T505540-5 - Roofing materials Vevor - Free user manual and instructions

Product Type	Synthetic thatch roof tiles
Brand	Vevor
Model	T505540-5
Dimensions (L × W)	5000 × 400 mm
Material	Synthetic (polyethylene or polypropylene)
Color	Speckled yellow (color R5055)
Primary Use	Decorative roof covering (eaves, ridge)
Fixing Methods	Cable ties, wire, nails, self-tapping screws, structural adhesive
Recommended Overlap	6.5 to 7 cm for the main part; greater overlap for the first 6 rows
Weather Resistance	Designed for outdoor use (UV and water resistant)
Maintenance	Gentle water cleaning; do not walk on tiles after installation
Usage Precautions	Do not use for fire or insect prevention; pay attention to safety during installation
Number of Pieces per Package	Not specified (sold individually or in rolls)
Country of Origin	China (Shanghai)
Warranty	Electronic warranty via www.vevor.com/support

Frequently Asked Questions - T505540-5 Vevor

How to install thatch tiles on an eave?

For the first row, nail the actual part along the reference line. The first six rows must be laid with a significant overlap (2-3 cm) to create a thickness effect. Above the sixth row, maintain an overlap of 6.5 to 7 cm.

What tools and fixings are needed for installation?

You can use cable ties, wire, nails (garden nails, straight nails) or self-tapping screws. Structural or double-sided adhesive can also be used.

How to lay tiles on the ridge (roof edge)?

Start with the main surface on both sides, then go up from bottom to top forming a backbone. Use 2-3 small cut pieces to adjust the ridge width. First lay the sides, then a center piece.

Can the tiles be cut to the desired size?

Yes, it is possible to cut the tiles into small pieces, especially for the ridge. Use shears or a utility knife to obtain suitable dimensions (about 2-3 pieces depending on ridge width).

What maintenance is recommended after installation?

After installation, avoid walking on the tiles and do not use them for fire or insect prevention. Gentle water cleaning is possible if necessary.

Are the tiles weather resistant (sun, rain)?

Yes, they are designed for outdoor use and are resistant to UV and water. However, follow the installation instructions to ensure good durability.

What is the difference between models T505540-1, -5 and -10?

The main difference is the length: T505540-1 is 1000 mm, T505540-5 is 5000 mm, and T505540-10 is 10000 mm. The width is 400 mm for all.

How to get warranty or technical assistance?

Technical assistance and electronic warranty certificate are available on the website www.vevor.com/support. Keep the proof of purchase.

Can the tiles be used on an existing roof?

Yes, they can be installed over an existing covering, provided the surface is clean and flat. Respect the specified overlaps to prevent infiltration.

What risks to avoid during installation?

Do not overtighten the fixings to avoid deforming the tiles. Wear gloves and use appropriate safety equipment. Avoid laying tiles in rainy or windy conditions.

USER MANUAL T505540-5 Vevor

Affordable. Reliable. Home Improvement.

THATCH ROOFING

MODEL:T505540-1 & T505540-5

T505540-10 & T505550-5

Technical Support and E-Warranty Certificate

www.vevor.com/support

MODEL:T505540-1 & T505540-5

T505540-10 & T505550-5

This is the original instruction, please read all manual instructions care before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the produ received. Please forgive us that we won't inform you again if there a technology or software updates on our product.

Technical parameter

Model	Size (L * W)	Colour
T505540-1	1000*400 mm	Spotted Yellow (Color R5055)
T505540-5	5000*400 mm
T505540-10	10000*400 mm
T505550-5	5000*500 mm

Installation - Roof

Note: The installation method may be different in different scenarios. The installation procedure is for reference only.

1. Eaves part:

In the first row, along the reference line (keel), nail the real part of the that along the eaves;

Second row, overlapping; The third row to the sixth row, each row cup back basically overlapping, highlighting the eaves thick effect; Above the sixth row, 6.5cms - 7cms (the width of the thatch tile part).

1. Ridge part:

Oblique ridge: first lay the main surface on both sides of the thatched house then synchronously spread the spine shape from the bottom to the top to for rain guide; Positive ridge: the roofing thatch tiles are laid and then the positive ridge is closed; Tips: Oblique ridge and positive ridge thatch pieces Angle to the main surface of the thatch shingle part to adjust the size, according to 1 to cut the thatch tiles into small pieces installation, the effect is natural, easy close, the number of 2-3 small pieces (according to the width of the ridge to determine the shear size), first spread on both sides and then spread a piece the middle to form the backbone effect;

1. Finishing work after installation:

After the entire thatch roof is installed, the bending of the thatch tile can be properly pressed and picked to make it smooth and natural (especially the east part). You can choose from a fluffy effect (with a high degree of thatch bend) a smooth effect (with a low degree of thatch bending) to finish as needed.

1. Installation tips:

Do not be too compact or too loose when installing, so as not to affect the effect; The thatched grass along the eaves suggests that the grass lines sholong and overlapping, and the first six rows of the eaves are basically overla highlighting the heavy effect of floating and hanging; Color and style are spre according to the proportioning scheme; Take the dislocation paving method, th overall effect from the bottom up, do not see the base layer of the roof, th effect.

Fixing method

1. Bind with cable ties or iron wire and rope;
2. fixed with nails, yard nails, straight nails, or self-tapping screws;
3. Use structural adhesive or double-sided adhesive to fix.

Matters needing attention

1. the installation is completed do not tread, with hand folding;
2. not used for fire and insect prevention after installation;
3. the installation process pay attention to safety, do a good job of protectio

Manufacturer: Shanghaiuxinmuyeyouxianggsi

Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN.

Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122 Australia

Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730

YH CONSULTING LIMITED. C/O YH Consultin Limited Office 147, Centurion House, London Road, Staines-upon-Thames, Surrey, TW18 4A

Technical Support and E-Warranty Certificate www.vevor.com/support
