MMU-04 - Uncategorized MPM - Free user manual and instructions

Product Type	Lint shaver / Fabric trimmer
Model	MMU-04
Brand	MPM
Power Supply	3 V DC (2 x 1.5 V LR6/AA batteries, not included)
Power Consumption	3 W
Noise Level	LWA = 63 dB
Intended Use	Removing lint, pills, and knots from clothing fabrics
Compatible Fabrics	All kinds of fabric (delicate fabrics use protective cover)
Cutting Mechanism	Rotating blades under a protective screen
Lint Collection	Removable transparent chamber (lint bin)
Operating Temperature	0–40°C
Storage	Cool, dry place, out of direct sunlight
Dimensions (approx.)	15 x 5 x 5 cm (estimated)
Weight (without batteries)	Approx. 150 g (estimated)
Color	Blue and white (as pictured)
Accessories Included	Protective cover, cleaning brush
Battery Type	2 x AA (LR6) 1.5 V
Safety Features	Sharp blade warning; do not use near water; keep away from children under 8
Cleaning	Clean blades with brush; wipe exterior with cloth; do not immerse in water
Maintenance	Empty lint bin regularly; replace batteries if motor slows
Disposal	Do not dispose with household waste; take to WEEE collection point
Manufacturer	MPM agd S.A.

Frequently Asked Questions - MMU-04 MPM

What type of batteries does the MMU-04 require?

The MMU-04 requires two 1.5V AA (LR6) batteries, which are not included in the package.

Can I use the lint shaver on delicate fabrics?

Yes, but for gentle textiles, attach the protective cover provided. This reduces the cutting surface and prevents damage.

How do I clean the lint shaver?

Unplug or remove batteries. Use the included brush to clean the blades. Wipe the exterior with a damp cloth. Do not immerse in water.

What should I do if the motor slows down or stops?

First, empty the lint bin (chamber). If the problem persists, replace the batteries with new ones.

Is the MMU-04 safe to use on clothes I am wearing?

No, always remove the garment before using the trimmer to avoid injury or damage to the appliance.

How often should I empty the lint bin?

Empty the lint bin regularly, especially when you notice reduced performance or the motor slowing down.

Can children use this device?

Children under 8 years old should not use it. Older children and persons with reduced capabilities need supervision and instruction.

What fabrics can the trimmer be used on?

It is suitable for all kinds of fabric, but avoid buttons, zippers, patches, and seams.

How do I replace the batteries?

Slide off the battery compartment cover (on the handle), insert two AA batteries with correct polarity, and close the cover.

What should I do if the blades become dull?

The blades are not user-replaceable. If they become dull, contact authorized service or consider replacing the unit.

USER MANUAL MMU-04 MPM

Illustration of a handheld hairdryer with blue and white casing (no text or symbols visible)

PRAWIDŁOWE USUWANIE PRODUKTU

Read carefully this manual before using the appliance.

This appliance must never be used near water!

Do not immerse the appliance in water or any other liquids!

- Close supervision is necessary when using the appliance near children.

Do not use the appliance in case of its damage, in such case the appliance should be handed over to an authorized service shop for repair.

To avoid the risk of damage or injury, always use the attachments recommended by the manufacturer.

Do not leave the operating appliance unattended!

Do not place the appliance on hot surfaces.

This appliance has been designed for domestic use only.

Do not use the appliance outdoors.

Do not use the appliance for the purposes different than it was designed for.

This appliance is not intended for use by children under 8 years of age and individuals with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be carried out by children without supervision.

Children should be supervised to ensure that they do not play with the appliance.
- Store the appliance out of reach of children under 8 years of age.
Make sure the device is protected from moisture. Use it on dry materials only.
Structural and very delicate materials, such as mo hair, may be damaged during the use of trimmer. Therefore, before the normal use of trimmer it is advisable first to check the effect on a less visible part of the garment, e.g. on the inner side.
Do not use the trimmer on the clothes you are wearing, always take them off. This may cause injury or damage to the trimmer.
Do not use the trimmer on buttons, zips, patches, labels, abrasions, seams, imprints, stickers, etc.

Note! Do not use the trimmer for shaving hair or beard - risk of injury.

Do not expose to direct sunlight. The appliance shall be stored in a cool, dry place, at a temperature 0-40°C. After use, put it in a dry place.

In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

WARNING! Do not allow small children to play with the foil as there is a danger of suffocation!

WARNING!: The cutting blades are very sharp, avoid touching them while emptying or cleaning the appliance - it may result in serious injury.

DESCRIPTION OF THE APPLIANCE

1. Container for trimming residues - chamber.
2. Blades cover - trimming head

3. Lid of the chamber for trimming residues

4. Trimming blades

5. Battery cover
6. Body of the appliance
7. On/Off switch
8. Brush

●The trimmer is designed for cutting hair and knots on clothing. Smoothes the fabric and removes lint.

● Suitable for all kinds of fabric.
● The clothes must be spread evenly on a flat horizontal surface.
- Do not press down the trimmer on the clothes when removing the knots - slide it gently over the fabric!

BEFORE FIRST USE

1. Unpack the lint shaver from the cardboard box. Remove all plastic bags and filling materials.
2. Remove the battery compartment cover ⑥ and install two 1.5V LR6 (AA) batteries. Follow the proper polarity marks. Close the battery compartment cover ⑥.

CAUTION! The batteries are not included with MMU-04.

1. Make sure that the lint shaver is properly assembled and the lint bin ① is empty.

USING THE TRIMMER

1. Remove the head protective cover ③.
2. Start the appliance using the switch ⑦. After switching on, the blades of the trimming head start to operate. When the head touches the surface, the sound of the trimmer changes. This is not unusual.
3. Operate the lint shaver by sweeping the cutting head screen in contact with the fabric. Do not press the lint shaver against the fabric. The lint shaver's cutting head will cut off the lint and force it into the lint bin ①. If you need to shave lint from gentle textiles, use the protective cover ③ with the cutting head ②. However, it will reduce the cutting surface of the cutting head ②.
4. The chamber ① must be regularly emptied. If the engine slows down or stops completely, this could mean that the chamber for trimming residues is full or replace the batteries.
5. After you have finished using the appliance, turn it off using the switch ⑦ and place the head protective cover ③.

NOTE! The trimming blades are very sharp. To avoid injury, use caution when removing the head and blades.

CLEANING AND MAINTENANCE

The trimmer does not require any special maintenance. Simply follow the instructions for use below:

● To ensure proper operation, the appliance should be kept clean.
- From time to time - depending on the degree of cleanliness of the blade ② - it is advisable to clean it with the brush ⑨. To do this, first unscrew the blade cover - trimming head ②, then clean the blade ② thoroughly. When finished, carefully screw the blade cover ② back in place.
●Use cloth for cleaning the external surfaces of the appliance. Do not immerse the appliance in water or any other liquids!
●Empty the lint bin ① contents into a trash bin. Remove the lint bin by grasping its both sides and pulling away until the locks let go. To reinstall the lint bin, slide it into the handle towards the cutting head.

• If the device is not going to be used for a prolonged period, please remove the batteries from the device in order to prevent the leaking of battery acid.
  ●Different battery types or new and used batteries must not be used together.

WARNING! Do not dispose of batteries in the domestic waste. Please return used batteries to the relevant collection points or the shop where they were bought. Never throw batteries into a fire.

TECHNICAL DATA

Power supply: 3 V

Power: 3 W

Noise level: LWA = 63 dB

NOTE! MPM agd S.A. reserves its right to modify the technical data.

PROPER DISPOSAL OF THE PRODUCT

(waste electrical and electronic equipment)

This symbol on the product indicates that the product, after its lifetime, should not be disposed with other household wastes. To avoid harmful influence on the environment and human health due to uncontrolled waste disposal, dispose the waste device to the service point of waste household appliances or report collecting it from home. In order to obtain detailed information about the location and how to dispose the waste electrical and electronic equipment in a safe way, contact your retailer or local Department of Environmental Protection. Do not dispose the device with other municipal waste

We wish you satisfaction from using the product and invite you to check a wide range of other MPM appliances
