Alco - Breathalyzer Xblitz - Free user manual and instructions

Product Type	Breathalyzer
Brand	Xblitz
Model	Alco
Sensor	Electrochemical
Measurement Range	0 to 4.000‰BAC (0 to 2.000 mg/L; 0 to 0.400 %BAC; 0 to 4.000 g/L)
Resolution	0.001‰BAC
Measurement Error	±0.050‰BAC at 0.500‰BAC
Measurement Units	mg/L, g/L, %BAC, ‰BAC
Warm-up Time	5 seconds
Display	LCD Screen
Memory	Up to 99 measurements
Power Supply	2 AAA 1.5 V batteries (included)
Dimensions (L x W x H)	76 x 52 x 21.5 mm
Weight (approx.)	50 g (without batteries)
Operating Conditions	0°C to 40°C, humidity ≤ 90% RH
Storage Conditions	-10°C to 60°C, humidity ≤ 90% RH
Package Contents	Breathalyzer, 2x AAA batteries, 5x mouthpieces, user manual
Main Features	Precise measurement with electrochemical sensor, measurement history (99), adjustable alarm threshold, LED and sound indicator, auto power-off
Maintenance and Cleaning	Wipe with a soft cloth; do not use caustic products; replace mouthpiece every 10 measurements or clean it
Safety	Do not blow smoke, liquids, or food; wait 15 minutes after drinking alcohol; do not drive after drinking
Spare Parts and Repairability	Mouthpieces available; calibration required every 6 months or 1000 tests; 60-month warranty (excluding calibration)
General Information	60-month warranty; calibration recommended every 6 months; non-legal result

Frequently Asked Questions - Alco Xblitz

How to turn on the device and perform a test?

Insert 2 AAA batteries, place a clean mouthpiece, then press the button (FIG. C2) until the beep. Wait for the 5-second countdown, then blow when the screen shows BLOW. The result appears after a few seconds.

What does the message 'CAL' on the screen mean?

The message CAL indicates that the device requires calibration. Calibration must be performed every 6 months or after 1000 tests to ensure accuracy.

How to change the measurement unit?

Turn on the device, press both buttons simultaneously to enter setup mode. Enter code 1111 to change the unit. Use the buttons to select mg/L, g/L, %BAC, or ‰BAC, then confirm by holding the right button.

What to do if the screen shows 'rP' or 'ERROR'?

This means insufficient airflow or interrupted breath. Wait a few seconds, then try again by blowing continuously and steadily into the mouthpiece.

How to view measurement history?

Turn on the device, then hold the left button (FIG. C1) to browse stored measurements. Use the buttons to navigate between measurements. The device stores up to 99 measurements.

How often should the mouthpiece be replaced?

It is recommended to change the mouthpiece every 10 measurements or clean it to prevent accumulation of water or saliva, which could skew the results.

Is the device accurate?

Yes, thanks to its electrochemical sensor, the device offers an accuracy of ±0.050‰BAC at 0.500‰BAC. However, accuracy depends on conditions such as temperature, humidity, and respect of waiting times (15 minutes after consumption).

Can I use the device as legal evidence?

No, the results of this breathalyzer do not constitute legal evidence and cannot be used in court. The driver is solely responsible for driving under the influence.

How to maintain the device?

Clean the housing with a soft cloth. Do not use caustic cleaners or hard objects. Avoid shocks and excessive humidity. Replace batteries when the message Lob appears.

What to do if the device does not turn on?

Check that the batteries are correctly inserted (respect polarities) and that they are sufficiently charged. If the problem persists, contact customer service.

USER MANUAL Alco Xblitz

Wymiary: 76x52x21.5mm

Waga: 53g (bez baterii)

07. KARTA GWARANCJI

Dear customer, thank you for choosing our brand.

The Xblitz Alco is a state-of-the-art breathalyser that features an advanced electrochemical sensor with high sensitivity, accuracy and repeatability of measurements. A large LCD screen and a mouthpiece with backflow protection ensure user comfort and ease of use. Features such as measurement history tracking, high precision and mobility make the device comfortable and safe to use and meet users' needs - in any situation. Before using the device, please read the following instructions.

CAUTION: Do not allow yourself or anyone else to drive after drinking alcohol.

PRECAUTIONS

1. Do not drop the device or shake it violently.
2. Test results may be inaccurate when battery capacity is low.
3. To ensure the accuracy of the measurement, perform the test 15 minutes after drinking alcohol.
4. If the device has been left unused for a long time, the first measurement taken may be inaccurate.
5. If you want to perform multiple tests, wait at least 1 minute between tests.
6. Do not blow tobacco smoke, liquids or pieces of food into the device. This can permanently damage the sensor and lead to an incorrect measurement.
7. If the device is dirty, use a soft cloth to wipe it off. Do not use caustic

cleaners, wire, or hard cleaning utensils, they may damage the housing of the device.

1. The correlation between breath alcohol content and blood alcohol concentration depends on many variables, including environmental factors (such as wind, humidity, temperature, etc.) as well as the health of the person being tested.

2. Measurement results from this device do not constitute evidence in legal terms and cannot be used in court. The driver bears full responsibility for driving under the influence of alcohol.

3. The test result may vary depending on a number of factors. Getting a particular test result one time does not mean that the result will be the same even a few minutes later.

4. Do not allow yourself or anyone else to drive after drinking alcohol. Always use a taxi or other vehicle driven by a sober person when you or someone else has consumed alcohol.

5. Under normal use, the device needs to be re-calibrated approximately every 6 months or after 1000 tests performed. For accurate measurement results, contact your device distributor or service centre and ask them to recalibrate the device's sensor.

01. CONTENTS OF THE KIT

1. Breathalyser
2. AAA battery x2
3. Mouthpiece x5
4. User manual

02. DESCRIPTION OF THE DEVICE

SEE FIG. A

1. Mouthpiece/air outlet
2. Display
3. Buttons
4. Air outlet
5. Indicator light
6. Loudspeaker
7. Battery cover

03. DESCRIPTION OF THE DISPLAY

SEE FIG. B

1. Battery status
2. Measurement value

3. Measurement unit

4. Measurements from memory

5. Error
6. Blow
7. Wait

04. COMMUNICATIONS

The following are the messages that may appear on the display and their meaning.

1. Message: „8.8 8 8”

Meaning: Reading

1. Message: „1000 after switching on“

Meaning: Number of remaining measurements before necessary calibration

1. Message: Wait + „5 4 3 2 1“

Meaning: Sensor warm-up in progress, please wait

1. Message: „Wait + ---”

Meaning: analysis in progress

1. Message: „CAL”

Meaning: Calibration

1. Message: „Blow“

Meaning: Please blow

1. Message: „Blow+ Error +rp“

Meaning: error during blowing

1. Message: „Lob“

Meaning: Low battery level

1. Message: „RECORDS XX“

Meaning: Recorded measurement number XX

1. Preparation for measurement and measurement

a. Remove the battery compartment cover on the back of the device. Place 2 AAA 1.5V batteries inside. Make sure the battery terminals are facing the right way. Place the battery compartment cover back in place.

b. Place a clean mouthpiece in the device. If you are unsure where and how to place the mouthpiece, see the device diagram in the DEVICE DESCRIPTION section.

c. Press and hold the button in FIG.C2 until you hear a short beep to switch the device on. The instrument's display will turn on, indicate the number of remaining measurements before the necessary calibration and illuminate the indicator LED alternately

in red, green and blue. It will then display a 5-second countdown to warm up the instrument's sensor.

NOTE: Do not blow into the mouthpiece until the countdown is complete. Premature use of the device may lead to an incorrect measurement of the breath alcohol content.

d. When the display shows „BLOW“ and you hear a beep, take a deep breath and blow continuously into the mouthpiece, which will illuminate if a measurement is being taken. Blow until you hear a beep coming from the device. After a few seconds, the measurement result will be displayed on the screen.

NOTE: If the air flow is too low or is interrupted while blowing, the display will show „rP” and display „BLOW” and „ERROR”. Wait a few seconds before measuring again.

e. If the measurement result is below the alarm threshold, the indicator LED will illuminate green. If the measurement result is at or above the alarm threshold, the LED will illuminate red and an alarm signal will sound from the unit.

f. Press the FIG.C2 button to turn off the result display and start the next measurement.

g. The breathalyser will automatically switch off if there is prolonged inactivity to save battery power.

h. If you wish to manually switch off the device, hold down the button for 3 seconds.

NOTE: If the test is repeated multiple times, replace the mouthpiece with a new one every 10 measurements or clean the mouthpiece to remove any water or saliva build-up. The presence of water/saliva in the mouthpiece can cause measurement errors.

2. Viewing stored measurements

With the unit switched on, press and hold the WATCH button in FIG.C1 to review the history of measurements taken. The first record that appears on the screen is the last measurement taken. The unit can store up to 99 recently taken measurements. Use the buttons to browse through the measurements. Press the FIG.C1 button to check the previous measurement or press the FIG.C2 button to check the next measurement. Holding down the left button longer will take you back to the test interface.

3. Function settings

a. Enter settings mode:

With the unit switched on, press both the SEE FIG.C.1 and FIG.C2 buttons simultaneously to enter the settings mode.

b. Changing the unit:

In setting mode, press the SEE FIG. C.1 button to change the flashing digit, then the SEE FIG. C.2 button to confirm the selection. Enter 1111 to change the unit of measurement (default - %oBAC). Use the SEE FIG. C.1 and FIG. C2 buttons to select your preferred unit. Once selected, press and hold the SEE FIG. C.2 button to confirm the selection or the SEE FIG. C.1 button to exit the setting without saving the changes.

c. Setting the alarm threshold:

In the setting mode, press the SEE FIG. C.1 button to change the flashing digit, then the SEE FIG. C.2 button to confirm the selection. Enter 1112 to change the alarm threshold (default - 0.200‰BAC). Press the SEE FIG. C.1 button to change the flashing digit, then the SEE FIG. C.2 button to confirm the selection. Once selected, press and hold the SEE FIG. C.2 button to confirm the selection or the SEE FIG. C.1 button to exit the setting without saving the changes.

4. Switching off the appliance

Hold down the FIG. C.2 button to switch off the appliance.

06. SPECIFICATIONS

Sensor: Electrochemical

Measurement Range: 0\~4,000‰BAC (0\~2,000mg/L; 0\~0.400%BAC; 0\~4,000g/L)

Measurement resolution: 0.001‰BAC

Measurement error: ±0.050‰BAC for 0.500‰BAC

Units: mg/L, g/L, %BAC, ‰BAC

Sensor warm-up time: 5s

Operating conditions: 0°C - 40, °C humidity: ≤ 90% RH

Storage conditions: -10^ - 60^ , humidity: ≤90% RH

Display: LCD

Memory: Up to 99 measurements taken

Power supply: 2x AAA 1.5V batteries

Dimensions: 76x52x21.5mm

Weight: 53g (without battery)

07. WARRANTY CARD

The product is covered by a 60-month warranty. Warranty terms and conditions can be found at: https://xblitz.pl/gwarancja

Complaints should be made using the complaint form found at:

Details, contact and service address can be found at: www.xblitz.pl

Serial number......

The warranty is only valid if the device is regularly serviced and calibrated at an authorised service centre. At least once a year. The device has been correctly calibrated since new. Every breathalyser on the market requires periodic calibration, i.e. every 1,000 measurements, while at least every 12 months (every 6 months is recommended) the device must be recalibrated correctly interpret the amount of alcohol in the air exhaled. The need for recalibration is not a defect in the device and is not subject to warranty. A device that is not regularly calibrated will show erroneous results.

DE

BEDIENUNGSANLEITUNG

Dimensions: 76x52x21.5mm

Poids: 53g (sans pile)

07. CARTE DE GARANTIE

The crossed out trash can symbol indicates that unusable electrical or electronic devices, its accessories (such as power supplies, cords) or components (for example batteries, if included) cannot be disposed of alongside with household waste. In order to dispose of the devices or its components (for example, batteries) deliver the device to the collection point, where it will be accepted free of Disposal is subject to the recast version of the WEEE Directive 19/ EU) and the Directive on batteries and accumulators (2006/66 / paper disposal of the device prevents degradation of the natural ment. Information about the collection points of the facilities is by the competent local authorities. Incorrect disposal of waste is to penalties provided for by the law in force in the given area.

DE

Seller's details: Calibration date:

Pure white background with no visible text, symbols, or objects

Xblitz®

Producent:

KGK TREND Sp. z o.o.

ul. Ujastek 5b, 31-752 Kraków, Polska.

Wyprodukowano w PRC

Producer:

KGK TREND Sp. z o. o.

Ujastek 5b, 31-752 Cracow, Poland.

Made in PRC
