Product Type	Power bank / External battery
Brand	GoGen
Model	PB100008R
Battery Type	Li-Polymer
Capacity	10000 mAh
Input (Micro USB)	5V/3A, 9V/2A, 12V/1.5A
Input (USB-C)	5V/3A, 9V/2A, 12V/1.5A
Output (USB-C)	5V/3A, 9V/2.22A, 12V/1.66A
Output (USB 1 & 2)	4.5V/5A, 5V/4.5A, 5V/3A, 9V/2A, 12V/1.5A
Max Output Power	22.5W
Dimensions	145.3 x 66 x 14.6 mm
Weight	245 g
Display	LCD power indicator
Cable Included	USB-C cable
Package Contents	Power bank, USB-C cable, user manual
Safety Features	Overcharge protection, short circuit protection, automatic shutdown
Auto-Off	20 seconds after disconnecting
Warranty	2 years from date of purchase
Operating Temperature	Not specified, recommended to avoid high temperature
Charging Time	Approximately 4 hours (with 5V/3A input)

Frequently Asked Questions - PB100008R GoGen

How do I charge the power bank?

Use a charging cable (Micro USB or USB-C) connected to a power source with at least 5V/2A. The power bank charges while connected.

How do I charge a mobile device?

Connect the device to one of the USB outputs or the USB-C output using a compatible cable. Charging starts automatically.

What does the LCD display show?

The LCD displays the remaining battery capacity as a percentage or level.

How do I turn on the power bank?

Press the ON button. It also turns on automatically when a device is connected for charging.

Does this power bank support fast charging (PD)?

Yes, via the USB-C output. It supports Power Delivery (PD) but requires a compatible PD cable (not included).

How long does it take to fully charge the power bank?

Approximately 4 hours using a 5V/3A adapter (input rate). Actual time may vary.

What safety precautions should I take?

Do not drop, disassemble, immerse in water, or expose to heat. Keep away from children. Charge every 3 months to maintain battery life.

How do I maintain the battery?

Fully charge the power bank every three months to prevent capacity loss. Avoid complete discharge.

What is the warranty period?

The product is warranted for 2 years from the date of purchase against material defects and workmanship.

How should I dispose of the product?

Do not dispose as household waste. Take it to a designated collection point for recycling of electrical and electronic equipment.

USER MANUAL PB100008R GoGen

Abstract logo design with a stylized white 'S' inside a circle on black background (no text or symbols)

GoGEN

PB 100008 B

PB 100008 R

Black power bank with digital display showing 100Ω, ports, and charging button (no text or symbols on body)

NEBEZPEČÍ UDUŠENÍ. PE SÁČEK ODKLÁ-DEJTE MIMO DOSAH DĚTÍ. SÁČEK NENÍ NA HRANÍ. NEPOUŽÍVEJTE TENTO SÁČEK V KOLÉBKÁCH, POSTÝLKÁCH, KOČÁRCÍCH NEBO DĚTSKÝCH OHRÁDKÁCH.

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid black rectangle below (no text or labels)

NEBEZPEČENSTVO UDUSENIA. PE VRECKO ODKLADAJTE MIMO DOSAHU DETÍ. VRECKO NIE JE NA HRANIE. NEPOUŽÍVAJTE TOTO VRECÚŠKO V KOLÍSKACH, POSTIEL'KACH, KOČÍKOCH ALEBO DETSKÝCH OHRÁDKACH.

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

Thank you for purchasing our product. For optimum performance and safety, please read these instructions carefully before operating the product. Please keep this manual for future reference.

PACKAGE CONTENT

Powerbank, USB-C cabel, instruction manual

DEVICE LAYOUT

1. LCD display power indicator
2. USB 1 output
3. Micro USB input
4. USB 2 output
5. USB-C input/output
6. ON button

CHARGING INSTRUCTION

The power bank will auto power on when connected and turn off automatically 20 seconds after disconnecting. Press the power button to turn the product on.

Charging of mobile devices

Connect the charging cable to the USB output or the USB-C output on the device and the mobile device. Charging starts automatically.

Please use compatible charging cable (not included) for using PD (Power Delivery) function.

Charging the power bank

Connect the backup power supply using a charging cable to a power supply with a minimum charging current of 5V / 2A. Micro USB or USB-C input on the device can be used.

Capacity Indication

Press the main button to show the remaining capacity.

ATTENTION

This device has safety protection that prevent the battery from damages when overcharging. It is normal for the casing to become warm during charging and it will gradually cool down to room temperature after fully charged.

Please make a complete charge every three month to avoid shorten the mobile power life span.

TECHNICAL SPECIFICATION

Battery type: Li-pol Battery

Capacity: 10 000 mAh

Input: Micro USB / USB-C DC 5 V / 3 A, 9 V / 2 A, 12 V / 1,5 A

Output: USB-C DC 5 V / 3 A,9 V 2,22 A, 12 V / 1,66 A

USB 1/2 DC 4,5V / 5A, 5V / 4,5A, 5V / 3A,

9 V / 2 A, 12 V / 1,5 A

Dimension: 145,3 x 66 x 14,6 mm

Weight: 245 g

CAUTION

• Please completely full charge the mobile power in first usage.
• Please make sure that use standard cable with appropriate specification, or it may lead to the mobile power damage.
• Please confirm the voltage of the electric device is 5V before charging it.
• Do not drop, knock, disassemble or attempt to repair the mobile power by yourself.
• Do not immerse or put the mobile power in water or damp place.
• Do not expose or put the mobile power near to heat sources or flammable place.
• Do not put the mobile power in car, for strong light and high temperature will lead to product damage.
• Keep the mobile power away from children.
• Do not put any item into the mobile power USB input and output ports to avoid any shortcut or damage.

• Please make a complete charge every three month to avoid shorten the mobile power life span.

• This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safety. Young children should be supervised to ensure that they do not play with the appliance.

• Never charge the battery unattended.

WARRANTY

Our product is warranted for 2 full year from the date of purchase. The warranty is provided on all material defects and workmanship. Guarantee of 24 months does not apply to decrease in the accumulator's effective capacity caused by its use or age. Effective capacity gradually decreases depending on the method of use of the accumulator.

WE RESERVE THE RIGHT TO CHANGE TECHNICAL SPECIFICATIONS.

Prohibition sign with a circular border and a stylized face inside (no text or symbols)

Prohibition sign with a crossed-out dog silhouette (no text or symbols)

TO AVOID DANGER OF SUFFOCATION, KEEP THE PLASTIC BAG AWAY FROM BABIES AND CHILDREN. DO NOT USE THIS BAG IN CRIBS, BEDS, CARRIAGES OR PLAYPENS. THIS BAG IS NOT A TOY.

Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Symbol of a trash bin crossed with no text or numbers, representing environmental restriction (no text present)

FULLADÁSVESZÉLY. TARTSA A PE ZACSKÓT GYERMEKEKTÓL ELZÁRT HELYEN. A ZACSKÓ NEM JÁTÉKSZER. NE HASZNÁLJA EZT A ZACSKÓT BÖLCSÖKBEN, KISÁGYAKBAN, BABAKOCSIKBAN, VAGY GYEREK

JÁRÓKÁKBAN.

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid black rectangle below (no text or labels)
