| Product Type | Wireless Mobile Adapter |
| Brand | Nikon |
| Model | WU-1b |
| Compatible With | Nikon cameras with accessory terminal (e.g., D3200, D5200) |
| Wireless Standard | IEEE 802.11b/g/n |
| Frequency Band | 2.4 GHz |
| Maximum Range | Approx. 30 m (line of sight) |
| Data Transfer | Image transfer and remote camera control |
| Power Source | Powered by camera (no battery needed) |
| Dimensions (W x H x D) | Approx. 45 x 30 x 10 mm |
| Weight | Approx. 15 g |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -20 to 60 °C |
| Humidity | 85% or less (non-condensing) |
| Connector | Accessory terminal (proprietary) |
| Supported OS (for app) | Android, iOS |
| App Required | Wireless Mobile Utility (free) |
| Maintenance | Keep dry; clean with soft cloth; avoid dust |
| Safety Precautions | Follow camera's safety instructions; do not disassemble |
| Spare Parts / Repairability | Not available as spare part; non-repairable unit |
Frequently Asked Questions - WU-1b NIKON
Which Nikon cameras are compatible with the WU-1b?
The WU-1b is compatible with Nikon DSLRs that have an accessory terminal, such as the D3200, D5200, D5300, D3300, and similar models. Check your camera's manual or Nikon's website for a full list.
How do I connect the WU-1b to my smartphone?
Attach the WU-1b to your camera's accessory terminal, then turn on the camera. Download and open the Wireless Mobile Utility app on your smartphone. The app will guide you to connect to the adapter's Wi-Fi network.
Can I use the WU-1b to transfer videos?
Yes, the WU-1b supports transfer of both still images and MP4 movies (up to 720p) from the camera to your smartphone.
Does the WU-1b support remote control?
Yes, with the Wireless Mobile Utility app you can remotely trigger the shutter and adjust some camera settings (e.g., exposure compensation) from your smartphone.
What is the wireless range of the WU-1b?
The effective range is approximately 30 meters (about 100 feet) in open line-of-sight conditions. Obstacles like walls can reduce the range.
Does the WU-1b need its own battery?
No, the WU-1b is powered directly by the camera through the accessory terminal. It does not require any separate battery or charging.
Can I connect multiple smartphones to one WU-1b?
No, the WU-1b supports a single connection at a time. If you need to switch devices, disconnect the current one first.
Why can't my smartphone find the WU-1b network?
Ensure the WU-1b is properly attached to the camera and the camera is turned on. Check that your smartphone's Wi-Fi is enabled and that you are within range. Restart the app and the camera if necessary.
Can I use the WU-1b with a Nikon film camera?
No, the WU-1b is designed exclusively for digital Nikon cameras with an accessory terminal and does not work with film cameras.
Is the WU-1b water-resistant or waterproof?
No, the WU-1b is not water-resistant. Avoid using it in rain or humid conditions, and store it in a dry place when not in use.
