USER MANUAL 48525 UNOLD

Red UNOLD Classic movie theater with open popcorn and glass bowl, no visible text or symbols on main objects

POPCORNMAKER CLASSIC

Bedienungsanleitung

Instructions for use I Notice d'utilisation Gebruiksaanwijzing I Istruzioni per l'uso Instrucciones de uso I Návod k obsluze Instrukcja obsługi

Modell 48525

INHALTSVERZEICHNIS

Instructions for use Model 48525

Technical data....14

Explanation of symbols....14

For your safety....14

Before using the appliance for the first time....17

Preparing popcorn 17

Cleaning and care....18

Guarantee Conditions....19

Waste Disposal / Environmental Protection 19

Service 13

1 Measuring cup
2 Housing with discharge opening
3 Motor block / popcorn chamber
4 On/Off switch (0 = Off, I = On)

F Page 20

Hand pouring granular substance from a red blender into a glass container (no text or symbols visible)

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid rectangle below (no text or labels)

INFORMATIONEN FÜR DEN FACHHANDEL

E-Mail [e-mail]

SCHWEIZ

MENAGROS AG

Hauptstr. 23

CH 9517 Mettlen

Telefon [phone]

Telefax [phone]

E-Mail [e-mail]

Internet www.bamix.ch

POLEN

Quadra-Net

Dziadoszanska 10

61-248 Poznań

Internet www.quadra-net.pl

TSCHECHIEN

befree.cz s.r.o.

Škroupova 150

537 01 Chrudim

Telefon [phone]

Housing: Plastic, red metallic/transparent

Dimensions

(L/W/H): Approx. 16.0 x 20.0 x 30.0 cm

Weight: Approx. 0.901 kg

Power cord: Approx. 85 cm

Max. capacity: Approx. 100 g of corn kernels

Features: On/Off switch, integrated measuring cup; it is not necessary to add oil

Accessories: Operating instructions

Equipment features, technology, colours and design are subject to change without notice. Errors and omissions excepted.

EXPLANATION OF SYMBOLS

This symbol denotes a possible hazard which could cause injury or damage to the appliance.

This symbol indicates a potential burning hazard. Please be especially careful at all times here.

FOR YOUR SAFETY

General safety instructions

1. Please read the following instructions and keep them on hand for later reference.
2. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

1. Children of less than 3 years should be kept away unless continuously supervised.
2. Children aged from 3 years and less than 8 years shall only switch on/off the appli-

ance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

1. Children should be supervised to ensure that they do not play with the appliance.
2. Keep the appliance out of the reach of children.
3. Only connect the appliance to an AC power supply with voltage corresponding to the voltage specified on the rating plate.
4. Do not operate this appliance with an external timer or remote control system.
5. The motor block, power cord and plug must not come into contact with water. However, if this should happen, all parts must dry completely before it is used again.
6. If not in use, always turn off the appliance and unplug it from the electrical outlet.
7. The appliance is intended for household use only, or for similar areas of use, such as, ■ kitchenettes in businesses, offices or other workplaces, ■ agricultural enterprises, ■ for use by guests in hotels, motels or other lodgings,

■ in private guest houses or holiday homes.

1. Never open the housing of the appliance. This can result in electric shock.
2. Check the appliance, the plug and the power cord regularly for wear or damage. In case of damage to the power cord or other parts, please send the appliance or the base for inspection and repair to our after sales service. Unauthorised repairs can result in serious hazards for the user and void the warranty.

Information on set-up and use of the appliance

1. For safety reasons, never place the appliance on hot surfaces, a metal tray or a wet surface.
2. Do not place the appliance or power cord near open flames during operation.
3. Always use the appliance on a level, uncluttered and heat-resistant surface.
4. The appliance is not suitable for use outdoors or in rooms that are damp or humid, such as bathrooms.
5. Ensure that the power cord does not hang over the edge of the counter top or table, since this can cause accidents, for example if small children pull on the cord.

6. Route the power cord so that there is no possibility of the cord being pulled or tripped over.

7. To unplug the appliance, always pull on the plug, never on the power cord.

8. Never use the power cord to carry the appliance.

9. If you use an extension cord, ensure that it is intact and suitable for the power draw of the appliance; otherwise, there is a possibility of the appliance overheating.

10. Maintain sufficient space between the appliance and walls and other flammable objects, such as curtains.

11. The appliance is only designed for the preparation of popcorn in quantities that are usual for a household.

12. The appliance must be completely assembled and the lid must be closed during operation. Never switch the appliance on if corn has not been filled.

13. Do not overfill the appliance (max. capacity 100 g corn).

14. Never open the appliance during operation and never reach into the appliance in running operation.

15. The appliance becomes hot during operation. Do not touch any hot surfaces. Please use pot holders when moving the hot appliance.

16. Never cover the appliance during operation.

17. Do not operate the appliance for longer than a maximum of 5 minutes at a time.

18. Then allow the appliance to cool for at least 10 minutes before you prepare another batch of popcorn.

19. To avoid damage, do not use the appliance with accessories of other manufacturers or brands.

20. Unplug the mains plug from the electrical outlet after use and before cleaning. Never leave the appliance unattended when the mains plug is plugged in.

21. Allow the appliance to cool before cleaning it.

22. Never immerse the motor block in water, if you do so the motor block can be damaged.

23. This appliance works with hot air. Consequently, do not use any grease or oil, if you do so the appliance can be damaged and there is danger of burn injuries.

24. Do not use any ready-made mixes that contain oil or grease. Only use conventional, dry corn kernels.

CAUTION:

The appliance is very hot during and after operation!

Never open the housing of the appliance. This can result in electric shock.

The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

BEFORE USING THE APPLIANCE FOR THE FIRST TIME

1. Remove all packaging materials and any transport safeguards. Keep children away from the packaging materials due to the danger of suffocation.

2. Clean all parts with a damp cloth, as described in the chapter "Cleaning and care".

3. Check to make sure that the appliance is stable.

PREPARING POPCORN

Caution: For safety reasons, do not under any circumstances add oil, butter or other greases or other ingredients to the corn kernels!

Only use customary, dry popcorn kernels without other additives, such as salt, sugar or grease. Do not use microwave popcorn.

The maximum fill quantity per batch is 100 g of corn kernels. Do not overfill the appliance, if you do so the corn kernels on the bottom can scorch and smoke can form.

Ensure that you use a sufficient quantity of corn kernels, if you do not fewer kernels will pop and there will be more hard corn kernels among the popcorn.

Do not switch the appliance on if no popcorn has been filled.

1. Check to make sure that the appliance is stable; maintain an adequate distance to other objects.

2. Take the measuring cup out of the lid of the appliance and fill it half full (max. 100 g) with dry, fresh corn kernels.

Hand pouring grains into a red food processor with a fork (no text or symbols visible)

1. Fill the corn into the popcorn chamber on the motor block, through the opening in the lid.
2. At the maximum, fill one

measuring cup full of corn kernels into the popcorn chamber. If you use too much corn the appliance

can clog and it is possible that the appliance can be damaged.

1. For safety reasons, do not add oil, butter or other greases or other ingredients to the corn kernels.

2. Seal the opening in the lid by turning the measuring cup upside down and placing it on the lid. Ensure that the lid is tightly sealed.

3. Place a sufficiently large, heat-resistant bowl under the popcorn discharge. We recommend that you not use metal bowls because they can become extremely hot.

4. Connect the appliance to the mains network (220–240 V\~, 50/60 Hz).

5. Switch on the appliance via the On/Off switch.

6. The appliance heats up and after a short time the corn starts popping.
7. The finished popcorn falls into the bowl through the discharge opening.
8. When all the corn kernels have popped, switch off the appliance via the On/Off switch.
9. You can enjoy the finished, still hot popcorn pure, or you can refine it to your taste:

■ For sweet popcorn add sugar, powdered sugar or caramel
■ For savoury popcorn add salt, paprika powder, curry, etc.

1. Tip: When adding spices to the popcorn, add 1-2 teaspoons of sunflower oil, the sugar and spices will adhere better.
2. Occasionally some corn kernels do not pop, these kernels must be carefully removed when the appliance has cooled, before the appli-

ance is used again. To do this, carefully tip the cooled appliance forward, so that these kernels can fall out.

1. If you want to prepare another batch of popcorn, repeat steps 2 - 13. However let the appliance cool for at least 10 minutes after 5 minutes of operation.
2. If you do not prepare more popcorn, switch off the appliance via the On/Off switch and unplug the plug from the electrical outlet.

Caution: The appliance, particularly the lid, becomes extremely hot during operation - danger of burn injuries! For example, use potholders when handling the appliance to prevent burns.

Do not remove the lid while the device is in operation - you can be burned by the escaping hot air.

CLEANING AND CARE

Switch off the appliance via the On/Off switch.

Unplug the plug from the electrical outlet.

Allow the appliance to cool.

1. Do not immerse the motor block and power cord in water or other liquids!

2. All removable parts (upper part, lid, measuring cup) can be cleaned in warm water with mild dish-washing detergent. These parts are not dishwasher-safe!

3. Do not use any abrasive scouring agents, steel wool, metal objects, hot cleaning agents or disinfectants, as they can damage the appliance.

4. The motor block and the popcorn chamber can be wiped off with a well wrung-out, damp cloth.
5. All parts must be carefully dried before the appliance is put back together and before it can be used again.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged and postage paid, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. If the defect is covered by the warranty, the customer will be reimbursed for the shipping costs only in Germany and Austria. The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard household waste. Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

Symbol of a trash bin with no text or labels, featuring a crossed-out box and a solid rectangle below (no readable text or symbols)

The instruction booklet is also available for download: www.unold.de

NOTICE D'UTILISATION MODÈLE 48525

CARACTÉRISTIQUES TECHNIQUES

Puissance : 900 Watt, 220-240 V\~, 50/60 Hz

Hand pouring grain into a red blender with a spoon (no text or symbols visible)

CONDITIONS DE GARANTIE

Symbol of a trash bin with crossed lines indicating no waste or restriction, and a solid rectangle below (no text or labels)

Hand pouring grain into a red toaster oven (no text or symbols visible)

Hand pouring granular material into a red silicone blender (no text or symbols visible)

Symbol of a trash bin with crossed lines indicating no waste, and a solid rectangle below (no text or labels)

INSTRUCCIONES DE USO MODELO 48525

DATOS TÉCNICOS

Potencia: 900 vatios, 220-240 V\~, 50/60 Hz

(L/An/Al): Aprox. 16,0 x 20,0 x 30,0 cm

Peso: Ca. 0,901 kg

Cable de

Hand pouring grain into a red blender with a spoon (no text or symbols visible)

Hand pouring grain into a red blender with a spoon (no text or symbols visible)

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

INSTRUKCJA OBSŁUGI MODEL 48525

DANE TECHNICZNE

Moc: 900 W, 220-240 V\~, 50/60 Hz

Hand pouring chopped nuts into a red blender with a fork (no text or symbols visible)
