PB300002B - Power bank GoGen - Free user manual and instructions

Product Type	Power Bank (External Battery)
Brand	GoGen
Model	PB300002B
Battery Type	Lithium Polymer (Li-Pol)
Battery Capacity	30,000 mAh
Input (USB-C)	5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A
Output (USB-C)	5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A
Output (USB 1/2)	4.5V/5A, 5V/3A, 9V/2A, 12V/1.5A
Power Delivery (PD)	Supported via USB-C
Dimensions (L x W x H)	164 x 70.5 x 43 mm
Weight	638 g
Display	LCD power indicator (percentage)
Auto Power On/Off	Yes (on when connected, off 20s after disconnection)
Safety Features	Overcharge protection, short circuit prevention, temperature protection
Package Contents	Power bank, USB-C cable, instruction manual
Warranty	2 years (excluding natural capacity decrease)
Maintenance	Fully charge every 3 months to prolong lifespan
Operating Temperature	Room temperature (avoid heat sources)

Frequently Asked Questions - PB300002B GoGen

How do I charge the power bank for the first time?

For first use, fully charge the power bank completely. Use a standard 5V/2A or higher charger with the USB-C cable provided.

Can I charge my laptop with this power bank?

Yes, via the USB-C port supporting Power Delivery (PD) up to 65W (20V/3.25A). Ensure your laptop supports USB-C charging and use a compatible cable.

How do I check the remaining battery level?

Press the power button on the side to display the remaining capacity as a percentage on the LCD screen.

How long does it take to fully charge the power bank?

Charging time depends on the input power. With a 65W charger (20V/3.25A), it can take approximately 4-5 hours. With a standard 5V/2A charger, it may take up to 15 hours.

Can I charge multiple devices simultaneously?

Yes, the power bank has two USB-A ports and two USB-C ports (one input/output). You can charge up to 4 devices at once, but total output power is shared.

Is it safe to leave the power bank charging overnight?

Yes, the power bank has overcharge protection. It will automatically stop charging when full. However, never leave it unattended for extended periods.

What should I do if the power bank gets hot during charging?

It is normal for the casing to warm up during charging. After full charge, it will cool down to room temperature. If overheating persists, stop use and contact support.

Can I use a non-standard charging cable?

It is recommended to use the provided USB-C cable or a certified cable with appropriate specifications to avoid damage to the power bank.

How do I maintain the battery lifespan?

Fully charge the power bank every three months if not in use. Avoid exposure to high temperatures, moisture, and dropping the device.

What does the warranty cover?

The product has a 2-year warranty covering material defects and workmanship. It does not cover natural capacity decrease due to age or usage.

USER MANUAL PB300002B GoGen

Exterior view of a modern black rectangular electronic device (no visible text or symbols)

Prohibition sign with a circular border and a central circular symbol (no text or numbers)

Prohibition sign with a crossed-out robot figure inside a circle (no text)

NEBEZPEČÍ UDUŠENÍ. PE SÁČEK ODKLÁDEJTE MIMO DOSAH DĚTÍ. SÁČEK NENÍ NA HRANÍ. NEPOUŽÍVEJTE TENTO SÁČEK V KOLÉBKÁCH, POSTÝLKÁCH, KOČÁRCÍCH NEBO DĚTSKÝCH

OHRÁDKÁCH.

Symbol of a trash bin crossed with two crossed lines and a solid black rectangle below (no text or labels)

Prohibition sign with a circular border and silhouette of a person (no text or symbols)

Prohibition sign with a crossed-out robot figure inside a circle (no text)

NEBEZPEČENSTVO UDUSENIA. PE VRECKO ODKLADAJTE MIMO DOSAHU DETÍ. VRECKO NIE JE NA HRANIE. NEPOUŽÍVAJTE TOTO VRECÚŠKO V KOLÍSKACH,

POSTIEL'KACH, KOČÍKOCH ALEBO DETSKÝCH OHRÁDKACH.

Thank you for purchasing our product. For optimum performance and safety, please read these instructions carefully before operating the product. Please keep this manual for future reference.

PACKAGE CONTENT

Powerbank, USB-C cabel, instruction manual

DEVICE LAYOUT

1. ON button
2. USB-C 1 input/ output
3. USB 1 output
4. USB-C 2 input/ output
5. USB 2 output
6. LCD display power indicator

CHARGING INSTRUCTION

The power bank will auto power on when connected and turn off automatically 20 seconds after disconnecting. Press the power button to turn the product on.

CHARGING OF MOBILE DEVICES

Connect the charging cable to the USB output or the USB-C output on the device and the mobile device. Charging starts automatically. Please use compatible charging cable for using PD (Power Delivery) function.

CHARGING THE POWER BANK

Connect the backup power supply using a charging cable to a power supply with a minimum charging current of 5V / 2A. USB-C input on the device can be used.

CAPACITY INDICATION

Press the main button to show the remaining capacity:

ATTENTION

This device has safety protection that prevent the battery from damages when overcharging. It is normal for the casing to become warm during charging and it will gradually cool down to room temperature after fully charged.

Please make a complete charge every three month to avoid shorten the mobile power life span.

TECHNICAL SPECIFICATION

Battery type: Li-pol Battery

Capacity: 30 000 mAh

Input: USB-C DC 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V / 3,25 A

Output: USB-C DC 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V / 3,25 A

USB 1/2 DC 4,5V / 5 A, 5 V / 3 A, 9 V / 2 A, 12 V / 1,5 A

Dimension: 164 x 70,5 x 43 mm

Weight: 638 g

CAUTION

• Please completely full charge the mobile power in first usage.
• Please make sure that use standard cable with appropriate specification, or it may lead to the mobile power damage.
• Please confirm the voltage of the electric device is 5V before charging it.
• Do not drop, knock, disassemble or attempt to repair the mobile power by yourself.
• Do not immerse or put the mobile power in water or damp place.
• Do not expose or put the mobile power near to heat sources or flammable place.
• Do not put the mobile power in car, for strong light and high temperature will lead to product damage.
• Keep the mobile power away from children.
• Do not put any item into the mobile power USB input and output ports to avoid any shortcut or damage.
• Please make a complete charge every three month to avoid shorten the mobile power life span.
• This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safety. Young children should be supervised to ensure that they do not play with the appliance.
• Never charge the battery unattended.

WARRANTY

Our product is warranted for 2 full year from the date of purchase. The warranty is provided on all material defects and workmanship. Guarantee of 24 months does not apply to decrease in the accumulator's effective capacity caused by its use or age. Effective capacity gradually decreases depending on the method of use of the accumulator.

WE RESERVE THE RIGHT TO CHANGE TECHNICAL SPECIFICATIONS.

TO AVOID DANGER OF SUFFOCATION, KEEP THE PLASTIC BAG AWAY FROM BABIES AND CHILDREN. DO NOT USE THIS BAG IN CRIBS, BEDS, CARRIAGES OR PLAYPENS. THIS BAG IS NOT A

TOY.

Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by

inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Symbol of a person without a device, enclosed in a circle (no text or numbers present)

Prohibition sign with a crossed-out robot silhouette (no text or symbols)

NIEBEZPIECZEŃSTWO UDUSZENIA. TOREBKE Z PE POŁOŻYĆ W MIEJSCU BĘDĄCYM POZA ZASIĘGIEM DZIECI. TOREBKA NIE SŁUŻY DO ZABAWY! TEGO WORKA NIE NALEŻY UŻYWAĆ W KOŁYSKACH, ŁÓŻECZKACH,

WÓZKACH LUB KOJCACH DZIECIĘCYCH.

Symbol of a trash bin crossed with a diagonal line and a horizontal bar below (no text or numbers present)

Symbol of a person inside a circle with a diagonal line crossing through it (no text or numbers present)

Prohibition sign with a crossed-out animal silhouette (no text or symbols)

FULLADÁSVESZÉLY. TARTSA A PE ZACSKÓT GYERMEKEKTÓL ELZÁRT HELYEN. A ZACSKÓ NEM JÁTÉKSZER. NE HASZNÁLJA EZT A ZACSKÓT BÖLCSŐKBEN, KISÁGYAKBAN,

BABAKOCSIKBAN, VAGY GYEREK JÁRÓKÁKBAN.

Symbol of a trash bin crossed with two crossed lines, no text or numbers present
