Product Type	LED Curtain Lights
Model Number	IAN 91572 (Z30171 / Z31589)
Indoor/Outdoor Use	Indoor and outdoor
Operating Voltage (Light Set)	24 V
Mains Adapter Input	230 V ~, 50 Hz
Mains Adapter Output	24 V, 3.6 W
Bulb Type	LED (non-replaceable)
Number of Small Lights	30 (20 mA each) for Z30171; 24 (20 mA each) for Z31589
Number of Large Lights	6 (5 LEDs each for Z30171; 6 LEDs each for Z31589)
Wire Configuration	6 parallel wires, each with 5 small lights and 1 large light, spaced ~16 cm apart
Protection Class (Light Set)	IP44
Safety Certifications	TÜV/GS (light set), ITS/GS (adapter)
Mounting Method	Suction cups (included)
Power On/Off	Plug/unplug mains adapter
Cleaning	Dry, lint-free cloth only; do not use water or liquids
Disposal	Recycle packaging; dispose of product at local recycling facility
Replaceable Parts	None (LEDs and cable non-replaceable)
Compatible Adapter	Model TH-P24036 only
Warranty Void if	Non-compliance with instructions, damage, or using other adapter
Intended Use	Private household decorative lighting

Frequently Asked Questions - IAN 91572 MELINERA

Can the LED bulbs be replaced if they burn out?

No, the LED bulbs are non-replaceable. If a bulb fails, the entire light set must be disposed of.

Is the light set suitable for outdoor use?

Yes, it is suitable for both indoor and outdoor use (IP44). However, the mains adapter should be protected from water.

What type of power adapter do I need?

Only use the supplied mains adapter TH-P24036. Using a different adapter voids the warranty and may be dangerous.

How do I install the curtain lights?

Mount the small lights onto the sockets, then use the included suction cups to hang the set. Connect the light plug to the adapter and screw the clamping nut. Finally, plug the adapter into the mains.

What should I do if some lights don't turn on?

The bulbs are connected in series; if one bulb is defective, all bulbs on that wire may go out. Check for loose bulbs or damage. Since bulbs are non-replaceable, the set may need replacement.

Can children use this product?

The product is not a toy. Children aged 8+ can use it under supervision. Cleaning and maintenance must be done by adults.

How do I clean the light set?

Unplug the adapter first. Use only a dry, lint-free cloth. Never use water or liquids to avoid electric shock.

What is the power consumption?

The mains adapter output is 24 V, 3.6 W. Input is 230 V~, 50 Hz.

How should I dispose of the product?

Dispose of the product at a local recycling facility. Do not dispose of it in household waste. Recycle the packaging.

Can the light set be connected to another set?

No, the string lights must not be electrically connected to another set of lights.

USER MANUAL IAN 91572 MELINERA

Operation and Safety Notes

RO

PErDEdLuMInOasă

CuLED-url

GB / CY Operation and Safety Notes Page 4

HR Upute za posluživanje i za Vašu sigurnost Stranica 10

Proper use....Page 5

Description of parts and features......Page 5

Technical data......Page 5

Safety Information......Page 6

Use Page 8

Cleaning and care......Page 9

Disposal Page 9

LED Curtain Lights

- Proper use

This product is suitable for use indoors and outdoors. This product is intended for use in private, domestic environment only and not for commercial purposes.

● Description of parts and features

1 Large light
2 Small light
3 Mains adapter
4 Suction cup

- Technical data

Light set:

Operating voltage: 24V

Bulbs for model Z30171:

30 x 3 V=20 mA (not replaceable), 6 x 5 LEDs in large light stars (not replaceable)

Bulbs for model Z31589:

24 x 3 V—, 20 mA (not replaceable), 6 x 6 LEDs in large light snowflake (not replaceable)

Protection class:

Light set (Model No. Z30171 / Z31589) TÜV / GS approved.

Mains adapter:

Nom. voltage input: 230 V \~, 50 Hz

Nom. voltage output: 24 V ——, 3.6 W

Protection class:

Mains adapter (Model No. TH-P24036) ITS / GS approved.

Safety Information

In the case of damage resulting from non-compliance with these operating instructions the guarantee claim becomes invalid! No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance with the safety instructions, no liability is accepted!

DANGKORDEATH AND

ACCIDENTS FOR TODDLERS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers. Please keep children away from the device at all times.

This device is not a toy and should not be played by children. Children are not able to understand the dangers that can occur when handling this device.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

■ Ensure that the product is installed by suitably experienced or qualified persons only.

CAUTION! RISK OF OVERHEATING! Do not operate the string lights inside the packaging.

■ After use, keep the string lights in the packaging to prevent unwanted damage.
- Do not pull the light chain cable and make sure it is laid down properly so that no one walks or trips over it.
The product can be used on all surfaces officially classified as being of "normal flammability".
■ Do not attach any other objects to the product.

Avoid the danger of death from electric shock!

Before use, ensure that the mains voltage available is the same as the required operating voltage for the device (230 V\~).
Before connecting the device to the mains you should always check the string lights and the mains lead for any damage.
■ Never use the light set if you discover that it is damaged in any way.
This light set's external flexible tube is non-replaceable. Hence if it becomes damaged you must dispose of the entire light set.
■ The LED lamps are not replaceable.
■ Use the light set only with a mains adapter type TH-P24036. Failure to observe this advice will invalidate any claims under the warranty.
■ Never open any of the electrical parts or insert any kind of object into them.
■ Protect the mains cable from sharp edges, mechanical loads and hot surfaces.

■ Do not install with sharp fasteners or nails.
■ Always unplug the mains adapter 3 from the socket before installation, dismantling or cleaning.
■ Never touch the light chain plug or the light chain itself with wet hands.
■ The string lights must not be electrically connected to another set of lights.

Use

Note: The light set has 6 parallel wires, each with five small lights 2 and one large light 1. The distance between the wires is approx. 16 cm.

□ Mount the small lights 2 on to the sockets of the bulbs.
☐ Use the supplied suction cups 4 to hang up the light set.
☐ Insert the plug on the end of the light set into the socket of the mains adapter 3. Secure the connection by pushing the clamping nut on the lead over the plug and screwing it on to the mains adapter.
☐ Insert the mains adapter 3 into the mains socket. The light set is now switched on.
☐ Pull the mains adapter ☐ out of the mains socket to switch off the light set.

Note: The bulbs are connected in series. If one bulb is defective, then all the bulbs of one wire may not light up.

- Cleaning and care

CAUTION! RISK OF ELECTRIC SHOCK! First remove the mains adapter 3 from the socket.

CAUTION! RISK OF ELECTRIC SHOCK! For reasons of electrical safety the device must never be cleaned with water or other liquids or immersed in water.

- Do not use any solvents, petrol or similar items. This would damage the device.

☐ Only a dry, lint-free cloth should be used for cleaning.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

EMC C€ IP44

Namjenska uporaba....Stranica 11

Светеща завеса

● Правилна употреба

- Απόσυρση

LED-Lichtervorhang

LEBAN SWINDJUNEALLGE-

OWIM GmbH & Co. KG

Stiftsbergstraße 1

D-74167 Neckarsulm

Model-No.: Z30171/Z31589

Version: 06/2013

Last Information Update · Stanje informacija

Ident.-No.: Z30171/Z31589052013-7

IAN91572
