KOV7002IX - Range hood Kluge - Free user manual and instructions

Product Type	Built-in range hood
Brand	Kluge
Model	KOV7002IX
EAN Code	5902429926846
Color	Stainless steel / Black
Width	675 mm
Depth	260 mm
Height (body)	285 mm
Duct Diameter	150 mm
Installation Type	Fully built-in (integrated)
Control Type	Electronic push buttons
Number of Speeds	3
Maximum Extraction Rate	600 m³/h
Noise Level (max speed)	65 dB(A)
Lighting	LED
Grease Filter	Aluminum mesh, washable
Charcoal Filter	Optional (for recirculation)
Energy Efficiency Class	A
Power Supply	220-240 V ~ 50 Hz
Net Weight	10 kg

Frequently Asked Questions - KOV7002IX Kluge

How do I install the Kluge KOV7002IX range hood?

Installation should be carried out by a qualified professional. Ensure the hood is securely mounted in a cabinet cutout with dimensions matching the product width (675 mm). Connect the ducting to the 150 mm outlet. Electrical connection must comply with local regulations. Refer to the manual for detailed steps.

How often should I clean the grease filters?

Clean the aluminum mesh grease filters every month for optimal performance. You can wash them by hand with warm soapy water or in a dishwasher at low temperature. Ensure they are completely dry before reinstalling.

Can this hood be used with a charcoal filter for recirculation?

Yes, the KOV7002IX can be used in recirculation mode with an optional charcoal filter. If you do not have an external duct, install the charcoal filter (purchased separately). Replace it every 3-6 months or when odor reduction decreases.

What are the dimensions of the KOV7002IX?

The hood body measures 675 mm in width, 260 mm in depth, and 285 mm in height. The duct outlet diameter is 150 mm. Always verify the actual dimensions before installation.

How do I change the LED light?

The LED light is integrated and should be replaced by a qualified technician. If the light fails, contact Kluge customer service or a certified electrician.

What should I do if the hood is not extracting effectively?

First, check that the grease filters are clean and properly installed. Ensure the ducting is not blocked or kinked. If using recirculation mode, verify the charcoal filter condition. Also, make sure the hood is on the correct speed setting.

Is the Kluge KOV7002IX suitable for use above an induction hob?

Yes, it is suitable. Maintain a minimum distance of 65 cm between the hob surface and the hood for electric/induction hobs, and 75 cm for gas hobs. Follow safety guidelines.

What is the noise level of this hood?

The noise level at maximum speed is approximately 65 dB(A), which is moderate. Lower speeds produce less noise.

Can I install the hood without a duct?

Yes, you can use it in recirculation mode. You will need to purchase a charcoal filter kit (not included). Ensure the hood is properly sealed to avoid air leaks.

Is there a warranty for the KOV7002IX?

Kluge typically offers a 2-year warranty for domestic use. Keep your purchase receipt and contact the retailer or Kluge customer support for warranty claims. The warranty covers manufacturing defects but not wear items like filters.

USER MANUAL KOV7002IX Kluge

Exterior view of a modern kitchen air conditioner unit with black and silver casing (no text or symbols visible)

ODSAVAČ PLNĚ VESTAVNÝ KOV7002IX

Výrobce: Kluge

Kód EAN: 5902429926846

Popis
