USER MANUAL SAD 3.7 G6 SILVERCREST

Operating instructions

FR BE

DIFFUSEUR DE BRUME À ULTRASONS

Mode d'emploi

ULTRAZVUKOVÝ AROMA DIFUZÉR

Návod k obsluze

ULTRAZVUKOVÝ AROMATICKÝ DIFUZÉR

Návod na obsluhu

AROMADIFFUSER MED ULTRALYD

GB/IE Operating instructions Page 1

Warnings and symbols used .... 2

Notes on trademarks 3

Safety ....

Basic safety instructions 3

Description of components .....7

Before use....7

Check package contents 7

Unpacking 7

Electrical connection 8

Handling and operation 8

Initial use 8

Switching the appliance on and off and the colour change function 8

Cleaning....9

Cleaning/descaling the appliance 9

Storage 9

Disposal....10

Disposal of the appliance....10

Disposal of the packaging 11

Technical specifications....1

Kompernass Handels GmbH warranty ..... 12

Service 14

Importer 14

Introduction

SILVERCREST SAD 3.7 G6 - Introduction - 1

Congratulations on the purchase of your new appliance.

You have selected a high-quality product. The operating instructions are part of this product. They contain impor-

tant information about safety, usage and disposal. Before using the product, please familiarise yourself with all operating and safety instructions. Use the product only as described and for the specified range of applications. Please also pass these operating instructions on to any future owner.

Intended Use

This appliance is intended only for domestic use and for the refreshing and humidification of air in enclosed spaces. This appliance is not intended for any other use or for uses beyond those mentioned here.

Claims of any kind resulting from damage caused by improper use, incompetent repairs, unauthorized modifications or the use of non-approved spare parts will not be acknowledged.

The operator alone bears liability.

Warnings and symbols used

The following warnings and symbols are used in these operating instructions, on the packaging and on the appliance (where applicable):

	DANGER! A warning with this symbol and the signal word "DANGER" indicates an imminently hazardous situation that will result in death or serious injury if not avoided.
	WARNING! A warning with this symbol and the signal word "WARNING" indicates a potentially hazardous situation that could result in death or serious injury if not avoided.
	CAUTION! A warning with this symbol and the signal word "CAUTION" indicates a potentially hazardous situation that could result in a minor or moderate injury if not avoided.
	ATTENTION! A warning with this symbol and the signal word "ATTENTION" indicates a potential situation that could result in property damage if not avoided.
	Note: A note identifies additional information that facilitates the use of the appliance.

SILVERCREST®

	Empty and refill the water tank every 3 days.
	Caution! Causes skin irritation.Can trigger allergic skin reactions.
	Read and observe the operating instructions!
	DC current/voltage.
	AC current/voltage.

Notes on trademarks

USB® is a registered trademark of USB Implementers Forum, Inc. All other names and products may be trademarks or registered trademarks of their respective owner.

Safety

In this chapter you will receive important safety information regarding the handling of the appliance. Incorrect usage can, however, lead to personal and property damage.

Basic safety instructions

For safe handling of the appliance observe the following safety information:

■ Check the appliance for visible external damage before use. Do not use an appliance that has been damaged or dropped.

■ This appliance may be used by children aged 8 years and above and by persons with limited physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use the appliance safely and are aware of the potential risks. Do not allow children to use the appliance as a toy.

■ Cleaning and user maintenance tasks may not be carried out by children unless they are supervised.

SILVERCREST®

■ DANGER! Do not allow children to play with the packaging material! Keep all packaging materials away from children. There is a risk of suffocation!
■ Connect the mains adapter only to correctly installed and earthed mains sockets. Ensure that the power supply corresponds with the information on the type plate of the appliance/mains adapter.
■ Make sure that the connection cable does not become wet or damp. Route the cable in such a way that it cannot get caught or damaged.
■ Do not use the appliance if the connection cable or power adapter is defective.
■ Do not make any unauthorised modifications or alterations to the appliance.
■ Do not operate the appliance near heat sources, such as radiators or other heat-generating appliances.

■ Do not expose the appliance to direct sunlight or high temperatures. Otherwise, it could overheat and be irreparably damaged.
- Keep the appliance away from open flames (e.g. candles) at all times.
■ Do not expose the appliance to water spray or dripping water, and do not place liquid-filled objects such as vases or open drink containers on or near the appliance.
■ Never immerse the appliance in water or other liquids!
■ Always set up the appliance on a stable and level surface. It can be damaged if dropped.
■ ⚠️ WARNING! Switch the appliance off immediately and disconnect the connected connection cable from the appliance if you smell fumes or notice any smoke. Have the appliance checked by a qualified specialist before using it again.

■ Only use the mains adapter in dry indoor areas.
■ Only use the appliance with the power adapter and connection cable supplied and only use the supplied power adapter and connection cable with the appliance.
Do not use the mains adapter if it has a damaged plug or cable.
■ The power adapter and connection cable may not be repaired. In the event of a defect, the part must be replaced with another of identical design.
■ No user action is required to set the product to 50 or 60 Hz. The product switches automatically to 50 or 60 Hz as required.
■ The power outlet used must be easily accessible at all times so that the mains adapter can be pulled out of the outlet quickly in a dangerous situation.

■ Disconnect the connection cable from the appliance every time before filling/emptying the water tank and before cleaning.
■ Note that high humidity can promote the growth of biological organisms in the environment.
■ Make sure that items in the vicinity of the appliance do not become damp or wet. If you notice damp formation, you need to reduce the output. If the output cannot be reduced, then you should only use the appliance periodically.

Do not allow absorbent materials such as carpeting, curtains, drapes, or tablecloths to become damp.

■ Make sure there is no water left in the water tank when the appliance is not in use.
■ Before storage, empty and clean the appliance. Clean the appliance before using it again.

SILVERCREST®

■ ⚠️ WARNING! Microorganisms that may be in the water or in the environment where the appliance is used or stored can multiply in the water tank and be blown into the air. This can lead to serious health risks if the water is not renewed and the water tank is not cleaned every 3 days.

■ The water tank must be emptied and refilled every 3 days.
■ Before filling, rinse out the water tank with fresh water. Any build-up, deposits, or layer of dirt that has formed on the surfaces of the water tank or the internal surfaces must be removed. All surfaces should be wiped dry.
■ Use the appliance only with essential oils (aromatic oils).
■ To prevent damage to the appliance, never use the appliance with undiluted aromatic oils.

■ Use only aromatic oils that comply with national health requirements. The use of other substances may result in poisoning or the risk of fire.
- Keep aromatic oils out of the reach of children.
■ Always store aromatic oils under lock and key.
■ Also note the warnings on the labels of the aromatic oils.

Description of components

(For illustrations see fold-out pages)

① Steam outlet
② Lid
③ Plug socket
4 Pouring direction arrow
5 Ceramic disc
6 Water tank
⑦ Maximum filling level
8 Ventilation slot
9 button
10 button
⑪ Mains adapter
12 USB connection cable
⑬ Measuring beaker
14 Scented oil

Before use

Check package contents

The appliance is supplied with the following components as standard:

Ultrasonic aromatherapy diffuser
Mains adapter
USB connection cable (USB type A to USB type C)
Measuring beaker
2 x 10 ml scented oil (green tea and lavender)
Operating Instructions

Unpacking

◆ Remove all parts of the appliance and these operating instructions from the box.
◆ Remove all packaging materials from the appliance.

(i) Note: Check the package for completeness and signs of visible damage.

If the delivery is incomplete or damage has occurred as a result of defective packaging or during transport, contact the service hotline (see the section Service).

Electrical connection

! ATTENTION!

(1) Before connecting the appliance, compare the specifications for the required input voltage on the rating plate with the intended voltage source for operation. This data must match to prevent damage to the appliance. (2) Make sure that the USB connection cable ⑫ and power adapter ⑪ are undamaged. (3) Ensure that the USB connection cable ⑫ is not laid over hot surfaces and/or sharp edges. (4) Ensure that the USB connection cable ⑫ is not stretched tightly or kinked. (5) Only use the supplied USB connection cable ⑫ and the supplied power adapter ⑪ to operate the appliance.

Connect the USB-A plug of the USB connection cable ⑫ to the plug socket of the power adapter ⑪.
Connect the USB-C plug of the USB connection cable 12 to the plug socket 3 of the appliance.
◆ Plug the power adapter ⑪ into a mains outlet.

Handling and operation

Initial use

! ATTENTION! It is possible that oil drops may cause damage to furniture surfaces. If necessary, place a cloth under the appliance.

◆ Place the appliance on a level and stable surface.

Remove the lid ② and fill the water tank ⑥ with at least 20 ml (maximum 150 ml) clean tap water using the provided measuring beaker ⑬. Note the maximum filling level ⑦ marked with MAX.
♦ Add 2 to 4 drops of the desired oil to the water.
Afterwards, place the lid ② back on the water tank ⑥. On the SAD 3.7 G6 model, the ventilation slot ⑧ must fit into the recess on the underside of the lid, otherwise the lid ② will not rest evenly.
♦ Plug the mains adapter ⑪ to the power outlet.

Switching the appliance on and off and the colour change function

Press the ⏻ button 10 to switch on the appliance. Aromatic mist production and the colour change function start.
◆ Press the ⚙ button Ⓗ to fix the current colour.

◆ Press the button ⑨ again to switch off the colour change function.

Press the 🎨 button ⑨ again to switch the colour change function back on.

Press the ⏻ button 10 again to switch off the appliance. Aromatic mist production and the colour change function stop.

① Note: The appliance switches itself off automatically as soon as the liquid in the water tank ⑥ has been used up.

! ATTENTION! Damage to the appliance! NEVER tilt the appliance during operation and do not try to empty it.

Always disconnect the USB connection cable 12 from the appliance before filling or emptying the appliance.

To prevent damage, do not empty the appliance through the ventilation slot ⑧. When emptying the appliance, note the pouring direction arrow ④ on the water tank ⑤.

Cleaning

! ATTENTION! Damage to the appliance! To avoid irreparable damage, when you are cleaning the appliance ensure that no moisture can penetrate into it.

Switch off the appliance before cleaning it.

Always disconnect the USB connection cable 12 from the appliance before cleaning the appliance.

To avoid damage, do not empty the appliance through the ventilation slot ⑧. When emptying it, take note of the pouring direction arrow ④ on the water tank ⑥.

Under no circumstances should you try to remove scale deposits with a pointed or sharp object. The appliance could be irreparably damaged.

Cleaning/descaling the appliance

Clean the water tank 6 after each use so as to remove oil residue as completely as possible. For this, use a soft and slightly moist cloth. In the case of stubborn stains, place a few drops of mild detergent on the damp cloth.

① Note: Use common retail sunflower oil to remove discolourations caused by oils from the water container Ⓔ.

Should the steam production diminish, the ceramic disk ⑤ located at the bottom of the water tank ⑥ must be cleaned. For this, use a slightly moistened cotton bud.

◆ Clean the surfaces of the appliance with a soft and dry cloth.

To descale the appliance, use a standard commercial liquid descaling agent. Pay heed also to the manufacturer's instructions for your descaler.

◆ Fill the water tank ⑥ to the maximum filling level ⑦ with descaler and let it stand until the scale is fully dissolved.

◆ Pour the scale removal away and then clean the water tank ⑥ with a soft and slightly damp cloth.

Storage

- Should you decide to not use the appliance for an extended period, disconnect it from the mains power supply and store it in a clean and dry location away from direct sunlight.

SILVERCREST®

Disposal

Applies only to France:
SILVERCREST SAD 3.7 G6 - Disposal - 1

The product, its packaging and the operating instructions are recyclable. They are subject to an extended manufacturer responsibility and will be collected separately.

Disposal of the appliance

SILVERCREST SAD 3.7 G6 - Disposal of the appliance - 1

The adjacent symbol of a crossed-out dustbin means that this appliance is subject to Directive 2012/19/EU. This directive states that this appliance may not be disposed of in the normal household waste at the end of its useful life, but must be taken to specially set-up collection locations, recycling depots or disposal companies.

SILVERCREST SAD 3.7 G6 - Disposal of the appliance - 2

The disposal is free of charge for the user. Protect the environment and dispose of this appliance properly.

If your old appliance has stored any personal data, you are responsible for deleting it yourself before returning it.

SILVERCREST SAD 3.7 G6 - Disposal of the appliance - 3

Your local community or municipal authorities can provide information on how to dispose of the worn-out product.

Disposal of the packaging

SILVERCREST SAD 3.7 G6 - Disposal of the packaging - 1

The packaging materials have been selected for their environmental friendliness and ease of disposal and are therefore recyclable. Dispose of packaging materials that are no longer needed in accordance with applicable local regulations.

SILVERCREST SAD 3.7 G6 - Disposal of the packaging - 2

Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and separate the packaging material components for disposal, if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings: 1-7: plastics, 20-22: paper and cardboard, 80-98: composites.

Technical specifications

Power adapter
Manufacturer	Fujian Titan Electronic Co., Ltd.8280 Lihan East Avenue, JiangkouTown, Hanjiang District, Putian City,Fujian Province, ChinaCommercial register number:91350303MA33E124XHImporter:KOMPERNASS HANDELS GMBH,BURGSTRASSE 21,44867 BOCHUM, GERMANY,Registered court: AG Bochum,Register number: HRB 4598
Model M4-0520-2E
Input voltage	100-240 V ~
Input AC frequency 50/60 Hz
Output voltage 5.0 V	==
Output current 2.0 A
Output power 10.0 W
Average efficiency in operation	79.4 %

SILVERCREST®

Power adapter
Power consumption at no load	0.09 W
Power consumption 0.3 A
Protection class	II/☐ (double insulation)
Polarity
Protection type IP 20
Efficiency class 6
Short-circuit proof safety transformer
Switched-mode power supply

Appliance
Input voltage 5.0 V	==
Power consumption 2.0 A
Protection class	III / ◇ (protection through low voltage)
Water tank capacity 150 ml

This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.

Warranty conditions

The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.

If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.

If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.

Warranty period and statutory claims for defects

The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.

Scope of the warranty

This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.

The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches, batteries or parts made of glass.

The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.

This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

■ Please have the till receipt and the item number (IAN) 452697_2310 available as proof of purchase.
■ You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

SILVERCREST SAD 3.7 G6 - Warranty claim procedure - 1

You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com.

This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 452697_2310.

SILVERCREST®

Service

GB Service Great Britain

Tel.: 0800 404 7657

E-Mail: kompernass@lidl.co.uk

IE ServiceIreland

Tel.: 1800 101010

E-Mail: kompernass@lidl.ie

IAN 452697_2310

Importer

Please note that the following address is not the service address.

Bevezető 1

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

NÉMETORSZÁG

www.kompernass.com

SILVERCREST SAD 3.7 G6 - Tartalomjegyzék - 1

SILVERCREST SAD 3.7 G6 - Tartalomjegyzék - 2

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Last Information Update · Stand der Informationen · Version des informations · Stand van de informatie

Stav informaci · Stan informacji · Stav informacií · Estado de las informaciones · Tilstand af information
