303000 - Digital timer switch Bearware - Free user manual and instructions

Type of product	Programmable digital timer switch
Brand	Bearware
Model	303000
Supply voltage	220-240 V ~ 50 Hz
Maximum load	16 A (resistive) / 3680 W
Protection rating	IP44 (splash-proof)
Temperature range	-25°C to +55°C
Programming	96 segments of 15 minutes (24 h cycle)
Number of cycles per day	Up to 48 on/off switchings
Display type	Graduated rotating ring from 1 to 24 h with blue scrolling bars
Housing material	UV-resistant plastic
Dimensions (approx.)	70 x 70 x 80 mm
Weight (approx.)	150 g
Main functions	Manual programming of on/off schedules, manual time setting
Safety	Overload protection (16 A max), do not short-circuit
Maintenance and cleaning	Clean with a dry, soft cloth; do not use abrasive products
Spare parts and repairability	Not user-repairable; no spare parts available
General information	Indoor or protected outdoor use (IP44); unplug during thunderstorms

Frequently Asked Questions - 303000 Bearware

How to set the current time on the timer switch?

Turn the inner ring clockwise until the black arrow on the housing points to the current time on the ring. This step is necessary before any programming.

How to set the on and off periods?

Press the blue scrolling bars corresponding to the desired time slots. A pressed bar = on, released = off. Each bar represents 15 minutes.

What to do if the device does not turn on or does not work?

Check that the power outlet works and that the connected device does not exceed the maximum load of 3680 W. Make sure the current time is correctly set and the programming bars are in the desired position.

Can I use this timer switch outdoors?

The device is IP44, so splash-proof. It can be used outdoors under shelter, but not directly exposed to rain or water jet.

What is the maximum power I can connect to this switch?

The maximum power is 3680 W (16 A resistive load). Do not exceed this value to avoid any risk of overheating.

How to clean the timer switch?

Unplug the device and clean it with a dry, soft cloth. Never use chemicals, alcohol, or abrasive cleaners.

Is this switch compatible with LED bulbs or electronic devices?

Yes, within the maximum load limit. For inductive loads (motors, transformers), the maximum load is reduced to 2 A (indicated by (2) in the specifications).

What to do in case of thunderstorm?

It is recommended to unplug the switch from the power outlet during a thunderstorm to avoid damage from lightning.

How to recycle this device at end of life?

Do not dispose of the device with household waste. Take it to a WEEE collection point (recycling center or store). The eco-contribution has been paid to finance its recycling.

Is the device certified?

Yes, the device complies with European directives (WEEE 2012/19/EU) and bears CE marking. The declaration of conformity can be requested from WD Plus GmbH.

USER MANUAL 303000 Bearware

Thank you for having chosen this product from Bearware and for placing your trust in our company. Before using the product for the first time, please read this manual carefully. For future reference, please keep this manual. Before using the delivered product, check that it is complete, faultless and undamaged.

1. Scope of supply

• Mechanical timer
• User manual

2. Technical specifications

Electrical voltage 220-240V AC 50Hz
maximum load 16 (2)A /	3680 W
IP protection class IP44
Ambient temperature -25°C to +55°C

3. Getting started

When the device is put into operation for the first time, check the intactness of the product or components and their function again. Take the product out of the package and remove all the packaging material. The Timer divides the 24 hours of a day into 96 individual sections of 15 minutes each. Using the 96 blue sliders, which are arranged in a circular shape on the front of the device, you can individually select the time for which electricity should flow. The inner ring represents the time of day in hours with the values 1-24 and is fixed to the sliders. Thus, the time indicated on the inner ring is associated with the adjacent slider. Push one of the sliders into the timer and the current flows for the appropriate time. If a slider is pulled out, then the device which is connected to the timer is switched off for that duration of time. After adjusting the time ranges as per your needs, it is necessary to set the current time of the day. Rotate the inner ring and the slider in a clockwise direction till the black, solid arrow on the front of the product points to the value of the inner ring, which corresponds to the current time of the day. Now plug the timer into a properly installed and earthed socket at home and then connect the device, whose power supply needs to be controlled by the timer. The timer is now ready for operation.

6 English

4. Important tips

• The wireless sockets are splash water proof (IP44) but should not be exposed to direct water jets
• Please do not plug the device into an extension cord but only into approved sockets
• Please do not connect in series
• The device does not carry current only when disconnected
• The specified maximum load should not be exceeded
• The socket has to be installed near the device and should be easily accessible
• Protect it against direct weather influences

5. Safety instructions and liability disclaimer

Never try to open the device to carry out repairs or conversions. Avoid contact with mains voltages. Do not short-circuit the product. Remove the plug from the mains when not in use or during thunderstorms. The device is only restrictedly suitable for outdoor use. Protect it against direct weather influences. Please use the device only in a protected area. The device is not certified for use in the open air; only use it in dry conditions. Protect it from high humidity, water and snow. Keep it away from high temperatures. Do not subject the device to sudden changes in temperature or heavy vibration as this might damage electronic components. Examine the device for damage before using it.

The unit should not be used if it has received an impact or has been damaged in any other way. Please observe national regulations and restrictions. Do not use the device for purposes other than those described in the instructions. This product is not a toy. Keep it out of the reach of children or mentally impaired persons. Any repair or alteration to the device not carried out by the original supplier, will invalidate the warranty or guarantee. The product may only be used by persons who have read and understood these instructions. The device specifications may change without any separate prior notice to this effect.

6. Disposal instructions

Electrical and electronic devices may only be disposed of in accordance with the European WEEE Directive and not with household rubbish. Components must be disposed of or recycled separately as dangerous, toxic elements can inflict sustained damage on the environment if they are disposed of incorrectly. As a consumer, you are bound by the Electrical and Electronic Devices Act (ElektroG) to return electrical and electronic goods free of charge at the end of their useful life to the manufacturer, the place of purchase or to specially set up, public collection points. The details in each case are governed by national law. The symbol on the product, the operating instructions and/or the packaging refers to these regulations. By separating materials in this way, recycling and disposing of old devices, you are making an important contribution towards protecting our environment.

WEEE guideline: 2012/19/EU WEEE register number: DE 67896761

WD Plus GmbH, herewith declares that this product 303000 conforms to the principle requirements and other relevant stipulations. The complete Declaration of Conformity can be obtained from: WD Plus GmbH, Wohlenbergstraße 16, 30719 Hanover

MO-FR 9:30am - 18pm CET

downloads.ganzeinfach.de

WD Plus GmbH
