USER MANUAL 302694 Bearware

QR code image containing encoded data, no visible human-readable text

ENG: Current drivers, user manuals and other relevant documents for this product can be found on our homepage.

Thank you for choosing a BEARWARE product. Please read the following user manual carefully so as to get the most from the product you have purchased. Before using the product, first check if the delivered item is complete, accurate and undamaged.

1. Scope of delivery

• Power strip
• Wireless foot switch
• User manual

2. Technical data

Power supply 230 V ~AC, 50 Hz, max. 16A
Power consumption max. 3680 W
Frequency 433.92 MHz
Transmitting power -2.6 dBm
Battery type (foot switch) One 3V CR2032
Sockets	2 permanently On / 4 can be switched On/Off (with foot switch)
Range approx. 15 m

CAUTION! PLEASE NOTE!

3. Important safety instructions

• Only for use in dry rooms!
• Do not exceed the maximum specified electric power!
• Do not connect in series!
• Do not operate in covered condition!
• Disconnected only when the plug is removed!
• The power strip has to be installed near the device and should be easily accessible!

4. Commissioning

Check if the product and the components are intact and if the device is working properly when using it for the first time Take the device out of the package and remove all the packaging material. Open the battery compartment at the bottom of the wireless foot switch and insert the provided 3V CR2032 type battery correctly. Pay attention to the correct polarity of the contacts!

Then connect the power strip to a properly installed socket. As soon as the red LED next to the ON/OFF button starts flashing in 1-sec. intervals, this means that the wireless foot switch has been connected successfully.

If the red LED next to the ON/OFF button does not glow, then you need to pair the foot switch again with the socket. Follow these steps to do this:

• Switch the power strip off. Then press and hold the ON/OFF button for about 5 seconds till the red LED starts flashing.
• Then press the foot switch button. The red LED on the power strip then flashes quickly and goes off again. The pairing process is now complete.

Once the pairing process is completed, press the foot switch only. The four sockets will be turned on or off depending on the previous state. Alternatively, you can switch it on or off by briefly pressing the ON/OFF button on the power strip. The two sockets to the left of the ON/OFF button are permanently on. After successful pairing, the status LED indicates the status of the 4 switchable sockets. If the LED is switched on, the 4 sockets are switched on. If the LED is switched off, the sockets are also switched off.

Decoupling the foot switch

To decouple the foot switch, press and hold the ON/OFF button till the red LED starts flashing slowly. Press and hold the button till the LED flashes quickly. The decoupling is now complete. To pair the device again, follow the instructions in the previous chapter "4 Commissioning".

5. Cleaning and Care

Disconnect the power strip from the mains socket before cleaning. Then disconnect all the connected loads and use a dry, soft cloth for cleaning. You can use a hair brush, for example to remove the dust. Never use aggressive cleaning agents, which may damage the housing or impair the function of the product.

6. Safety instructions and disclaimer

Never try to open the device to repair or make modifications. Avoid contact with the mains voltage. Do not short-circuit the product. The appliance is not waterproof, therefore please use it only in dry surroundings. Protect it from high humidity, water and snow. Do not expose the device to high temperatures.

Do not expose the device to sudden changes in temperature or strong vibrations, as this could damage the electronic components. Check the device for any damage before using it. The device should not be used if it was subject to impact or has been damaged in some other manner. Please comply with the local regulations and restrictions. Do not use the appliance for purposes other than those described in the user manual. This product is not a toy. Keep it out of the reach of children or mentally disabled persons.

Any repair or modifications to the appliance, which is not carried out by the original supplier, will void any warranty and guarantee claims. The appliance should be used only by persons who have read and understood this user manual. The specifications of the device may be changed without prior notification.

7. Disposal instructions

In line with the European WEEE directive, electrical and electronic devices should not be disposed of along with domestic waste. Their components have to be separately sent for recycling or disposal, because improper disposal of toxic and dangerous components may permanently damage the environment. According to the electrical and electronic equipment act (ElektroG), you are obliged (as a consumer) to return (free of charge) all electrical and electronic devices to the manufacturer, the point of sale, or public collection points at the end of their service life.

The relevant local laws regulate the details in this regard. The symbol displayed on the product, in the user manual or/and on the packaging refers to these regulations. With this manner of sorting, recycling and disposal of used devices, you make an important contribution towards protecting our environment.

8. Instructions for battery disposal

In conjunction with the sale of batteries along with the supply of devices that include batteries, the supplier is obliged to point out the following to the customer: The customer is legally obliged to return used batteries. He can return used batteries which the supplier offers or has offered as new batteries in his assortment free of charge to the supplier's dispatch warehouse (shipping address). The symbols shown on the batteries mean the following: Pb = battery contains more than 0.004 percent lead by weight, Cd = battery contains more than 0.002 percent cadmium by weight, Hg = battery contains more than 0.0005 percent mercury by weight.

9. Warranty and guarantee

The manufacturer provides a warranty of 2 years for this product with regards to workmanship and material.

1. The statutory warranty rights apply for products: For new items, the warranty period is two years from the date of delivery.
2. If the buyer is a merchant, the following applies by way of derogation from clause 1:
3. The quality of the goods is defined as agreed, only by the seller's own specifications and the product description of the manufacturer, but not any other kind of advertising, public promotions and statements by the manufacturer.
4. The buyer is obliged to check the goods immediately with utmost care for deviations of quality and quantity and report apparent defects promptly to the seller in writing. Timely dispatch of the notification of defects shall suffice for complying with the time limit. This also applies for concealed defects established later, from the time of their discovery. In case of violation of the obligation to inspect and notify, warranty claims cannot be asserted.
5. In case of defects, the seller may provide warranty either by repair or replacement.

Please note: As far as possible, the buyer is requested not to return the goods freight forward but as an insured package to the seller. The seller shall gladly pay the cost of postage in advance, if he has to bear the return charges. The buyer is also requested to avoid damage and contamination of the goods.

Goods should be returned in their original packaging with all accessories and with all packaging components to the seller. If the buyer no longer has the original packaging, he should return the goods in a suitable package to avoid damage in transit.

Note: The procedures indicated above are not a prerequisite for effective exercise of your warranty claims. Your warranty claims and your right of cancellation remain unaffected hereby.

The symbol of the crossed-out dustbin means that the battery must not be disposed of in household waste.

WEEE directive 2012/19/EU WEEE Register no.: DE 67896761

The company WD Plus GmbH hereby certifies that the device 302694 complies with the fundamental requirements and all other relevant stipulations of the guideline 2014/53/EC. A complete conformity statement can be obtained from: WD Plus GmbH, Wohlenbergstraße 16, 30179 Hanover, https://model.ganzeinfach.de/302694

MO-FR 9:30am - 18pm CET
