SS-8455 - Earphones Sogo - Free user manual and instructions

USER MANUAL SS-8455 Sogo

Black outdoor headphones with adjustable design and earband (no visible text or symbols)

Cascos Auriculares - Cancelacion de Ruido Headphone - Noise Cancelling Casque de musique - Antibruit

ref. SS-8455

CE RoHS 2017/EB/2018

SEGURIDAD Y MANTENIMIENTO

Technical line drawing of a mechanical device with no visible text or symbols

Cargar la batería

This instruction manual can also be downloaded from our web page www.sogo.es

• Please read the suggestions below in order to help prolong the product lifespan.
• Keep the product dry, do not put it in humid circumstance to avoid short circuit.
• Do not expose it to the sun or high heat. High heating will short lifespan of electronic components, damage battery and deform some plastic parts.
• Do not put it in cold circumstance to avoid damage to PCB board.
• Do not attempt to take apart the product, especially non-professionals.
• Do not fall, vibrate strongly, strike with hard objects, to avoid damage to inner electronic circuit.
• Do not use high chemical products, detergent to clean the item.
• Do not scratch the surface with sharp items to avert damaging the case and appearance.
• Do not make it charging 10 hours continuously for the sake of lifespan.
  If the product cannot work properly, please send it to SOGO authorized maintenance agents. Our staff will help to solve the problems for you.

Keys and Parts

The headset contains the following parts:

Audio cable *1PC Charge cable*1PC Manual *1pc Air-plane adapter *1pc EVA Hard Carry Case*1pc

Technical line drawing of a mechanical device with no visible text or symbols

Charge the Battery

The headphone contains a Micro USB cable that can be connected to your computer or other device made for USB charging. Plug the Micro USB end of the included USB cable into the USB micro port charger connector under the left ear-cap of the headphone. Plug the other end into a USB port on your computer or other devices made for USB charging. The indicator light will be red while charging. Once fully charged, the indicator light will turn off. Charge time is two hours on an empty battery. The fully charged battery has power for up to 12 hours talking and/or music time (and up to 20 hours standby time).

When red light flashes, it is low battery. Please charge the headphone as soon as possible.

Note:

The headset is with built-in lithium ion battery. Please keep at least 4 hours full charge before first time of use (Suggestion: Do not use the car charger for charging it the first time,).

Specifications

Driver units: 40mm neodymium Sensitivity: 98db Impedance: 32 ohms Noise Reduction: 18db-22db Noise reduction range: 50-950HZ Audio cable length: 1.5M Battery: 3.7v, 250mah Charging time: 2 hours Working time with ANC: 12 hours

SAFETY AND MAINTENANCE

This instruction manual can also be downloaded from our web page www.sogo.es

Technical line drawing of a mechanical device with no visible text or symbols

Charger la batterie

DECLARATION OF CONFORMITY

This product complies with directive 99/05/EC of the European Parliament and the Council of March 9, 1999, transposed into Spanish law by Royal Decree 1890/2000, of November 20th.

DÉCLARATION DE CONFORMITÉ

This symbol means that in case you wish to dispose of the product once its working life has ended, take it to an authorised waste agent for the selective collection of waste electrical and electronic equipment (WEEE).

Product made in P.R.C. – Designed by SOGO based on the European Quality Standards

Customer Service: www.sogosat.com /

[e-mail] / 0034 902 222 161

Simple line drawing of a trash bin with crossed lines indicating no waste or discharge (no text or symbols)
