KOV5002BLG - Range hood Kluge - Free user manual and instructions

Product Type	Range Hood
Brand	Kluge
Model	KOV5002BLG
Mounting Type	Under-cabinet
Width	60 cm (approx.)
Extraction Type	Recirculating / Ducted
Number of Motor Speeds	3
Max Extraction Rate	650 m³/h (approx.)
Noise Level	55 dB (approx.)
Lighting	2 x 3 W LED
Filter Type	Aluminum grease filter
Filter Cleaning	Monthly in dishwasher or by hand
Carbon Filter	Optional for recirculation
Energy Class	A+ (approx.)
Power Consumption	100 W (approx.)
Voltage	220-240 V, 50 Hz
Dimensions (W x D x H)	60 x 50 x 13 cm (approx.)
Weight	12 kg (approx.)
Control Type	Push buttons
Safety Features	Auto shut-off, thermal protection
Spare Parts	Grease filters, carbon filters, LED lamps available
Repairability Index	8/10 (estimated)
Warranty	2 years

Frequently Asked Questions - KOV5002BLG Kluge

How do I install the Kluge KOV5002BLG range hood?

Installation should be carried out by a qualified technician. Ensure the hood is mounted at least 65 cm above gas cooktops or 50 cm above electric cooktops. Use the included mounting bracket and follow the manual's instructions for ducting or recirculation setup.

How can I switch between ducted and recirculating mode?

The hood can operate in both modes. For recirculation, you need to install an optional carbon filter (not included). In ducted mode, connect the exhaust hose to an external vent. Refer to the manual for the filter installation guide.

How often should I clean the grease filters?

Clean the aluminum grease filters every month or more frequently if you cook heavily. They are dishwasher safe. Remove them by pressing the latch and pulling them down. Ensure they are completely dry before reinstalling.

How do I replace the carbon filter?

Carbon filters should be replaced every 3-6 months depending on usage. To replace, remove the grease filters, then slide out the old carbon filter and insert a new one. Make sure the filter locks into place.

What should I do if the hood is not extracting air properly?

Check that the grease filters are clean and not clogged. Ensure the ducting is not blocked or kinked. If using recirculation, verify the carbon filter is not saturated. Also, make sure the vent flaps open when the hood is on.

How do I change the LED bulbs?

The LED lights are integrated and not user-replaceable. If they fail, contact Kluge customer service or a qualified technician for replacement. Do not attempt to replace them yourself to avoid electric shock.

Why is the hood making noise?

Noise can be due to loose parts, unbalanced fan blades, or a blocked duct. Check all screws and tighten if necessary. Ensure the filters are properly installed. If noise persists, contact support.

Can I use the hood without a filter?

No, never operate the hood without the grease filters. The filters protect the motor from grease buildup and prevent fire hazards. Operating without filters can also reduce suction efficiency.

How do I reset the filter cleaning indicator?

After cleaning or replacing filters, press and hold the light button for about 5 seconds until the indicator light turns off or blinks. Refer to the manual for exact procedure as it may vary.

Where can I find spare parts for the KOV5002BLG?

Spare parts such as grease filters, carbon filters, and LED lamps can be purchased from Kluge authorized dealers or online stores. Use the model number KOV5002BLG to ensure compatibility.

USER MANUAL KOV5002BLG Kluge

Black overhead air duct with ventilation grilles and mounting holes (no text or symbols visible)

ODSAVAČ PLNĚ VESTAVNÝ KOV5002BLG

Výrobce: Kluge

Kód EAN: 5902429926815

Popis
