MV-LDP - Uncategorized HILTI - Free user manual and instructions

Product Type	Laser Distance Meter
Brand	Hilti
Model	MV-LDP
Measurement Range	0.05 m to 100 m
Measurement Accuracy	±1.0 mm
Laser Class	Class 2 (630-670 nm, <1 mW)
Power Supply	2 x AAA batteries (1.5 V)
Battery Life	Up to 5,000 measurements
Display	Backlit LCD with 4 lines
Dimensions (H x W x D)	122 x 55 x 28 mm
Weight (including batteries)	0.2 kg
Ingress Protection	IP54 (dust and splash proof)
Operating Temperature	-10 °C to +50 °C
Storage Temperature	-20 °C to +70 °C
Measurement Functions	Distance, area, volume, continuous measurement, Pythagoras, stake-out
Memory	Last 20 measurements
Units	m, ft, in (selectable)
Auto-off	After 1 minute idle
Key Features	One-button operation, tilt sensor for indirect height measurement, Bluetooth connectivity
Included Accessories	Belt pouch, 2 x AAA batteries, quick-start guide
Maintenance	Clean lens with dry soft cloth; store in dry environment

Frequently Asked Questions - MV-LDP HILTI

How do I turn on the Hilti MV-LDP laser distance meter?

Press the ON/DIST button briefly. The laser will activate and the device is ready to measure.

What is the maximum measuring distance?

The maximum range is 100 m under favorable conditions (good target reflectivity, no strong ambient light).

How do I change the measurement unit?

Press and hold the UNIT button for 2 seconds to cycle through meters, feet, and inches.

Can I measure area or volume?

Yes, press the FUNC button to switch between distance, area, and volume modes. Follow the on-screen prompts.

What batteries does the MV-LDP require?

It uses two AAA 1.5V alkaline batteries. Open the battery compartment on the back and insert with correct polarity.

Why does the device show 'Error'?

An 'Error' message usually indicates the laser beam is interrupted, target too far or too reflective, or the device is outside operating temperature. Reposition and try again.

How do I clean the laser lens?

Use a soft, lint-free cloth slightly dampened with water or lens cleaner. Gently wipe the lens. Do not use abrasive materials.

Is the laser safe for eyes?

The device emits a Class 2 laser (≤1 mW). Do not stare directly into the beam. Avoid pointing at others' eyes.

How do I perform indirect height measurement?

Use the Pythagoras function: measure two sides of a right triangle, and the device calculates the third. The tilt sensor aids in angle measurement.

Where can I download the full user manual?

Visit notice-facile.com and search for 'Hilti MV-LDP' to download the manual in PDF format.

USER MANUAL MV-LDP HILTI

m = 311

3a1

3b
