

• The device is only for private use and is not to be used in hospitals.

- Never handle a heating blanket that has fallen into water. If this happens, unplug the blanket from the mains power supply immediately.

- Do not use the heating blanket in a damp or humid environment, or if the heating blanket itself is damp. Only use the blanket when it is completely dry.

- Never expose the control switch or leads to moisture of any kind.

- Keep the mains lead away from hot surfaces.

- Never carry, pull or twist the heating blanket by the mains lead and do not allow the lead to become tangled or snagged.

• Do not repair the heating blanket yourself in the event of damage or malfunction. Repairs should only be carried out by an authorized specialist dealer or suitably qualified personnel.
• The heating blanket may only be operated using the supplied control unit.
• When storing the appliance, allow it to cool down before folding.
• Should you have any health concerns, consult your doctor before using the heating blanket.
• If you experience persistent pains in the muscles and joints you should inform your doctor immediately. Persistent pains can be a symptom of serious illness.
• If you experience any pain or discomfort while using the unit, discontinue use immediately.

Device and controls

1. Heating blanket
2. Control unit with sliding switch
3. Cable
4. Indicator light

What's in the package

Before using the appliance, check that the unit is complete and not damaged in any way. If in doubt, do not use the appliance

The following parts are included as standard:

1 heating blanket with control unit

1 instruction for use

If you notice any transport damage while unpacking the appliance, please contact your dealer immediately.

The appliance is only to be used with the supplied controller.

The appliance must be returned to the manufacturer or agent if the thermal link has ruptured.

Do not crease the appliance by placing items on top of it during storage.

The appliance is not to be used by young children unless the controls have been pre-set by a parent or guardian, or the child has been adequately instructed on how to operate the controls safely. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they are supervised or given instruction in the use of the appliance by a person responsible for their safety.

If the power supply cord is damaged, it must be replaced by the manufacturer, a service agent or similarly qualified persons in order to avoid hazards.

WARNUNG

Please ensure that polybag packing is kept away from reach of children! Risk of suffocation!

Use

Using the heating blanket (1), you can gently

warm and relax your whole body. Snuggle up under the extra-soft

blanket for a pleasant, cosy feeling of well-being.

The heating blanket features an electric temperature control

that precisely regulates the warmth supplied according to the chosen setting (1-2-3-4). The two outer layers of the three-layer blanket are made of fluffy microfiber fleece.

The easy to care for material and the detachable operating element make the blanket and-washable

at up to 30°C.

Operation

WFB-1

Operation of controller

To turn on the unit push "On/Off button.

Push the heat button to set your desired temperature with heat levels “L-1.2.3----H”. Your setting will appear on display.

As an extra safety feature the heating blanket will turn off automatically after 3 hours. Push "On/Off" button to restart the unit.

Cleaning and maintenance

Before washing the heating blanket, unplug it from the mains outlet and let it cool down.

Unplug the control unit (2) from the heating blanket using the connector on the underside.

You may hand-wash the blanket at up to 30^ C.

Never immerse the control unit (2) in water. Moisture must never be allowed to get into the unit. . To dry, lay the heating blanket flat on a moisture absorbent towel or mat.

When the heating blanket is completely dry, it should be reconnected to the control unit (2) in the correct manner. The heating blanket may only be operated with the supplied control unit.

.When storing the heating blanket, allow it to cool down before folding. Store in a clean, dry place.

Disposal

This product must not be disposed of with normal domestic waste.

All users are obliged to hand in all electrical or electronic devices at a municipal or commercial collection point so that they can be disposed of in an environmentally acceptable manner, regardless of whether or not they contain toxic substances..

Consult your municipal authority or your dealer for information about disposal of this product.

Warranty and repair terms

Please contact your dealer or service centre in the case of a claim under warranty. When sending in the unit, please enclose a copy of your receipt and state the defect.

The following warranty terms apply:

1. The warranty period is two years from the date of purchase. In the case of a warranty claim, the date of purchase must be evidenced by the sales receipt or invoice.

2. Defects in material or workmanship will be removed free of charge within the warranty period.

3. Repairs under warranty do not extend the warranty period for the unit or replacement parts.

4. The following are excluded under the warranty:

a. All damage due to improper treatment, e.g. nonobservance of the user instructions.

b. All damage due to tampering or repairs carried out by the customer or unauthorized third parties.

c. Damage caused during transport from the manufacturer to the consumer or during transport to the service centre.

d. Accessories which are subject to normal wear and tear.

1. No liability can be taken for direct or indirect consequential losses caused by the unit, even if the damage to the unit is accepted as a warranty claim.

Specifications

Model No : WFB-1

Power supply : 220-240V\~50Hz

Heat output : approx. 160W

In accordance with our policy of continual product improvement, we reserve the right to make technical and design changes without notice.

According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in future you need to dispose of this product please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available.
