CANVAS 27F 165 - Monitor NZXT - Free user manual and instructions

Product type	Gaming monitor
Brand	NZXT
Model	CANVAS 27F 165
Screen size	27 inches (diagonal)
Maximum resolution	1920 x 1080 (FHD)
Aspect ratio	16:9
Refresh rate	165 Hz
Response time	1 ms (GtG)
Sync technology	AMD FreeSync Premium
Brightness	300 cd/m² (typical)
Viewing angle (H/V)	178° / 178°
Color gamut	92% DCI-P3, 99% sRGB
Video inputs	1 x HDMI 2.0, 1 x DisplayPort 1.2
Audio output	3.5mm headphone jack
Power supply	External adapter 19V 2.1A (100-240V AC)
Standby power consumption	< 0.5 W
Adjustments	Tilt -5° to +17°, swivel +/-45°
VESA compatibility	100 x 100 mm (M4 x 16 screws)
Dimensions with stand (W x H x D)	615 x 443.3 x 188.4 mm
Net weight	5.4 kg
Chassis color	White
Features	Flicker-free, low blue light, anti-glare, motion blur reduction
Care and cleaning	Unplug before cleaning, use a soft lint-free cloth, do not use chemicals.
Safety	Follow safety instructions detailed in the manual: do not expose to moisture, do not block ventilation, use a grounded outlet.
Spare parts and repairability	Do not disassemble the monitor. For any repairs, contact NZXT customer support via support.nzxt.com.

Frequently Asked Questions - CANVAS 27F 165 NZXT

How to turn on the monitor?

Press the joystick on the back of the monitor to turn on. Hold for 3 seconds to turn off.

The screen stays black but the power LED is on, what to do?

Check that the video cable (HDMI or DisplayPort) is properly connected. Press the joystick to wake from sleep. Check the input source in the OSD menu.

How to adjust brightness?

Access the OSD menu with the joystick, go to Image then Brightness. Adjust from 0 to 100%.

How to enable FreeSync Premium?

In the OSD menu, go to System Settings then FreeSync Premium and enable it. Compatible with G-Sync via DisplayPort.

How to change the input source?

Press the joystick to the right for quick access to source, or navigate OSD menu > Input Source.

The monitor flickers or has waves, what to do?

Check the video cable, adjust Sharpness in the Image menu, change Response Time (Normal/Fast/Fastest), enable FreeSync Premium.

How to adjust image sharpness?

In the OSD menu, go to Image then Sharpness and adjust from 0 to 10.

How to reset all settings?

In the OSD menu, go to System Settings then Reset All and select Yes.

The image is too bright or too dark, what to do?

Adjust Brightness in the Image menu (0-100%). Also check Contrast.

How to clean the screen?

Unplug the monitor. Use a slightly damp soft lint-free cloth. Do not use chemicals or abrasive cleaners. Do not spray liquid directly onto the screen.

USER MANUAL CANVAS 27F 165 NZXT

Line drawing of a flat-screen monitor with 'NZXT' label on the front panel (no other text or symbols)

CANVAS 27F 165

27" FHD 165HZ GAMING MONITOR

TABLE OF CONTENTS

VERSION 2, 2023/08/08

PREFACE 01

SAFETY INSTRUCTIONS 05

STABILITY HAZARD INSTRUCTIONS 07

GETTING STARTED 08

PACKAGE CONTENTS 09

MONITOR OVERVIEW 10

MONITOR REAR IO PORTS 11

MONITOR STAND INSTALLATION 12

ADJUSTING THE MONITOR ORIENTATION 16

VESA MOUNT INSTALLATION 17

5-WAY JOYSTICK CONTROL INSTRUCTIONS.... 18

OSD MENU INTRODUCTION 19

SPECIFICATIONS 27

TROUBLESHOOTING (FAQ) 31

SUPPORTED TIMING LIST 35

NZXT GLOBAL WARRANTY POLICY 39

REGULATORY STATEMENT 42

SUPPORT AND SERVICE 44

PREFACE

PREFACIO

PRÉFACE

VORWORT

A. Copyright® NZXT, Inc. All Rights Reserved.

This manual including all illustrations and screen captures, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author.

B. Disclaimer

The information in this document is subject to change without notice. The manufacturer makes no representations or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any person of such revision or changes.

C. Trademark Recognition

Product names used in this manual are the properties of their respective owners and are acknowledged.

D. Safety Precautions

Follow these safety precautions when setting up the monitor:

• Keep this User Manual with the package for future reference.
• Read the safety instructions carefully and thoroughly before using this product

- Setup the device on a reliable flat surface.

- To prevent fire or shock hazard, keep this device away from humidity and high temperature. Do not leave the device in an unconditioned environment with a storage temperature above 60°C or below -20°C, may cause damage to the device. Maximum operating temperature of the device is around 40°C.

- Make sure that the power voltage is within its safety range and has been adjusted properly to the value of 100\~240V before connecting the device to the power outlet. Do not disable the protective earth pin from the plug. The device must be connected to an earthed mains socket-outlet. Do not place anything on the power cord and avoid the power cord from being stepped on.

- Always disconnect the power cord or switch the wall socket off if the device would be left unused for a certain time to achieve zero energy consumption.

- The ventilator on the device is used for air convection and to prevent the device from overheating. Do not cover the ventilator.

- When cleaning the device, be sure to remove the power plug. Use a piece of soft cloth rather than industrial chemicals to clean the device. Never pour any liquid into the opening; that could damage the device or cause electric shock.

• Always keep strong magnetic or electrical objects away from the device.

- It is recommended to take a 10 minute break for every 30 minutes of screen time.

- It is not recommended for children under 2 years of age to have any screen time. For children 2 years and over, screen time should be limited to less than one hour per day.

• Refer servicing to qualified personnel only. If any of the following situations arises, get the device checked by service personnel:

The power cord or plug is damaged.
Liquid has penetrated into the device.
The device has been exposed to moisture.

The device does not work well or you can not get it to work according to the user's manual.

The device has dropped and damaged.

The device has obvious signs of breakage.

Read through the following Safety Precautions before using the monitor

• Make sure that the power voltage is within its safety range and has been adjusted properly to the value of 100\~240V before connecting the device to the power outlet. Do not disable the protective earth pin from the plug. The device must be connected to an earthed mains socket-outlet.
• Only use the accessories that are provided with the monitor or that which are recommended by the manufacturer.
  • Always keep strong magnetic or electrical objects away from the device.
• Keep the plastic packaging bag for the product in a place that cannot be reached by children.
• Do not touch the plug with wet hands, otherwise it can easily cause electric shock.
• Place the monitor in a stable and well-ventilated place.
• Do not place the monitor near any heat sources such as electric radiators or direct sunlight.
• The holes or openings on the monitor are for ventilation. Do not cover or block the ventilation holes with any objects.
• Do not use the monitor near water, drinks, or all types of liquids. Failure to do so may result in electric shock or damage to the monitor.
• Make sure to unplug the monitor from the power outlet before cleaning or remove..
• As the screen surface is easy to be scratched, avoid touching the surface with any hard or sharp object.
• Use a soft lint-free cloth instead of a tissue to wipe the screen. You may use a glass cleaner to clean the monitor if required. However, never spray the cleaner directly onto the screen.
• Always disconnect the power cord or switch the wall socket off if the device would be left unused for a certain time to achieve zero energy consumption.
• Do not attempt to disassemble or repair the monitor yourself.

The product may fall, causing serious personal injury or death. To prevent injury, this product must be securely attached to the floor/wall in accordance with the installation instructions.

• Please use stands or installation methods recommended by the manufacturer of the product set.
• Lay this device on a reliable flat surface before setting it up.
• Please route cords and cables connected to your product so they cannot be tripped over, pulled or grabbed.

- To prevent the monitor from tipping over, secure the monitor to a desk, wall or fixed object with an anti-tip fastener that helps to properly support the monitor and keep it safe in place.

Purple triangular warning sign with exclamation mark (no text or symbols beyond the icon itself)

CAUTION

It is recommended to wear a grounding strap attached to a grounded device to avoid damage from static electricity.

PRECAUCIÓN

Do not use any sharp objects on the monitor.

IMPORTANTE

Blank white rectangle with a thin black border and no visible text, symbols, or markings.

E Power Cable

×1

B Monitor Stand

×1

F Power Adapter

×1

Line drawing of a handheld screwdriver with a rectangular head and threaded shaft (no text or symbols)

C Stand Base

×1

G DisplayPort Cable

×1

Pure electrical connector diagram without any text, numbers, or symbols

D Screws M4L5

×4

Ranura para VESA 100x100

5-WAY Joystick / Power

NZXT ① 2 3 4

DisplayPort HDMI Headphone Jack Power Jack

1. DisplayPort
2. HDMI
3. Jack de auriculares

4. Jack de alimentación

5. DisplayPort

6. HDMI
7. Prise casque

8. Prise d'alimentation

9. DisplayPort

10. HDMI
11. Kopfhörerbuchse
12. Stromanschluss

MONITOR STAND INSTALLATION

INSTALACIÓN DEL SOPORTE DEL MONITOR INSTALLATION DU SUPPORT DU MONITEUR INSTALLATION DES MONITORSTANDFUßES

IMPORTANT

I. Place the monitor on a soft, protected surface to avoid scratching the display panel.
II. The holes for installing the stand can also be used for 100x100 VESA compatible mounts.

IMPORTANTE

Technical diagram of a mechanical assembly with labeled components A, B, C, and D showing exploded view and assembly details.

STEP 1

Carefully hold the stand base (C) and Insert base to the monitor stand (B) with the guiding structure.

Technical line drawing of a mechanical device with internal components and a purple arrow indicating a process (no text or symbols present)

STEP 3

Align and fit the top of the stand to the slot in the rear of the monitor panel (A)

Push down to latch the quick-release mount and lock stand into place. You should hear a clicking sound once it is locked in place.

Carefully lift up the monitor with two hands. Do not use one hand to hold the unit.

To maximize viewing comfort, this monitor includes tilt and swivel adjustments.

VESA MOUNT INSTALLATION

Use the M4L16 screws to mount the monitor panel to the VESA mount.

Technical illustration showing two mechanical assembly states: one with a base plate and directional arrows, the other with a robotic arm mounted on a base plate (no text or symbols present)

STEP 1

Remove screws from display vesa interface.

Install Vesa hinge bracket to display vesa interface with M4L16 screw x4 pcs.

The monitor comes with a 5-way joystick for power and multi-directional control that navigates the monitor OSD (On-Screen Display) Menu.

Simple circular icon with a central power button (no text or symbols)

Source

Fuente

Source

Quelle

Picture Mode

Modo de imagen

Mode d'image

Bildmodus

OSD MENU INTRODUCTION

1st Level Menu 2nd Level Menu 3rd Level Menu Description
Picture	Picture Mode	StandardFPSRTSRPGRacingCinemaProfessionalNight
		HDR Input HDR Source
	Brightness 0-100% Brightness can be adjusted in any Mode
	Contrast 0-100% Contrast can be adjusted in any Mode
	Sharpness 0-10			· Sharpness can be adjusted in any Mode· This improves clarity and details of images
	Color Temperature Cool / Normal / Warm			· Default Color Temperature depends on Picture Mode selected.· Use the Up or Down button to select and preview mode effects.· Press the Center Button to confirm and apply the selected Mode type.· Users can adjust Color Temperature in Customization Mode.
		Customization	R(0-100)G(0-100)B(0-100)
	Gamma Off / 2.0 / 2.2 / 2.4
	Saturation 0-10
	Response Time Normal / Fast / Fastest
	Refresh Rate Off / Upper Right / Upper Left
	MPRT On / Off
	Low Blue Light 0-10			· Low Blue Light protects your eyes against monitor blue light. When enabled, the screen color temperature is adjusted to a more yellow light.· Adjust Low Blue Light in any Mode.· When Reader Mode is On, Low Blue Light will be automatically turned ON.
	Black Equalizer	0-10
	Aspect Ratio	Auto / 4:3 / 16:9

OSD MENU INTRODUCTION

1st Level Menu 2nd Level Menu 3rd Level Menu Description
OSD Settings	Language	Chinese (Traditional) / English / French / German /Italian / Spanish / Korean / Japanese / Russian / Portuguese	Default Language is English.Users can use the Up or Down button to switch to different languages. Center Button to apply new selection.Language is an independent setting. Users’ own language setting will override factory default. When the user sets Reset to Yes, Language will not be changed.
	OSD Transparency 0% /	20% / 40% / 60% / 80% Adjust OSD Transparency in any Mode
	OSD TimeOut 10-60 sec	Adjust OSD TimeOut in any Mode

System Settings

1st Level Menu 2nd Level Menu 3rd Level Menu Description
System Settings	Free Sync Premium On / Off	Default is OFF. FreeSync is a united switch; if HDMI is set to OFF, each input source will also be set to OFF.Only DisplayPort can enable G-Sync compatibility for NVIDIA graphics cards.
	LED On / Off Default is ON. Controls LED indicator light on or off
	Source Detection Auto / Manual Automatically or manually switching between input sources.
	Mute On / Off Default is OFF. Controls 3.5mm audio jack on/off
	Volume	0-100	Default is 50. Controls 3.5mm audio jack volume
	Reset All	On / Off Reset or restore settings to original OSD Default in any Mode.

Input Source

1st Level Menu 2nd Level Menu 3rd Level Menu Description
Input Source	HDMI
	DisplayPort

Monitor Information

1. Source

2. Resolution

3. Refresh Rate

4. FreeSync Premium

5.HDR

6.FW Version

OSD MENU INTRODUCTION

SPÉCIFICATIONS DU PRODUIT

PRODUKTSPEZIFIKATIONEN

Model NZXT Canvas 27F Gaming Monitor
Panel Size 27"
Aspect Ratio 16:9
Flat / Curved Flat
Max. Resolution FHD 1920x1080
LCM Brightness (Typ.) 300 cd/m2
Bezel Type Borderless
Active Display Area (H*V) 597.6 (H) x 332.15 (V)
Color Gamut DCI-P3 92%, sRGB 99%
View Angle (H/V) 178° / 178° (Typ.)
Display Colors 16.7M
Response Time 1ms (GTG)
Adaptive Sync. AMD FreeSync Premium
Panel Refresh Rate 165Hz
Video Input	1x HDMI 2.01x DP 1.2
Headphone Out 3.5mm x1
Power Type	External Adapter (SHENZHEN HONOR ELECTRONIC CO LTD ADS-40SI-19-3 19040E)
Adapter Power Input	100-240Vac, 50-60Hz,1.0A Max
Adapter Power Output	19V ~ 2.1 A
Chassis Colors Black
Power Saving Mode	< 0.5W
Power Off Mode < 0.3W
VESA Compatibility	100 x 100 mmScrew type: M4 x 16mmThis apparatus is intended to be supported by UL listed Wall Mount Bracket.
Viewing	Anti-flickerAnti-glareBlur ReductionBlue light protection
Tilt Adjustment	-5°~+17°
Swivel Adjustment	Left 45°~Right 45°
Dimension with Stand(WxHxD)	615mm x 443.3mm x 188.4mm
Dimension without Stand(WxHxD)	615mm x 367mm x 68.6mm
Box Dimension (WxHxD)	860mm x 166mm x 490mm
Net Weight	5.4kg
Voltage Rating	19V ~ 2.1 A
Environment	Operating:Temperature: 0°C to 40°CHumidity: 20% to 90%, non-condensingAltitude: 0 ~ 5000m
	Storage:Temperature: -20°C to 60°CHumidity: 10% to 90%, non-condensing

SPECIFICATIONS

SPÉCIFICATIONS DU PRODUIT

PRODUKTSPEZIFIKATIONEN

SPÉCIFICATIONS DU PRODUIT

PRODUKTSPEZIFIKATIONEN

SPÉCIFICATIONS DU PRODUIT

PRODUKTSPEZIFIKATIONEN

Problem Possible Solution
Power LED is not ON	Check if the adapter or power cord is correctly and firmly connected or out.If the screen is working without power LED on, check MENU > Other Setting > LED, make sure it is turned to ON.
The power LED light is on but there is no screen image	Check if the operating system had entered sleep or power-save mode. Press the joystick or move the mouse to wake it up.Check if the signal cable (HDMI/DisplayPort/Type-C) is well connected, and confirm another end of the output cable has been firmly connected to the computer input port (graphics card). Unplug and plug 2-terminals again to ensure all pins aren't bent.Replace signal cable (HDMI/DisplayPort/Type-C) to take a cross-testCheck MENU > Input Source, and switch to the correct source.Connect monitor to the other computers (PC/Notebook) to confirm whether it is normalReset the monitor, MENU > Other Setting > Reset All.
Screen image is too light or dark Check and set MENU > Image > Brightness, the larger value means lighter.
Screen image bounces or a wave pattern is present in the image	Check and set MENU > Image > Sharpness.Check MENU > Image > Response time and switch Normal/Fast/Fastest mode.Check MENU > Image > MPRT and switch OFF/ON.Check MENU > Other Setting > FreeSync Premium and switch OFF/ON and check if the abnormal display disappeared.
Screen image has color defects (white does not look white)	Check MENU > Image > Color Temperature and switch Cool/Normal/Warm.Check and set Color Temperature > Customization > R/G/B.If it still does not look “white” enough, reset the monitor, MENU > Other Setting > Reset All, and try the above actions again.
Setting and changing display refresh rate	Default display refresh rate setting is 60HzTo change display refresh rate settings:Right click on Windows desktopSelect “Display Settings” from the drop downScroll down and select “Advanced Display Settings”Select the display to view or change the settings for itSelect Refresh Rate settingNote - To use display in portrait mode, follow above steps to change display refresh rate settings prior to changing display orientation to portrait mode. You will not be able to change the refresh rate settings while in portrait mode.

TROUBLESHOOTING (FAQ)

This NZXT Global Warranty Policy governs the sale of products by NZXT to you.

I. WARRANTY LENGTH

New NZXT Product Warranty Length

Monitor 3 Years

Any replacement product will be covered under warranty for the remainder of the warranty period or thirty days, whichever is longer. Proof of purchase is required for warranty service.

II. WHO IS PROTECTED

The Warranty covers only NZXT products purchased by the original consumer.

III. WHAT IS AND IS NOT COVERED

Please note that our warranty is not an unconditional guarantee. If the product, in NZXT's reasonable opinion, malfunctions within the warranty period, NZXT will provide you at its sole discretion with a repaired or replacement product, either new or refurbished, with a similar function that is equal or greater in value depending on supply. Our warranty does not cover the following:

• any product or serial number/warranty sticker modification applied without permission from NZXT;
• any damage that is not a manufacturing defect;
• damage, deterioration or malfunction resulting from: accident, abuse, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification or failure to follow instructions included with the product;
• improper installation, unauthorized alterations or modifications, or repair or attempted repair by anyone not authorized by NZXT;
• shipping or transport damage (claims must be made with the carrier);
• normal wear and tear.

NZXT does not warrant that this product will meet your requirements. It is your responsibility to determine the suitability of this product for your purpose. For NZXT Store orders, we cover two way return shipping for all exchanges and returns. For all other authorized dealers, NZXT Support does not cover return shipping and only covers one way shipping from NZXT back to the end user for exchanges. Two way expedited shipping is provided for all PSUs covered under the Less Than Three program, indiscriminate of purchase location, provided the location is an approved NZXT reseller.

IV. EXCLUSION OF DAMAGES (DISCLAIMER)

NZXT's sole obligation and liability under this warranty is limited to the repair or replacement of a defective product with either a new or refurbished product with a similar function that is equal or greater in value at our option. NZXT shall not, in any event, be liable for any incidental or consequential damage, including but not limited to damages resulting from interruption of service and loss of data, business, or for liability in tort relating to this product or resulting from its use or possession.

V. LIMITATIONS OF IMPLIED WARRANTIES

There are no other warranties, expressed or implied, including but not limited to those of merchantability or fitness for a particular purpose. The duration of implied warranties is limited to the warranty length specified in Paragraph I.

VI. TO OBTAIN TECHNICAL SUPPORT

If you have already referenced your product owner's manual and still need help, you may contact us by phone at [phone], by email at [e-mail], or visit the NZXT Support site at nzxt.com/customer-support.

VII. HOW TO OBTAIN A WARRANTY SERVICE FROM NZXT

To receive a warranty service for your product when purchased directly from NZXT, you must submit a request via the NZXT Support site outlining the problem. If a technician deems the product defective or requiring testing, you will be required to provide a copy of your proof of purchase, which will enable you to submit a Return Merchandise Authorization "RMA" request.

Once approved, you'll receive an RMA number, upon which you will be asked to ship the defective item back to NZXT with the RMA number clearly marked or labelled on the package. NZXT recommends that appropriate measures are taken to safeguard the product from damage during shipping.

VIII. APPLICABLE LAW AND ADDITIONAL LEGAL RIGHTS FOR CONSUMERS

This warranty gives you specific legal rights. These conditions are governed and construed in accordance with the laws of California (with exception of its conflict of law provisions), and the application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded. The non-exclusive jurisdiction of the courts of California is agreed, which means that you may bring a claim to enforce your consumer protection rights in connection with this Global Warranty in the country which you have your habitual residence where you may have additional rights. These rights may vary.

For original consumers who are covered by consumer protection laws or regulations in their country, state, or province of purchase or, if different, their country, state, or province of residence, the benefits conferred by this warranty are in addition to all rights and remedies conveyed by such consumer protection laws and regulations. To the extent that liability under such consumer laws can be limited, NZXT's liability is limited, and its sole option, to repair or replacement, either new or refurbished, with a similar function that is equal or greater in value depending on supply.

In the United Kingdom:

• For NZXT products sold to customers in the UK, during the expected lifespan of your product your legal rights entitle you to the following:

Up to 30 days: if your goods are faulty, then you can get an immediate refund.
Up to six months: if your goods can't be repaired or replaced, then you're entitled to a full refund, in most cases.
Up to six years: if your goods do not last a reasonable length of time you may be entitled to some money back.
- If the person seeking to rely on the guarantee is not the original consumer, the NZXT Warranty will cover the product in relation to that person provided that they are able to provide proof of the transfer of the benefit of the guarantee from the original consumer.
- The implied warranties under the Consumer Rights Act 2015 says that your goods must be as described, fit for all purposes for which such goods are usually supplied, and of satisfactory quality.

In the EU:

- If you are a consumer and have your habitual residence in the EU, you additionally enjoy the protection afforded to you by provisions that cannot be derogated from by agreement by virtue of the law where you have your habitual residence.

IX. WARRANTY SERVICE FROM RESELLERS

In the event that a warranty service is sought, you must provide proof of purchase (store receipt or invoice) in order to receive the service and if deemed necessary, repair or replacement product.

In North America:

Within the first 60 days after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval and an RMA number.

In Europe:

Within the first year after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval.

In Australasia:

Within the first two years after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval.

The cost of shipping will be borne at the first instance by you; however, if the purchased item is defective, NZXT will reimburse reasonable postage or transportation of costs.

Outside North America, Europe, and Australasia:

If your product needs to be returned within the warranty period, please contact the retailer or distributor from whom you purchased the product.

X. NZXT.COM STORE RETURNS/EXCHANGE POLICY

Eligible products under this NZXT Warranty qualify for a full refund or exchange only with an authorized RMA number and if the item is returned to the NZXT.com store inventory within 30 days of purchase. Returns are not allowed beyond 30 days of the purchase date. The NZXT.com Store reserves the right to deny any return or exchange. Refunds will be credited to the original method of payment. To initiate a return, simply submit a request via NZXT support site.

Visit nzxt.com/warranty and support.nzxt.com for information on warranty coverage and service.
Visite el sitio Web nzxt.com/warranty y support.nzxt.com para obtener información sobre la cobertura y el servicio de la garantía.
Visitez nzxt.com/warranty et support.nzxt.com pour les informations de la couverture de la garantie et du service.
Informationen zu Geltungsbereich und Service der Garantie finden Sie unter support.nzxt.com und nzxt.com/warranty.
Visitare il sito nzxt.com/warranty e support.nzxt.com per informazioni sulla copertura e sul servizio della garanzia.
Visite nzxt.com/warranty e support.nzxt.com para obter informações sobre a cobertura da garantia e assistência.
제품 보증 범위와 서비스 정보를 확인하시러면 nzxt.com/warranty 또는 support.nzxt.com을 방문해 주시기 바랍니다.
保証範囲およびサービスに関する情報については、support.nzxt.comとnzxt.com/warrantyにアクセスしてください。
请造访 nzxt.com/warranty 和 support.nzxt.com 了解保修范围和服务的信息。
請訪問 nzxt.com/warranty 和 support.nzxt.com 了解產品保固範圍和更多服務訊息。

NZXT, Inc. | 15736 E. Valley Blvd, City of Industry, CA 91744, USA

NZXT UK Ltd. | First Floor 5 Fleet Place London EC4M 7RD, GB United Kingdom

[phone] / [e-mail] / nzxt.com

REGULATORY STATEMENT

This product is compliant to implemented RoHS (Restriction of Hazardous Substances) type regulations worldwide, including but not limited to China, India, Japan, Korea and European Union.

REACH STATEMENT

EU REACH SVHC Disclosure on Candidate List

REACH (Registration, Evaluation, Authorization and Restriction of Chemicals, EC 1907/2006) is the European Union's (EU) chemical substances regulatory framework. REACH requires NZXT Inc. to provide customers with sufficient information on Substances of Very High Concern (SVHC) contained in products in concentration above 0.1% weight by weight (w/w) to allow safe use of the product.

DECLARATION OF CONFORMITY

The device complies with the requirements set out in the Council Directives relevant Union harmonisation legislation:

• EMC Directive 2014/30/EU
• RoHS Directive 2011/65/EU & (EU) 2015/863
• LVD Directive 2014/35/EU

DÉCLARATION DE CONFORMITÉ

KONFORMITETSDEKLARATION

To protect the global environment and as an environmentalist, NZXT must remind you that:

Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005, products of “electrical and electronic equipment” cannot be discarded as municipal waste anymore and manufacturers of covered electronic equipment will be obligated to take back such products at the end of their useful life. NZXT will comply with the product take back requirements at the end of life of NZXT-branded products that are sold into the EU. You can return these products to local collection points.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-003(B) / NMB-003(B)

SUPPORT AND SERVICE

SUPPORT AND SERVICE

If you have any questions or problems with the NZXT product you purchased, please don't hesitate to contact us using our support system. [e-mail] support.nzxt.com

Please include a detailed explanation of your problem and your proof of purchase. For comments and suggestions, you can e-mail our design team, [e-mail].

Lastly we would like to thank you for your support by purchasing this product. For more information about NZXT, please visit us online. NZXT Website: NZXT.com

SOPORTE Y SERVICIO

NZXT, Inc. | 15736 E. Valley Blvd, City of Industry, CA 91744, USA

NZXT UK Ltd. | First Floor 5 Fleet Place London EC4M 7RD, GB United Kingdom

[phone] / [e-mail] / nzxt.com
