Product Type	Firestop Sealing Strip
Brand	Hilti
Model	CFS-T SST
Width	60 mm
Thickness	1 mm or 4 mm (depending on variant)
Length	720 mm
Material	HFE (fire-resistant elastomer)
Application	Diameter adjustment for CFS-T RR firestop plugs
Compatible Plugs	CFS-T RR 50, RR 70, RR 90, RR 100, RR 103, RR 125, RR 150, RR 154, RR 200
Diameter Increase per Strip (1 mm thick)	+2 mm (single layer), +4 mm (double layer), up to +16 mm (4 mm thick variant with 4 layers)
Installation Lubricant	Hilti CFS-T LUB
Safety Requirements	Read manual and safety data sheet before use; professional use only
Torque Requirement for Plugs	6 Nm (for RR 50-103), 6.5-8 Nm (for RR 125-200)
Professional Use Only	Yes
Packaging Quantity	1 strip per unit
Country of Origin	Designed and manufactured by Hilti (various locations)
User Manual Language	English (2 pages PDF)
Warranty	Refer to Hilti warranty policy

Frequently Asked Questions - CFS-T SST HILTI

What is the Hilti CFS-T SST used for?

The Hilti CFS-T SST is a firestop sealing strip used to adjust the diameter of CFS-T RR firestop plugs, ensuring a tight fit in cable penetrations.

How do I install the CFS-T SST strip?

Apply Hilti CFS-T LUB lubricant to the strip and wrap it around the plug or cable to achieve the desired diameter. Refer to the manual for detailed steps.

What lubricant is recommended?

Use only Hilti CFS-T LUB lubricant for installation to ensure proper adhesion and firestop performance.

What are the dimensions of the CFS-T SST?

The strip is 60 mm wide, 720 mm long, and available in 1 mm or 4 mm thickness.

Is the CFS-T SST reusable?

No, the strip is designed for single-use only. Once installed, it should not be removed or reused to maintain firestop integrity.

Can I use the CFS-T SST with non-Hilti plugs?

The strip is specifically designed for Hilti CFS-T RR plugs. Compatiblity with other brands is not guaranteed.

What temperature rating does the CFS-T SST have?

The strip is part of the Hilti CFS-T firestop system, which meets high-temperature fire resistance standards. Exact rating is in the product manual.

How many strips come in a pack?

Each package contains 1 strip of 720 mm length.

Where can I purchase the Hilti CFS-T SST?

It is available through Hilti official distributors and authorized retailers. Check the Hilti website for local contact.

Is the installation manual included?

Yes, a 2-page user manual in English is available for download. Read it before installation to ensure safety and compliance.

USER MANUAL CFS-T SST HILTI

Instructions for use

3D mechanical component diagram with a red arrow indicating direction, no visible text or symbols

Mechanical assembly diagram showing a rotating shaft with a flanged circular component and a red arrow indicating direction (no text or symbols)

Mechanical assembly diagram showing a tool interacting with a cylindrical component and a hand gesture (no text or symbols)

Mechanical assembly diagram showing a cylindrical component with two red arrows indicating motion or force directions (no text or symbols present)

Mechanical assembly diagram showing a shaft and housing with a red directional arrow indicating motion (no text or symbols)

Mechanical assembly diagram showing a rotating shaft and flange with a red arrow indicating motion direction (no text or symbols)

Mechanical assembly diagram showing a rotating component with a red arrow indicating direction (no text or symbols)

Mechanical assembly diagram showing a flanged circular component with two rods and bolt holes (no text or symbols)

Note: The Hilti instructions for use and the safety data sheet must be read before installation. The approval must be observed. For professional use only.

Dimensions of the CFS-T RR plug seal

Type Space avail.	Hole dia. (max. dia. using adapter/strip)			Dimensions in mm		Torque (T) Nm
	AxB cm	^2 D3 / ø mm	D1 D2
CFS-T RR 50 30x30		9	50 (66)	50	56	6
CFS-T RR 70	40x40	16	70 (86)	70	76	6
CFS-T RR-90	60x60	36	90 (106)	90	100	6
CFS-T RR 100	60x60	36	100 (116)	100	110	6
CFS-T RR-103	60x60	36	103 (119)	103	110	6
CFS-T RR 125	80x80	64	125 (141)	125	135	6,5 – 8
CFS-T RR 150	90x90	81	150 (166)	150	160	6,5 – 8
CFS-T RR-154	90x90	81	154 (170)	154	160	6,5 – 8
CFS-T RR 200	120x120	144	200 (216)	200	210	6,5 – 8

Adapters and strips for diameter adjustment

Type Description		thickness in mm	increase in dia in mm	Picture Non-Cut Plug (Cables not running)
Adapter CFS-T AS-100		1	+2
Adapter	CFS-T AS-125	1	+2
Adapter	CFS-T AS-150	1	+2
Adapter	CFS-T AS-200	1	+2

Sealing Strip	CFS-T SST60x1x720 HFE	1	1x1 mm = +22x1 mm = +4		ø +2mm < ø +4mm < ø +8mm < ø +16mm
Sealing Strip	CFS-T SST60x4x720 HFE	4 1x4 mm = +82x4 mm = +16
