PB100009W - Power bank GoGen - Free user manual and instructions

Product Type	Portable Power Bank / External Battery
Brand	GoGen
Model	PB100009W
Battery Capacity	10,000 mAh
Battery Type	Lithium-Polymer (Li-Pol)
Input Ports	Micro USB, USB-C (DC 5V/2A)
Output Ports	2 x USB-A (DC 5V/2.1A each)
Dimensions	100 x 63 x 26 mm
Weight	220 g
Color	White
LED Indicators	4-level capacity indicator (25%, 50%, 75%, 100%)
Power Button	Yes, for checking battery level and manual power on
Auto Power On/Off	Auto on when connected, auto off after 20 seconds of disconnection
Safety Protections	Overcharge, short circuit, temperature protection
Package Contents	Power bank, charging cable (USB-A to Micro USB/USB-C?), instruction manual
Warranty	2 years from date of purchase (does not cover capacity loss due to use or age)
Charging Time (Power Bank)	Approx. 5-6 hours with 5V/2A charger (estimated)
Compatible Devices	Smartphones, tablets, and other USB-charged devices up to 2.1A
Usage Temperature	0°C to 45°C (charging), -10°C to 60°C (storage)
Disposal	Do not dispose with household waste; recycle at appropriate collection point

Frequently Asked Questions - PB100009W GoGen

How do I charge the power bank?

Use the provided charging cable and a power adapter with at least 5V/2A output. Connect the cable to the Micro USB or USB-C input on the power bank. The LED indicators will show the charging status.

How do I charge my phone with this power bank?

Connect your phone's charging cable to one of the USB output ports (USB 1 or USB 2). Charging starts automatically. The power bank will turn off 20 seconds after disconnecting.

How can I check the remaining battery level?

Press the power button once. The LED indicators will light up to show the remaining capacity: 1 LED = 25%, 2 LEDs = 50%, 3 LEDs = 75%, 4 LEDs = 100%.

Can I charge the power bank and my phone at the same time?

Yes, you can charge the power bank while it is charging your phone. However, note that the output may be slightly slower due to shared input power.

What is the maximum output current?

Each USB port provides up to 2.1A (5V). The total output is limited, but sufficient for most smartphones and tablets.

Is it normal for the power bank to get warm while charging?

Yes, it is normal for the casing to become warm during charging or discharging. It will gradually cool down after use. If it becomes excessively hot, stop using and contact support.

How often should I recharge the power bank if not used?

To maintain battery health, perform a full charge every three months. This prevents excessive discharge and prolongs lifespan.

What safety features does this power bank have?

The power bank includes protection against overcharging, short circuits, and overheating. It automatically stops charging when full and has temperature control.

Can I use any USB cable to charge devices?

It is recommended to use high-quality cables with appropriate specifications. Poor quality cables may result in slower charging or damage to the power bank.

What is the warranty period and what does it cover?

The power bank comes with a 2-year warranty from the date of purchase. It covers material defects and workmanship but does not cover normal capacity loss due to use or aging.

USER MANUAL PB100009W GoGen

Abstract logo design with a stylized white 'S' inside a circle on black background (no text or symbols)

PB 100009 B

PB 100009 W

GoGEN

Black rectangular electronic device with 'mi' branding and 'Chatter' branding, showing ports and connectors (no readable text beyond branding)

Simple X-shaped diagram with a black dot at the center and four surrounding circles (no text or symbols)

25%

Simple X-shaped diagram with black and white dots on each side (no text or symbols)

50%

Simple X-shaped diagram with four black dots and a white circle inside, no text or symbols present.

75%

Simple X-shaped diagram with four black dots at each corner, no text or symbols present.

100%

UPOZORNĚNÍ

Prohibition symbol with a person silhouette inside a circle (no text or numbers)

Prohibition sign with a diagonal line crossing through it, no text or symbols present.

NEBEZPEČÍ UDUŠENÍ. PE SÁČEK ODKLÁDEJTE MIMO DOSAH DĚTÍ. SÁČEK NENÍ NA HRANÍ. NEPOUŽÍVEJTE TENTO SÁČEK V KOLÉBKÁCH, POSTÝLKÁCH, KOČÁRCÍCH

NEBO DĚTSKÝCH OHRÁDKÁCH.

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

Simple X-shaped diagram with four circular nodes and a black dot at the top center (no text or symbols)

25%

Simple X-shaped diagram with two black dots and two white circles inside, no text or symbols present.

50%

Simple X-shaped diagram with four dots and a white circle inside, no text or symbols present.

75%

Simple X-shaped diagram with four black dots at the center and two outer curved lines forming a loop (no text or symbols)

100%

UPOZORNENIE

Prohibition sign with a figure crossed out by a diagonal line (no text or symbols)

Prohibition sign with a diagonal line crossing through it, no text or symbols present.

NEBEZPEČENSTVO UDUSENIA. PE VRECKO ODKLADAJTE MIMO DOSAHU DETÍ. VRECKO NIE JE NA HRANIE. NEPOUŽÍVAJTE TOTO VRECÚŠKO V KOLÍSKACH,

POSTIEL'KACH, KOČÍKOCH ALEBO DETSKÝCH OHRÁDKACH.

Symbol of a trash bin crossed with a diagonal line and a horizontal bar below (no text or numbers present)

Thank you for purchasing our product. For optimum performance and safety, please read these instructions carefully before operating the product. Please keep this manual for future reference.

PACKAGE CONTENT

Powerbank, charging cabel, instruction manual

DEVICE LAYOUT

1. ON button
2. USB 1 output
3. Micro USB input
4. USB-C input
5. USB 2 output
6. LED power indicator

CHARGING INSTRUCTION

The power bank will auto power on when connected and turn off automatically 20 seconds after disconnecting. Press the power button to turn the product on.

Charging of mobile devices

Connect the charging cable to the USB output on the device and the mobile device. Charging starts automatically.

Charging the power bank

Connect the backup power supply using a charging cable to a power supply with a minimum charging current of 5V / 2A. Micro USB or USB-C input on the device can be used.

Capacity Indication

Press the main button to show the remaining capacity:

Simple X-shaped diagram with a black dot at the center and four circular endpoints (no text or symbols)

25%

Simple X-shaped diagram with two black dots and two white circles, no text or symbols present.

50%

Simple X-shaped diagram with four dots and a small circle inside, no text or symbols present.

75%

Simple X-shaped diagram with four dots at the center and four outer circles, no text or symbols present.

100%

ATTENTION

This device has safety protection that prevent the battery from damages when overcharging. It is normal for the casing to become warm during charging and it will gradually cool down to room temperature after fully charged.

Please make a complete charge every three month to avoid shorten the mobile power life span.

TECHNICAL SPECIFICATION

Battery type: Li-pol Battery

Capacity: 10 000 mAh

Input: Micro USB / USB-C DC 5 V / 2 A

Output: USB 1/2 DC 5V / 2,1 A

Dimension: 100 x 63 x 26 mm

Weight: 220 g

CAUTION

- Please completely full charge the mobile power in first usage.

- Please make sure that use standard cable with appropriate specification, or it may lead to the mobile power damage.

- Please confirm the voltage of the electric device is 5V before charging it.

- Do not drop, knock, disassemble or attempt to repair the mobile power by yourself.

- Do not immerse or put the mobile power in water or damp place.

- Do not expose or put the mobile power near to heat sources or flammable place.

- Do not put the mobile power in car, for strong light and high temperature will lead to product damage.

- Keep the mobile power away from children.

- Do not put any item into the mobile power USB input and output ports to avoid any shortcut or damage.

- Please make a complete charge every three month to avoid shorten the mobile power life span.

- This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safety. Young children should be supervised to ensure that they do not play with the appliance.

- Never charge the battery unattended.

WARRANTY

Our product is warranted for 2 full year from the date of purchase. The warranty is provided on all material defects and workmanship. Guarantee of 24 months does not apply to decrease in the accumulator's effective capacity caused by its use or age. Effective capacity gradually decreases depending on the method of use of the accumulator.

WE RESERVE THE RIGHT TO CHANGE TECHNICAL SPECIFICATIONS.

TO AVOID DANGER OF SUFFOCATION, KEEP THE PLASTIC BAG AWAY FROM BABIES AND CHILDREN. DO NOT USE THIS BAG IN

CRIBS, BEDS, CARRIAGES OR PLAYPENS. THIS BAG IS NOT A TOY.

Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Simple X-shaped diagram with a black dot at the top center and four surrounding circles (no text or symbols)

25%

Simple X-shaped diagram with two black dots and two white circles on a white background (no text or symbols)

50%

Simple X-shaped diagram with four dots and a small circle inside, no text or symbols present.

75%

Simple X-shaped diagram with four black dots at the center and two curved lines forming an X shape (no text or symbols)

100%

UWAGA

NIEBEZPIECZEŃSTWO UDUSZENIA. TOREBKE Z PE POŁOŻYĆ W MIEJSCU BĘDĄCYM POZA ZASIĘGIEM DZIECI. TOREBKA NIE SŁUŻY DO ZABAWY! TEGO WORKA NIE

NALEŻY UŻYWAĆ W KOŁYSKACH, ŁÓŻECZKACH, WÓZKACH LUB KOJCACH DZIECIĘCYCH.

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

Simple geometric X-shaped diagram with four rounded corners and a central dot (no text or symbols)

25%

Simple X-shaped diagram with black and white dots on a white background (no text or symbols)

50%

Simple X-shaped diagram with four dots and a small circle inside, no text or symbols present.

75%

Simple X-shaped diagram with four black dots at each corner, no text or symbols present.

100%

FIGYELEM

FULLADÁSVESZÉLY. TARTSA A PE ZACSKÓT GYERMEKEKTŐL ELZÁRT HELYEN. A ZACSKÓ NEM JÁTÉKSZER. NE HASZNÁLJA EZT A ZACSKÓT

BÖLCSÖKBEN, KISÁGYAKBAN, BABAKOCSIKBAN, VAGY GYEREK JÁRÓKÁKBAN.

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid black rectangle below (no text or labels)
