KMI3500BL - Range hood Kluge - Free user manual and instructions

Product Type	Range Hood
Brand	Kluge
Model	KMI3500BL
EAN Code	5901703840960
Energy Class	A++
Annual Energy Consumption	66 kWh/annum
Noise Level	65 dB
Dimensions (W x D x H)	600 x 500 x (adjustable) mm
Weight	12 kg
Power Supply	220-240 V, 50 Hz
Motor Power	250 W
Maximum Extraction Rate	500 m³/h
Number of Speeds	3
Lighting	LED (2 x 1.5 W)
Filter Type	Aluminum grease filter
Control Type	Electronic touch controls
Installation Type	Wall-mounted chimney hood
Mode	Ducted / Recirculating (optional carbon filter)
Maintenance	Clean grease filter monthly
Security Features	Auto shut-off timer, overheat protection
Spare Parts Available	Grease filters, carbon filters, LED bulbs
Warranty	2 years
Repairability Index	7.0 / 10 (based on user rating)

Frequently Asked Questions - KMI3500BL Kluge

How do I install the KMI3500BL range hood?

Installation should be done by a qualified professional. Ensure the hood is mounted at the recommended height (65-75 cm above electric hob, 75-85 cm above gas hob). Use the included mounting template and secure with appropriate anchors. Connect ductwork for exit air or install carbon filters for recirculation mode.

How often should I clean the grease filter?

The aluminum grease filter should be cleaned every month under normal usage. Remove it and wash with warm soapy water or in the dishwasher at low temperature. Dry thoroughly before reattaching.

How do I replace the charcoal filter for recirculation mode?

Charcoal filters are needed for recirculation mode. They should be replaced every 3-6 months depending on usage. Remove the grease filter first, then slide out the old charcoal filter and insert a new one (model: Kluge ACKMI). Reattach the grease filter.

What is the noise level of the KMI3500BL?

The noise level is rated at 65 dB, which is comparable to a normal conversation. It may vary slightly depending on the speed setting.

What are the dimensions of this range hood?

The KMI3500BL has a width of 600 mm, a depth of 500 mm, and a height adjustable from 700 to 1100 mm (including chimney). Always check the manual for exact measurements.

How do I control the hood?

The hood features electronic touch controls. Press the power button to turn on/off. Use the speed buttons (1-3) to adjust fan speed. The light button toggles the LED lighting.

Does the hood have a warranty?

Yes, the Kluge KMI3500BL comes with a 2-year manufacturer warranty covering defects in materials and workmanship. Retain your purchase receipt for service.

What should I do if the hood is not extracting effectively?

First, check that the grease filter is clean. If clogged, clean or replace it. Ensure ductwork is not blocked. In recirculation mode, replace the charcoal filter if saturated. Also verify that the speed setting is adequate.

Can I use the hood without ducting?

Yes, the KMI3500BL can be used in recirculation mode. You need to install Kluge charcoal filters (sold separately) to filter odors and recirculate air back into the kitchen.

How do I reset the filter reminder?

After cleaning or replacing filters, press and hold the speed button for 3 seconds until the indicator light blinks and turns off. This resets the alarm. Refer to the manual for exact procedure.

USER MANUAL KMI3500BL Kluge

Black cylindrical device with ventilation grille and three vertical slots, no visible text or symbols

ODSAVAČ KMI3500BL

Výrobce: Kluge

Kód EAN: 5901703840960

Popis
