REBAR CUTTING SAW

MODEL:RD-10

We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represent the estimate of savings you might benefit from buying certain tools with us compared to top brands and does not necessarily mean to cover all categories of tools offered. Are kindly reminded to verify carefully when you are placing an order with us actually saving half in comparison with the top major brands.

MODEL:RD-10

NEED HELP? CONTACT US!

Have product questions? Need technical support? Please feel fr contact us:

Technical Support and E-Warranty Certificate www.vevor.com/support

This is the original instruction, please read all manual instruction carefully before operating. VEVOR reserves a clear interpretation user manual. The appearance of the product shall be subject to product you received. Please forgive us that we won't inform you there are any technology or software updates on our product.

PARAMETER LIST

Model	NRB-22
Wattage(W)	1100
G.W.(kg)	5,75
N.W.(kg)	6.4
Cutting speed	≤16s
Max Rebar	40mm
Min Rebar	4mm

Note: There are two versions of the voltage of the above product m respectively, AC220-240V 50Hz and 120V 60Hz, please see the name information of the product.

SAFETY INSTRUCTIONS

Purpose of this manual This manual is intended to provide users with correct knowledge and the procedures for operation, maintenance and inspection of the tool, a multipurpose flush cutting saw for cutting reinforcing bar, coil rod, all-threaded rod, pipe, tubing, and conduit. Improper use of the tool may possibly lead to a serious accident. Th always read this instruction manual before using the tool to familiarize yourself with its correct usage, operating method, warnings, etc.

Safety Instruction & General Safety Rules

Warning! Read and understand all instructions. Failure to follow

instructions listed below may result in electric shock, fire and/or serious personal injury.

Work Area Safety

• Keep work area clean and well lit. Cluttered or dark areas invite acid

• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create spars which may ignite the dust or fumes.

• Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control.

Electrical Safety

• Power tool plugs must match the outlet. Never modify the plug in a Do not use any adapter plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electric shock
- Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electroshock if your body is earthed or grounded.

Do not expose power tools to rain or wet conditions. Water entering power tool will increase the risk of electric shock.

Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edg moving parts. Damaged or entangled cords increase the risk of electri shock. Replace damaged cords.

When operating a power tool outdoors, use an extension cord suitable outdoor use. Use of a cord suitable for outdoor use reduces the risk electric shock.

If operating a power tool in a damp location is unavoidable, use a r current device

(RCD) protected supply. Use of an RCD reduces the risk of electric

NOTE: The term residual current device (RCD may be replaced by the term ground fault circuit interrupter (GFCI) or earth leakage circuit bre (ELCB).

Personal Safety

• Always wear eye protection. Care must be taken to prevent chips from hitting other workers in the same area.

• Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

• Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes, hard or hearing protection used for appropriate conditions will reduce person injuries.

• Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch energizing power tools that have the switch on invites accidents.

Remove any adjusting key or wrench before turning the power tool o wrench or a key left attached to a rotating part of the power tool m in personal injury.

• Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

• Dress properly. Do not wear loose clothing or jewelry. Keep your hair clothing and gloves away from moving parts. Loose clothes, jewelry or hair can be caught in moving parts.

• If devices are provided for the connection of dust extraction and coll facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

Power Tool Use and Care

Power tools are dangerous in the hands of untrained users.

• Do not force the power tool. Use the correct power tool for your app. The correct power tool will do the job better and safer at the rate f was designed.

• Do not use the power tool if the switch does not turn it on and or power tool that cannot be controlled with the switch is dangerous and be repaired.

• Disconnect the plug from the power source and/ or the battery pack the power tool before making any adjustments, changing accessories, storing power tools. Such preventive safety measures reduce the risk starting the power tool accidentally.

• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate power tool.
• Maintain power tools. Check for misalignment or binding of moving parts and any other condition that may affect the power operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools sharp cutting edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc., in accordance with these instructions, taking into account the working conditions and the to be performed. Use of the power tool for operations different from intended could result in a hazardous situation.

Service

Have your power tool serviced only by a qualified repair person using identical replacement parts. This will ensure that the safety of the pot tool is maintained.

Contents of the Cutting Edge Saw Package

Upon purchasing the Cutting Edge Saw, open the carrying case and the contents for the following:

CE-25 Package

1.CE-25 Corded Cutting Edge Saw with blade mounted : 1unit
2.Removable Side Handle and chip collector attachment: 1 unit
3. Allen Wrenches for Blade Removal and Installation: 1 unit
4. Additional Saw Blade: 1 unit
5. Operation Manual: 1 copy

Functions and Applications

This section describes the functions, applications, service environment and other aspects of the Cutting Edge Saw. The Cutting Edge Saw is a tool developed for fast and efficient cutting of various ferrous and nonferrous materials. This multipurpose tool can be used by a variety of contractors however the primary design was for flush cutting or free or reinforcing bars, coil rod and all-threaded rod used in the construction industry.

Application of the Tool Actual areas of application the Cutting Edge S used for are as follows:

CE-25

3/8" to 1" or 10mm to 25mm grade 60 rebar (reinforcing bars), up to pipe, 1" O.D. copper water pipe, 1" O.D. tubing, 1" conduit, 1" square tubing and bar, and up to 1" O.D. all-threaded or coil rod.

Rules of Use and Storage To use the tool to its fullest performance, user is required to be fully familiar with the saw itself, the cutting bl and storage procedures upon completion of work.

Specifications

The power tool is a multipurpose saw with an enclosed guard and flcutting capabilities. The specifications of the main unit are as follows.

Standard Blade: (Best for Ferrous Metals)

The CE-25 is supplied with (2) each 5" (127mm) blade diameter × 1 thickness, 24 teeth with laser welded flange for mounting to Cutting E Saw spindle. The maximum blade RPM is 2,000.

Operation

Checking and Preparation of Working Environment: Check the following before using the Cutting Edge Saw. Always observe the instructions a prohibited items.

Checking of weather conditions, do not use in the rain or snow:

DANGER: The Cutting Edge Saw is not a waterproof pow

tool. If it becomes wet, the power source system may become faulty operator may get an electric shock. Therefore, when it is raining or s never operate this saw outdoors, on top of buildings or under roofs or rain or snow enters freely. Do not use where water accumulates or water splashes.

Operation Instructions

Adjust the rear handle position to comfortably grip the tool. (The rear handle changes position with the button located on the top of the hat. Locate the front handle in the mounting hole that provides the best go operate the trigger, depress the trigger lock button (on the side of the and then pull the trigger to start the saw. Start the saw before cutting then apply a light pressure moving forward through the cut.

DANGER: Electric Shock Hazard Ignoring this warning may

lead to death or serious injury. When raining or snowing, do not open outdoors or indoors where rain or snow enters freely or in extreme temperatures.

Do not use under high temperature and humidity or extremely cold temperature conditions. The tool is designed for use under an allowable environmental temperature of 0 to 100^ . Operation at higher temperatures may cause the tool's main unit to overheat. Operation at high temperatures with high humidity may cause the tool to fail due to condensation.

Also, do not operate the Cutting Edge Saw in very cold places or in refrigerators where the temperature is freezing or below.

Check The State of Your Work Site

Before using the tool, check whether the state of the worksite is as is the worksite free of foreign objects, debris, water, ice, snow, power electrical cables, and excessive dust? Is the floor free of obstructions? there adequate ventilation? Is the worker properly insulated from the ground. Follow the operation instructions and avoid prohibited items.

Remove Hazardous Substances

Since the tool is an electric tool, it may spark and cause an explosive fire if operated near gas cylinders, thinner, or explosive and other hazardous substances or in a place filled with flammable gas, etc. Therefore, do not use the tool in places where such hazardous subst are present.

DANGER: May cause an explosion or a fire. Ignoring this

warning may cause death or serious injury. Never use the tool in plain filled with flammable gas or near hazardous substances of high flammability.

Maintenance of the Main Unit

Always unplug the saw from the electric outlet before attempting any maintenance. Clean the entire unit occasionally by removing dust, debris and oils. Occasionally remove the flush cutting bottom plate; then remarry cutting chips that remain lodged in the area where the cutting brotates.

It is also recommended that the cutting blade be removed and inspect any materials that did not exit out the chip exhaust area. This should done after 4-8 hours of use. Most material cutting chips would normally out the chip exhaust area and into the Cutting Chip Catch Bag. It is recommended that the Cutting Chip Catch bag be emptied when it becomes 2/3 full of cut material.

CE-25 Blade

The Blade for the CE-25 Cutting Edge Saw should be replaced when blade is dull or chipped and a noticeable increase in cutting time has occurred.

To change the Blade, remove the screws that hold the Blade Cover Body (4). Remove the cover and unscrew the (4) bolts holding the b the Hub. The replacement blades that you purchase have new screws be used when installing the new blade. Make sure that when you re the blade you clean out the head of any metal debris that has not the tool.

Please see your distributor for more information.

General Operating Cautions

The following describe the general cautions on operating tool. Always observe the cautions stated in each item.

• Do not press the operation switch if the tool is pointed towards any Operating the tool by holding it toward anyone may cause injury from contact with the blade.

• Do not apply the Cutting Edge Saw for purposes it is not intended.

• Do not use the tool for lifting or hammering etc. instead, only use it for cutting. Otherwise, the main unit may be broken or damaged, cause injury.

Manufacturer: Shanghaiuxinmuyeyouxianggsi

Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN.

Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122 Australia

Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730

UK

REP

YH CONSULTING LIMITED. C/O YH Consultin Limited Office 147, Centurion House, London Road, Staines-upon-Thames, Surrey, TW18 4A

EC

REP

Technical Support and E-Warranty Certificate

www.vevor.com/support
