X-WAVE - Bluetooth speaker CROSSCALL - Free user manual and instructions
Find the device manual for free X-WAVE CROSSCALL in PDF.
| Product type | Bluetooth speaker |
| Brand | CROSSCALL |
| Model | X-WAVE |
| Dimensions | 98 mm (width) x 105 mm (depth) x 40 mm (height) |
| Speaker | 5 W |
| Battery | Lithium-ion Polymer 600 mAh |
| Charging time | 2 hours |
| Power supply | 5 V, 500 mA (via USB) |
| Bluetooth range | 10 meters |
| Water resistance rating | IPX7 (resists water up to 1 meter for 30 minutes) |
| Buoyancy | Yes, the speaker floats |
| Built-in microphone | Yes, for hands-free calls |
| Main functions | Wireless music streaming, telephone calls |
| Connectivity | Bluetooth |
| Material | Silicone coating for water resistance |
| Included accessories | Charging cable, carabiner |
| Maintenance | Rinse with clean water after use in sea or pool, let air dry |
| Safety | Do not expose to over 60 °C, do not modify or repair yourself |
| Recommended operating temperature | 15 to 25 °C |
| Assembled in | China |
| Manufacturer | CROSSCALL, 655 RUE P.S LAPLACE, 13290 Aix en Pce, France |
Frequently Asked Questions - X-WAVE CROSSCALL
User questions about X-WAVE CROSSCALL
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Bluetooth speaker in PDF format for free! Find your manual X-WAVE - CROSSCALL and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. X-WAVE by CROSSCALL.
USER MANUAL X-WAVE CROSSCALL
You can find the complete version of our user guide on our website, www.crosscall.com.
ADVANTAGES FOR USERS
• A clear and quality sound
- Easily transportable
• Waterproof and floating
- Perfectly suited for celebrations, inside or outside
• Built-in microphone: lets you take calls on your speaker
TECHNICAL SPECIFICATIONS
- Speaker: 5W
- Integrated battery: Lithium-ion Polymer 600mAh
- Dimensions: 98mm(W)*105mm(L)*40mm(H)
- Bluetooth range: 10m
- Charge time: 2 hours
- Charge: 5V, 500mA
IPX7 WATERPROOF SPEAKER
You speaker resists water (30 minutes at a 1 meter
depth). If you use it in the sea or the pool, do not forget to rinse your speaker in clean water after use.
SAFETY MEASURES
Carefully follow the steps described in the quick start guide to ensure your safety.
- Use with the correct charger.
- Do not dispose of your device in a fire.
- Do not burn your device.
- Do not expose your device to temperatures greater than 60^ / 140^ .
• Recycle according to current standards.
- Ensure you always close the sealing cap properly.
- The hook is for attaching the speaker. Under no circumstances must it be used for other purposes. Do not use the hook for climbing.
- The tubular stand must not be submersed in water.
- Allow the speaker to dry in the open air.
- The small parts (screw, screwdriver, hook, etc.) can be a choking risk.
• Always store this device between 15 and 25 degrees to maximize its life.
- Do not expose to dust, direct sunlight, high humidity, heat or any mechanical impacts.
- Avoid impacts.
- If the device overheats, falls or has been damaged, please stop using it immediately.
- Do not allow your children or pets to chew or lick the device.
- Do not use aggressive cleaning agents or solvents such as petrol or alcohol to wash your product: risk of damage.
- Be careful with the edges, uneven surfaces and metal parts of this device, as well as its packaging to avoid any possible injury or damage.
- Do not modify, repair or disassemble your device. Doing so may result in fire, electric shock, or complete destruction of the speaker. None of this is covered by the warranty.
- Do not attempt to change a part by yourself; if a part needs to be changed, contact your dealer.
- Do not remove the silicone coating of the speaker, it ensures its watertightness.
- This device is not intended for use by persons (including children) with reduced physical, sensory or mental
capacities, or persons without experience or knowledge, unless they are supervised by a person responsible for their safety or have received prior instructions concerning the use of the device. Children should be supervised to ensure that they do not play with the device.
- High volume and prolonged listening can cause hearing loss. When you turn on your speaker, ensure that the volume is set low. Raise it gradually.
- If you hear a slight buzz or feel any discomfort, stop using your device immediately.
• / ! \ Using your device at a high volume level while driving a motor vehicle, motorcycle, watercraft or even a bicycle is dangerous, or even strictly prohibited in some countries. Be sure to check the legislation in your country and be careful in all circumstances.
- Avoid exposing your device to rain or other liquids.
- Observe the various guidelines and instructions requiring all electrical equipment or equipment emitting radio waves to be switched off in restricted areas (hospitals and airplanes).
- Do not leave your battery charging unnecessarily as this may shorten its life.
- The battery used in this product may cause burns or chemical burns in case of improper handling. Only recharge your battery with approved chargers designed for this product.
- When unplugging the charger, grasp the plug, not the cord.
- If you do not use your speaker, the built-in battery will gradually lose its charge.
- Health Recommendations: If liquid coming out of the battery comes into contact with your eyes, wash them immediately and thoroughly with clean water and consult a doctor as it may cause blindness or injury. If liquid coming out of the battery comes into contact with your body or hands, wash thoroughly with water. If liquid coming out of the battery comes into contact with the product, wipe it thoroughly, avoiding direct contact with your hands.
WARNING
The logo and the Bluetooth ^® trademark are the property of Bluetooth SIG, INc. Any use of this trademark is subject to license. Other brand names and trade names are the property of their respective owners.
ENVIRONMENTAL PROTECTION
This symbol affixed on the product means that it is a device whose treatment as waste is subject to Waste Electrical and Electronic Equipment (WEEE) regulations.
Please respect the local regulations on the device's packaging, on disposing of it when you no longer require it and on placing it in selective collections points so that it can be properly recycled. Do not dispose of the device in an ordinary garbage can. Please dispose of the used device that you do not want to keep in a place designated for this purpose. Do not dispose of it with the household garbage.
| PROBLEMSOLUTION | |
| The speaker does not connect to my Bluetooth device. | The speaker must be connected/paired to the Bluetooth device again. |
| A sound is being emitted regularly. | The speaker must be charged. |
| The Bluetooth connection does not reach 10 meters. | Avoid connecting in areas with high levels of electromagnetic interference. Move your speaker close to your Bluetooth device. Fully charge your speaker and try again. |
| The speaker does not turn on. | The speaker must be charged. |
| The speaker cannot be controlled manually. | The speaker must be connected via Bluetooth for optimal control. |
| The sound is distorted when the volume is high. | The volume must be lowered. |
X-WAVE
Assembled in China Imported by: CROSSCALL 655 RUE P.S LAPLACE 13290 Aix en Pce - France www.crosscall.com
OUTDOOR MOBILE TECHNOLOGY
CROSSCALL.COM
