ND18D2PL - Fireplace Cotech - Free user manual and instructions

Product Type	Decorative Wood Stove Heater (Fan Heater)
Brand	Cotech
Model	ND18D2PL
Color	Black
Rated Voltage	230 V AC, 50 Hz
Power Consumption	900 W / 1800 W (two heat settings)
Dimensions (W × D × H)	41 × 28 × 54 cm
Weight	6.9 kg
Heat Output (Nominal)	1.8 kW
Heat Output (Minimum)	0.9 kW
Decorative Flame Effect	Yes, with adjustable intensity knob
Thermostat Control	Yes, mechanical thermostat with adjustable temperature
Fan Only Mode	Yes (no heat)
Control Panel Cover	Yes
Safety Features	Do not cover; keep at least 15 cm clearance; automatic shut-off when overheating? ( Not explicitly stated but implied by thermostat)
Indoor Use Only	Yes
Suitable for Well-Insulated Spaces	Yes, or occasional use
Cleaning	Wipe with damp cloth; vacuum air vents regularly
Standby Power Consumption	0 W
Seasonal Space Heating Energy Efficiency	36%
Accessories Included	None specified (standard mains lead)

Frequently Asked Questions - ND18D2PL Cotech

How do I turn on the heat?

First press the fan button [∅] to start the fan, then press [900 W] to activate the 900 W heat setting. To increase to 1800 W, press the second 900 W button. The fan must be on for heating to work.

Does the flame effect work without heat?

Yes, you can use the decorative flame effect independently of the heater by pressing the decorative light effect button [♦] and adjusting the intensity with the knob []. The fan and heat can be off.

How do I set the thermostat?

Turn the thermostat knob to the maximum setting, wait until the room reaches desired temperature, then turn the knob back until the stove switches off. It will automatically turn on again when the temperature drops.

Can I use this fireplace in a bathroom?

No, this product is for indoor use only and should not be used in bathrooms, shower rooms, or near pools. Keep it away from water and moisture.

How much clearance is needed around the heater?

Always allow at least 15 cm of free space on all sides for adequate air circulation. Never place it directly under a wall socket.

Can I leave the heater unattended?

No, never leave the product unattended while switched on. Always turn it off if you leave the room, even for a short time.

How do I clean the fireplace?

Switch off, unplug, and let it cool completely. Wipe with a soft damp cloth using mild cleaning agents. Regularly vacuum the air inlet and outlet at the bottom.

What should I do if the mains lead is damaged?

Do not use the product. If the lead or plug is damaged, it must be replaced by the manufacturer, its service agent, or a similarly qualified person to avoid hazard.

Is the fireplace suitable for continuous use?

It is designed for well-insulated spaces or occasional use. In very cold weather or rapid temperature changes, the capacity may be insufficient.

How should I dispose of the product at the end of its life?

Do not dispose with household waste. Take it to a local collection facility or contact the place of purchase for environmentally safe recycling, in accordance with EU regulations.

USER MANUAL ND18D2PL Cotech

Decorative Wood Stove Heater

This product is only suitable for well insulated spaces or occasional use.

Read the entire instruction manual carefully and make sure that you fully understand it before you use the equipment. Keep the manual for future reference.

Viktig information:

Original instructions

Bruksanvisning i original

Originalbruksanvisning

Decorative Wood Stove Heater

Art.no 18-1362 Model ND18D2PL 36-6036 ND18D2PL

Please read the entire instruction manual before using the product and then save it for future reference. We reserve the right for any errors in text or images and any necessary changes made to technical data. In the event of technical problems or other queries, please contact our Customer Services (see address details on the back).

Safety

• The product should only be connected to a 230 V AC, 50 Hz electrical outlet.
• Never leave the product unattended whilst it is switched on.
• If you have to leave the product unattended, even for a short while, always switch it off.
• Keep the product out of children's reach and do not allow children to use it.
• The product is only intended for normal domestic use and only in the manner described in this instruction manual.
• Inspect the mains lead regularly. Never use the product if the mains lead or plug has been damaged in any way.
• Do not place the mains lead on or near any hot surface.
• Never cover the product.
• Position the product so that there is always at least 15 cm of free space on all sides to ensure adequate air circulation. Never immerse the product in water or any other liquid. Do not use the product in a bathroom, shower room or close to a pool.
• The product is intended for indoor use only.
• Do not touch the product if your hands are moist or wet.
• Do not use the product on or near hot surfaces.
• Never move the product by pulling on the lead.
• Only use accessories that are recommended by the manufacturer or retailer. The use of other accessories can lead to a risk of injury to people and animals or damage to the product.
• Never place the product directly under a wall socket.

Buttons and functions

1. Decorative effect
2. Control panel cover
3. Fan Heater
4. [☀] Thermostat
5. [ ] Fan (no heat)
6. [900 W] Heat setting
7. [900 W] Heat setting
8. [◀] Decorative light effect on/off
9. [\~] Decorative light effect setting knob

Operating instructions

1. Position and connect the stove in accordance with the instructions in the Safety section above.
2. Switch the fan on by pressing [∅].
3. Press [900 W] (6) to switch on the 900 W heat setting.

Note: The fan must be switched on in order for the heating element to come on.

1. Press [900 W] (7) to increase the heat setting to 1800 W (900 W+900 W).
2. Press [♦] to switch the decorative light effect on.
3. Turn the [💡] knob to adjust the intensity of the decorative light effect.

Thermostat

1. Switch the stove on as directed above.
2. Turn the thermostat knob (1) to the maximum setting.
3. Wait until the room has reached the desired temperature.
4. Turn the knob back the other way until the stove switches off.
5. The stove will now switch on again when the room temperature drops.

Note: Bear in mind that the room temperature can be affected by many factors.

The capacity of the stove may be insufficient in very cold weather or if the temperature changes rapidly.

Care and maintenance

• Switch the stove off, unplug it from the electrical outlet and let it cool completely before cleaning.
• Wipe the stove clean with a soft damp cloth. Use only mild cleaning agents, never solvents or corrosive chemicals.
  • Vacuum clean the bottom (the air inlet and outlet of the fan) at regular intervals.

Responsible disposal

This symbol indicates that this product should not be disposed of with general household waste. This applies throughout the entire EU. In order to prevent any harm to the environment or health hazards caused by incorrect waste disposal, the product must be handed in for recycling so that the material can be disposed of in a responsible manner. When recycling your product, take it to your local collection facility or contact the place of purchase. They will ensure that the product is disposed of in an environmentally sound manner.

Specifications

Rated voltage 230 V AC, 50 Hz

Power 900/1800 W

Size 41 × 28 × 54 cm

Weight 6.9 kg

Information requirement for the electric local space heaters

Model identifier(s): ND18D2PL
Item Symbol Value Unit	Item Unit
Heat output Type of heat input, for electric storage				local space heaters only (select one)
Nominal heat output P	nom	1.8 kW		manual heat charge control, with integrated thermostat	No
Minimum heat output (indicative)	Pmin	0.9 kW		manual heat charge control with room and/or outdoor temperature feedback	No
Maximum continuous heat output	Pmax,c	1.8 kW		electronic heat charge control with room and/or outdoor temperature feedback	No
Auxiliary electricity consumption	---	--- ---	fan assisted heat output No
At nominal heat output	eImax	0.0 kW		Type of heat output/room temperature control (select one)
At minimum heat output	eImin	0.0 kW		single stage heat output and no room temperature control	No
In standby mode el	SB	0.0 kW		Two or more manual stages, no room temperature control	No
				with mechanic thermostat room temperature control	Yes
				with electronic room temperature control	No
				electronic room temperature control plus day timer	No
				electronic room temperature control plus week timer	No
				Other control options (multiple selections possible)
				room temperature control, with presence detection	No
				room temperature control, with open window detection	No
				with distance control option No
				with adaptive start control No
				with working time limitation	No
				with black bulb sensor	No
Contact details	CLAS OHLSON AB, SE-793 85 INSJÖN, SWEDEN

Test Data

Commission Regulation (EC) No 1275/2008 Requirement

Mode Ecodesign	requirements, from 7 January 2013 Result - Remark Verdict
Off mode Power	consumption in ‘off mode’:Power consumption of equipment in any off-mode condition shall not exceed 0.50 W	0 W P
Standby mode P	Power consumption in ‘standby mode(s)’:The power consumption of equipment in any condition providing only a reactivation function, or providing only a reactivation function and a mere indication of enabled reactivation function, shall not exceed 0.50 W.		N/A
	The power consumption of equipment in any condition providing only information or status display, or providing only a combination of reactivation function and information or status display shall not exceed 1.00 W.		N/A

Seasonal space heating energy efficiency

Description Value
Seasonal space heating energy efficiency in active mode- ηS,on	40 %
For electric local space heaters- ηth	100 %
The electric to primary energy ‘conversion coefficient-CC 2.5
F(1) is a correction factor accounting for a positive contribution to the seasonal space heating energy efficiency of electric storage local space heaters due to adjusted contributions for options for heat storage and output; and a negative contribution to seasonal space heating efficiency for commercial local space heaters due to adjusted contributions for options for the heat output, expressed in %;	0.0 %
F(2) is a correction factor accounting for a positive contribution to the seasonal space heating energy efficiency due to adjusted contributions of controls of indoor heating comfort, the values of which are mutually exclusive, cannot be added to each other, expressed in %;	6.0 %
F(3) is a correction factor accounting for a positive contribution to the seasonal space heating energy efficiency due to adjusted contributions of controls for indoor heating comfort the values of which can be added to each other, expressed in %;	0.0 %
F(4) is a correction factor accounting for a negative contribution to the seasonal space heating energy efficiency by auxiliary electricity consumption, expressed in %;	0.0 %
F(5) is a correction factor accounting for a negative contribution to the seasonal space heating energy efficiency by energy consumption of a permanent pilot flame, expressed in %.	0.0 %
Seasonal space heating energy efficiency- ηS	36.00%
Verdict P

Dekorationskamin

Art.nr 18-1362

36-6036

Modell

ND18D2PL

ND18D2PL

Användning

Specifikationer

Bruk

Spesifikasjoner

Spenning 230 V AC, 50 Hz

Effekt 900/1800 W

Mål 41 × 28 × 54 cm

Vekt 6,9 kg

Käyttö

Tekniset tiedot

Benutzung

Technische Daten
