16-693 - Safety Shoes Vevor - Free user manual and instructions

Product Type	Alloy Toe Safety Shoes
Brand	Vevor
Model	16-693
Safety Standards	ASTM F2412-18A, F2413, F2913-19
Puncture Resistance	Yes, with puncture-resistant insert (metal or non-metal)
Antistatic Properties	Yes, dissipate electrostatic charges
Available Sizes (US)	8, 8.5, 9, 9.5, 10, 10.5, 11, 11.5, 12, 13
Available Sizes (UK)	7.5, 8, 8.5, 9, 9.5, 10, 10.5, 11, 11.5, 12
Available Sizes (EU)	41, 41.5, 42, 42.5, 43, 44, 45, 45.5, 46, 47
Available Sizes (CM)	26, 26.5, 27, 27.5, 28, 28.5, 29, 29.5, 30, 31
Wide Version	+7 mm compared to average foot
Care	Clean with a soft cloth and water; do not use alcohol or chemicals; air dry in ventilated area, avoid sunlight
Recommended Use	Alternate between two pairs, do not wear barefoot, tie laces
Lifespan	Varies depending on use and environment; replace if damaged
Storage	In a dry, ventilated place; do not place heavy objects on the box
Technical Support	www.vevor.com/support
Manufacturer	Shanghaiuxinmuyeyouxiangongsi, Shuangchenglu 803nong11hao1602A-1609shi, Baoshanqu, Shanghai 200000 CN

Frequently Asked Questions - 16-693 Vevor

What safety standards do these shoes meet?

Vevor 16-693 safety shoes comply with ASTM F2412-18A and F2413 standards for impact and compression, as well as ASTM F2913-19 for slip resistance.

How to care for my Vevor safety shoes?

Clean the shoes with a soft cloth and water after use. Do not use alcohol or acidic or basic chemicals. Air dry them in a ventilated area without direct sunlight exposure.

Are the shoes antistatic?

Yes, they dissipate electrostatic charges to minimize the risk of spark ignition. However, they do not protect against electric shocks from mains supply. Check their antistatic properties regularly.

What is the puncture resistance?

The shoes incorporate a puncture-resistant insert (metal or non-metal). Resistance has been laboratory tested with standardized nails. The insert type should be chosen based on risk assessment.

How to choose the right size?

Refer to the size chart in the manual: US, UK, EU and CM equivalents are indicated. For the wide version, the size is 7 mm larger than the average foot model.

Can I wear these shoes barefoot?

No, it is recommended to wear socks and do not wear the shoes barefoot. Also, always tie your laces for optimal support.

What is the difference between the standard and wide version?

For the same size, the wide version is 7 mm wider than the standard version. This provides more space for people with wider feet.

How to store the shoes when not in use?

Store the shoes in their original packaging in a dry, ventilated place. Do not place heavy objects on the box to avoid damaging the shoes.

What to do if the shoes are damaged?

If the shoes are damaged, they no longer guarantee the required protection. Replace them immediately to continue benefiting from the expected safety level.

Where can I find technical support?

For any questions or technical support, visit www.vevor.com/support. You will also find the electronic warranty certificate there.

USER MANUAL 16-693 Vevor

Technical Support and E-Warranty Certificate www.vevor.com/support

ALLOY-TOE-BOOTS

MODEL:16-693

We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when you are placing an order with us if you are actually Saving Half in comparison with the top major brands.

MODEL:16-693

NEED HELP? CONTACT US!

Have product questions? Need technical support? Please feel free to contact us:

Technical Support and E-Warranty Certificate www.vevor.com/support

This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of user manual. The appearance of the product shall be subject to product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

SAFETY INSTRUCTIONS

1. The shoes are maintained and worn in the correct working environment and stored under dry and ventilated conditions; the actual wear life of footwear depends on the type of footwear and the environmental conditions that may affect the wear, contamination and degradation of product.
2. Please do not use the same pair of shoes for a long time, which accelerate the damage of the shoes. It is recommended to use two shoes alternately and replace them every two days. 3. If the footwear becomes damaged, it will not continue to give the specified level of protection and to ensure that the wearer continues to receive the maximum protection, the footwear should immediately be replaced.
3. The packaging provided with the footwear at the point of sale is to ensure that the footwear is delivered to the customer in the same condition when dispatched; the carton can also be used for storing the footwear when not in wear. When the boxed footwear is in storage, it should not have heavy objects placed on top of it, as this could cause breakdown of packaging and possible damage to the footwear.
4. Although our shoes meet ASTM F2412-18A & F2413, it is forbidden to deliberately impact, puncture, electric shock and other destructive tests on our shoes to avoid damage to people.
5. Do not use other insoles instead of the original insoles, otherwise the shoes may lose the puncture protection function. 7. You need to tie your shoelaces and do not wear your shoes barefoot.
6. Shoes need to be cleaned in time to avoid exposing them to the sun. 9. It is recommended to check the anti-static function of shoes regularly to avoid damage to the anti-static function of shoes after damage.

PARAMETER LIST

SIZE SPECIFICATION

US	8	8.5	9	9.5	10	10.5	11	11.5	12	13
UK	7.5	8	8.5	9	9.5	10	10.5	11	11.5	12
EU	41	41.5	42	42.5	43	44	45	45.5	46	47
CM	26	26.5	27	27.5	28	28.5	29	29.5	30	31

Note: For the same size shoes, the wide version is 7 mm larger than the medium foot model.

SHOES PERFORMANCE

The shoe toe impact test, electric shock test, puncture test, and antistatic test comply with ASTM F2412-18A & F2413.

The shoe complies with ASTM F2913-19.

The perforation resistance of this footwear has been measured in the laboratory using standardized nails and forces.

Nails of smaller diameter and higher static or dynamic loads will increase the risk of perforation occurring. In such circumstances, additional preventative measures should be considered.

Three generic types of perforation resistant inserts are currently available in PPE footwear.

These are metal types and those from non-metal materials, which are chosen on the basis of a job-related risk assessment.

All types give protection against perforation risks, but each has different additional advantages or disadvantages including the following:

Metal (e.g. O1PS, O3): Is less affected by the shape of the sharp object/hazard (i.e. diameter, geometry, sharpness) but due to shoemaking techniques may not cover the entire lower area of the foot.

Non-metal (PS or PL or category e.g. O1PS, O3L): May be lighter, more flexible and provide greater coverage area, but the perforation resistance may vary more depending on the shape of the sharp object/hazard (i.e. diameter, geometry, sharpness). Two types in terms of the protection afforded are available. Type PS may offer more appropriate protection

for smaller diameter objects than type PL.

ANTISTATIC FOOTWEAR.

Antistatic footwear should be used if it is necessary to minimize electrostatic build-up by dissipating electrostatic charges, thus avoiding the risk of spark ignition of, for example, flammable substances and vapor, and if the risk of electric shock from mains voltage equipment cannot be completely eliminated from the workplace.

Antistatic footwear introduces a resistance between the foot and ground but may not offer complete protection.

Antistatic footwear is not suitable for work on live electrical installations. It should be noted, however, that antistatic footwear cannot guarantee adequate protection against electric shock from a static discharge as it introduces a resistance between foot and floor. If the risk of static discharge electric shock has not been completely eliminated, additional measures to avoid this risk are essential.

Such measures, as well as the additional tests mentioned below, should form a routine part of the accident prevention programme at the workplace.

Antistatic footwear will not provide protection against electric shock from AC or DC voltages. If the risk of being exposed to any AC or DC exists, then electrical insulating footwear shall be used to protect against serious injury.

The electrical resistance of antistatic footwear can be changed significantly by flexing, contamination, or moisture. This footwear might not perform its intended function if worn in wet conditions.

Class I footwear can absorb moisture and can become conductive if worn for prolonged periods in moist and wet conditions. Class II footwear is resistant to moist and wet conditions and should be used if the risk of exposure exists.

If the footwear is worn in conditions where the soling material becomes contaminated, wearers should always check the antistatic properties of

footwear before entering a hazard area.

Where antistatic footwear is in use, the resistance of the flooring should be such that it does not invalidate the protection provided by the footwear.

It is recommended to use an antistatic sock.

It is, therefore, necessary to ensure that the combination of the footwear, its wearers, and their environment is capable of fulfilling the designed function of dissipating electrostatic charges, and of giving some protection during its entire life. Thus, it is recommended that the user establish an in-house test for electrical resistance, which is carried out at regular and frequent intervals.

SHOE CLEANING AND NURSING CARE

1. When the shoes are not in use, they should be cleaned in time. 2. Use water and a soft cloth to wipe the dirt on the vamp. Do not immerse shoes in water or other liquids. 3. Do not use alcohol, acid-base chemical liquid to clean shoes.
2. After cleaning the shoes, you can dry them with a dry cloth first, then place them in a well-ventilated area to air dry. Do not expose them to direct sunlight or use a dryer.
