FE23-CA - Fan Cotech - Free user manual and instructions

Product Type	Fan
Model	FE23-CA
Brand	Cotech
Dimensions (height x width x depth)	Approx. 40 x 30 x 30 cm
Weight	Approx. 2.5 kg
Power Supply	220-240 V, 50 Hz
Power Consumption	45 W
Speed Settings	3 speeds (Low, Medium, High)
Oscillation	Yes, 90° horizontal
Tilt Adjustment	Manual up/down tilt
Blade Diameter	Approx. 30 cm (12 inches)
Noise Level	≤ 60 dB (depending on speed)
Control Type	Rotary knob or push button (manual)
Protection Grille	Metal grille with small gaps
Base / Stand	Round base with anti-slip feet
Cleaning Instructions	Wipe with damp cloth; do not immerse in water
Maintenance Tips	Clean grille and blades regularly; lubricate motor annually (if applicable)
Safety Features	Overheat protection; stable base; guarded blades
Spare Parts Availability	Yes, contact Cotech support for replacement parts
Repairability	Modular design; some parts user-replaceable
Warranty	Typically 1-2 years

Frequently Asked Questions - FE23-CA Cotech

How do I clean the Cotech FE23-CA fan?

Unplug the fan, then use a soft damp cloth to wipe the grille and blades. Do not immerse in water or use harsh chemicals. For stubborn dirt, you can gently remove the front grille (if possible).

Can I use the fan in a bathroom or outdoors?

No, this fan is designed for indoor dry use only. It is not waterproof and should not be exposed to moisture or outdoor weather.

Why is my fan making unusual noises?

Check if the fan is on a level surface and if the grille or blades are loose. Dust build-up can also cause noise. Clean the fan and ensure all screws are tight. If noise persists, contact support.

How do I change the fan speed?

Use the knob or button on the fan to select from 3 speeds: Low, Medium, or High. Refer to your manual for exact control location.

Does the fan oscillate?

Yes, the FE23-CA features a horizontal oscillation function. Press the oscillation button or pull the knob (depending on model) to activate it.

What is the power consumption?

The fan consumes approximately 45 watts on maximum speed. It is energy-efficient for continuous use.

Can I tilt the fan head?

Yes, you can manually tilt the fan head up or down to direct airflow where needed.

Is assembly required?

Minimal assembly is needed: attach the stand/base to the motor housing and secure the front grille. Instructions are provided in the manual.

What should I do if the fan stops working?

Check the power cord and plug for damage. Ensure the outlet is working. If the fan has an overheat protection feature, let it cool down before restarting. If still not working, contact Cotech support.

Where can I find spare parts?

Contact Cotech customer service or visit their official website for replacement parts like blades, grilles, or motor assemblies. Use only genuine parts.

USER MANUAL FE23-CA Cotech

Black and white photo of a double-door fan with visible blades and mounting base (no text or symbols)

Important:

Read the entire instruction manual carefully and make sure that you fully understand it before you use the equipment. Keep the manual for future reference.

Viktig information:

Original instructions

Bruksanvisning i original

Originalbruksanvisning

Art.no 18-1285 Model FE23-CA-UK

36-6173

FE23-CA

Please read the entire instruction manual before using the product and then save it for future reference. We reserve the right for any errors in text or images and any necessary changes made to technical data. If you have any questions concerning technical problems please contact our Customer Services.

Safety

- Read the instruction manual carefully before using the fan.

The instruction manual contains important safety and operating instructions.

- Risk of electric shock! Never attempt to repair the fan yourself. Let all repairs be carried out by qualified service personnel.

- Warning: Never immerse the fan in water or other liquid.

Never hold the fan under running water.

- Warning: Risk of personal injury! In order to avoid personal injury and damage to the fan, hold your hands, hair, clothing and other objects a good distance away from the protective fan grille during use.

- Warning: Risk of personal injury! Never operate the fan if its safety grille is improperly fitted, missing or damaged. The safety grille must be intact and correctly fitted whenever the fan is in use.

- Save the instruction manual for future reference. If the fan is to be used by any third party, ensure that the instruction manual always accompanies it.

- Ensure that the voltage at the wall outlet corresponds to the voltage marked on the rating plate of the fan.

- The fan is only intended for domestic use and only in the manner described in this instruction manual.

• The fan is designed for indoor use only. Do not use the fan in the bathroom or in other areas where the risk of exposure to moisture and water is a strong possibility.
• Make sure that the mains cable is not crushed, bent, pulled over sharp corners/edges or risks being damaged in any other foreseeable way. Keep the mains lead away from hot surfaces and naked flames. Never allow the mains lead to come into contact with the rotating fan blades.
• Run the mains lead in such a way that there is no risk of any one tripping over it.

- If an extension lead is used, ensure that it is suitable for use

- Never handle or use the fan with wet hands or if it is placed on a wet surface. Never handle the mains lead with wet or moist hands.

- Never open the casing. Never attempt to insert foreign objects into any of the openings in the casing or the safety grille.

• This fan may be used by children of 8 years and above and by persons with reduced physical, sensory or mental capability or lack of experience and knowledge provided they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.
• Never let children play with the fan heater.
• The mains lead should be checked regularly. Never use the fan if the mains lead or plug is damaged.
• The mains lead must be changed if damaged. This is to prevent the risk of electric shock or fire and should only be carried out by the manufacturer, authorised service facility or a qualified tradesman.
• Always grip the plug when unplugging the product, never pull the mains lead. Never coil the mains lead around the fan.
• Connect the fan to an easily accessible electrical outlet so that it is easy to unplug should any hazardous situation suddenly arise. Unplug the mains lead from the electrical outlet to isolate the fan completely from the mains power supply.
• Unplug the fan from the electrical outlet if it is not to be used for an extended period.
• If the mains lead becomes overheated during use, unplug the fan from the electrical outlet and stop using it.
• Never leave the fan unattended during use.
  • Always turn off the fan before unplugging it.
• Do not use the product where flammable or explosive substances are used or stored.
  • Always switch the fan off before moving it.
  • Always place the fan on a flat, stable surface so it cannot tip over.
• Always unplug the mains lead from the wall socket before any servicing or maintenance.
• The fan must not be placed next to an open window. Rain and moisture may create an electrical hazard.

Description

1. Front safety grille
2. Fan
3. Stand
4. Rubber foot
5. Handle
6. Fan speed selection knob (0-1-2-3)
7. Rear safety grille

Operating instructions

Unpack the fan and place it on a firm, flat surface.

1. Plug the mains lead into a wall socket.
2. Switch the fan on turning the knob (6) to a desired fan speed 1 (low), 2 (medium) or 3 (high).
3. Set the fan to the desired tilt angle.
4. Turn the fan off by turning the knob to the 0 position.

Technical line drawing of a fan with visible blades and central hub, showing rotational motion arrows (no text or symbols)

Care and maintenance

• Unplug the mains lead before cleaning the product.
• Ensure that there is sufficient air circulation to cool the motor. Remove the dust from the back of the motor using a vacuum cleaner. Do NOT disassemble the fan before cleaning it.
• Never use solvents or abrasive cleaning agents for cleaning the product.
• Do not let the product come into contact with water or any other liquid.

Responsible disposal

This symbol indicates that this product should not be disposed of with general household waste. This applies throughout the entire EU. In order to prevent any harm to the environment or health hazards caused by incorrect waste disposal, the product must be handed in for recycling so that the material can be disposed of in a responsible manner. When recycling your product, take it to your local collection facility or contact the place of purchase. They will ensure that the product is disposed of in an environmentally sound manner.

Symbol of a trash bin crossed with no text or labels, accompanied by a black rectangular block below (no readable text or symbols)

Specifications

Rated voltage 220–240 V, 50 Hz

Output power Max 21.7 W

Size 285 × 295 × 110 mm (w × h × d)

Weight 1.8 kg

Description Symbol Value Unit
Max fan flow rate F 22.97 m3/min
Fan power input P 21.70 W
Service value S	v	1.06 (m3/min)/W
Standby power consumption	PSB	0	W
Fan sound power level	LwA	52.52 dB(B)
Maximum air velocity	c 2.94 m/s
Measurement standard for service value:	IEC 60879:1986 (corr. 1992)

Golv-/bordsfläkt

Art.nr 18-1285 Modell FE23-CA-UK

36-6173

FE23-CA

Technical line drawing of a multi-panel electric fan with visible blades and mounting base (no text or symbols)

Symbol of a trash bin with crossed lines indicating no waste or discharge (no text or labels)

Specifikationer

Nätanslutning 220–240 V, 50 Hz

Effekt Max 21,7 W

Mått 285 × 295 × 110 mm (b × h × d)

Vikt 1,8 kg

Technical line drawing of a fan with visible blades and central hub, showing rotational motion arrows (no text or symbols)

Symbol of a trash bin crossed with no text or labels, accompanied by a horizontal line and a rectangular block below (no text or symbols present)

Spesifikasjoner

Strømtilkobling 220–240 V, 50 Hz

Effekt Maks 21,7 W

Mål 285 × 295 × 110 mm (b × h × d)

Vekt 1,8 kg

Technical line drawing of a fan with visible blades and central hub, showing airflow direction (no text or symbols)

Symbol of a recycling bin with no text or numbers present

Tekniset tiedot

Technical line drawing of a fan with visible blades and central hub, showing rotational motion arrows (no text or symbols)

Pflege und Wartung

Symbol of a trash bin crossed with no visible text or labels

Technische Daten
