USER MANUAL TVB123M Duronic

Creative Consumer Products

DURONIC water heater with control panel and lid, no visible text or symbols on the device itself.

YM2 Yogurt Maker

duronic.com

duronic

@duronicmedia

Duronic

@duronicmedia

DURONIC

DURONIC

Contents

English Manual 5

A reminder to the user about high voltage.

Warning symbol

A reminder to the user about the necessity of operating according to the instructions.

When using electrical appliances, you should take the following precautions:

• Use the device according to the instruction manual.
  • Always place the device on a stable surface.
• Use the tools which are included with the device.

Please keep the cord away from liquids to protect against the risk. of electrical shock.

- Keep the device away from flammable substances to avoid the risk of fire.

Never attempt to open the device by yourself as this may damage the appliance and void your warranty.

- Please wait 1-2 hours before turning the device on if it's moved from a cold area to a hot area and vice versa.

In order to prevent electrical shock, keep the appliance away from water and never submerge the base or cord under water.

• Be careful when using the device around children.
• Do not touch any hot surfaces, as this may cause injury. Always handle the appliance with gloves.
• Do not allow the cord to hang over the edge of the table or touch any hot surfaces.
• Do not connect this device to an extension lead which is used with other appliances, it can lead to the device not functioning properly.
• Do not place the device near gas/electric stoves or ovens.
• Please make sure to disconnect the device from the power socket after use.

DURONIC

• Please do not drop the device.
• Please make sure you disconnect the device from the power socket while cleaning or changing accessories.
• Do not use this device outdoors.
• This device is not intended for use by anyone (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge. They should only use the device under the supervision of the person responsible for their safety. Do not allow children to play with the product.
  • This product is intended for domestic use only.
• If the power cord is damaged, it must be replaced by a specialist or the manufacturer in order to avoid harm.
• Do not use abrasives and cleaners (alcohol, gasoline, etc.) when cleaning the device. You are allowed to use small amounts of neutral detergents to clean the device.

Recommendations

• Please keep the manual after reading for further use.
• All illustrations in this manual are schematic representations of the device, which may differ from the actual images.
• Be careful when using ceramic containers as it is a fragile material that is subject to breaking.
• Please do not move or open the device while it is switched on.
• Make sure the device is operated on a flat and stable surface.

Do not apply excessive force to the device as this may result in misuse and will void the warranty

What's In The Box?

Body - 1 pc

Lid - 1 pc

Ceramic container, 125 ml - 8 pc

220 V A 1 2 B C ✓ ✓ ✓ ✓ ✓ ✗ ✓ ✓ ✓ ✗ ✗ ✓ ✓ ✗ ✗ ✓

8
DURONIC

Features

Utilization

Control panel, fig. B-2

On/off button timer button

Cooking time indication

Yogurt maker operation indicator

Temperature indicator

Getting Started

First use: Please clean the containers along with the lids before using the device for the first time. They can be cleaned using warm soapy water and dried with a soft cloth.

Operating Instructions:

1. Place your ingredients into the containers and make sure the caps are firmly closed. Place the containers into the device and close the lid.
2. Connect the power cord to the device.
3. Plug the device into a power socket.
4. Set the preset time with the ⏻ button (Yogurt Mode -10/maximum up
   to 24 hours).
5. Press button to start cooking.
6. Press the button again to cancel or switch off.
7. A red indicator will light up first – indicating that the device is warming up. This is followed by a green light as soon as the device reaches the temperature required to operate.
8. When the cooking is finished, you will hear a beep and "00:00" will be displayed.
9. Switch the device off. Unplug it and remove the containers. Wait until the containers are cool then place them into your refrigerator.
   NOTE: You can store yogurt in the refrigerator up to 8 days.

9

Preparation Recommendations

Product Leaven	Milk	Requirements	Cooking Time	Amount Note
Powder Milk Yogurt	Yogurt Powder milk 8-12 hours
Natural Yogurt	Yogurt Sterilized, pasteurized, UHT and heat-treated milk of any fat content	6-10 hours	Based on your preference	Rich taste depends on fat content of milk
Greek Yogurt	Yogurt Sterilized, pasteurized, UHT and heat-treated milk of any fat content	8-15 hours	Prepared Based on your preference	yogurt is recommended to filter using gauze or linen napkins to drain the whey
Natural Yogurt (based on a pre-prepared yogurt)		Sterilized, pasteurized, UHT and heat-treated milk of any fat content	6-10 hours	25 ml of yogurt for every 1.125 liters of milk	Prepare yogurt with this method no more than 5 times, then renew the leaven
Turkish Yogurt	Yogurt Sterilized low fat cream	6-10 hours	Based on your preference	You can use diluted milk cream, pre-boiled and then cooled to 40^ C

1. Please clean the containers before every use. Kitchenware should always be sterilized before use for health and safety.
2. Always wash your hands before any form of cooking.
3. Follow the recommendations in the instruction manual and recipe book
4. It is not recommended to add nuts, grains, dried fruits, fresh fruit
   and vegetables without pre-treatment. This increases the rise of harmfulmicroorganisms in the fermentation process. It is safer to add them into the finished product.
5. If the yogurt is too thin, increase the amount of leaven or increase the fermentation time.
6. If you are using fruit, please do not wipe them dry. This removes the wax layer from the fruit. It is better to let fruit dry naturally.
7. Use room temperature milk.
8. Use only fresh and quality ingredients to prepare yogurt and dairy products.
9. Use special dried leaven or buy a simple yogurt without additives to prepare yogurt.
10. When adding ingredients, please keep in mind that in the process of fermentation, the volume will increase.
11. Overloading can result in spillage and leaking into the device itself.

Cleaning And Maintenance

Problems Possible cause Solutions
Display does not light up. No power supply Check the socket to see if it is switched on/working.
Temperature is not rising.	Heating element malfunction Contact Duronic.
Yogurt is not fermented enough, or over fermented.	Cooking time isn't set correctly.	Follow the recommendations in the recipe. Consider the temperature of the ingredients. The longer the cooking time, the more sour the yogurt will be.

DURONIC

The inner surface of the fermenter got dirty with the ingredients from the jar and/or the lids were blown off the jar and body of the fermenter.	Jars were overloadedCooking time set too long.	When placing the ingredients into the container, take into consideration that the volume will increase in the fermentation process. Control the cooking time. Beginners must note and record the optimal mode.
Setting reset Power failure occurred. Check the quality of the		products, if they are not spoiled and little time had passed after disconnecting, set the required mode again.

Specifications

Specifications
MODEL YM2
Capacity, ml 125
Number of cooking containers 8
Container material Ceramic
Power consumption, W max 20
Rated voltage 220-240 V~; 50-60 Hz
Level of protection II
Storage and transportation temperature* -25 °C to +35 °C
Operating temperature from +5 °C to +35 °C
Humidity requirements 15-75%
Dimensions, mm 268x240x166
Weight, kg 1,89

DURONIC

Warranty

1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products. NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A CONSUMER

This product has been manufactured under the strictest or quality control procedures, and using the highest quality of materials, to ensure excellent performance and reliability. It will give very good and long lasting service, provided it is properly used and maintained. The product is guaranteed for 1 years from the date of original purchase. If any defect arises due to a faulty materials or poor workmanship, the faulty product must be returned to the original place of purchase. Refund or replacement is at the discretion of that company. Duronic Products are offered with a 1 year guarantee under the following conditions:

1. The product must be installed and used in accordance with the instructions contained in
   this operating manual.
2. It must be used only for domestic purposes.
3. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or consumable parts.
4. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
5. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
6. Valid in the UK only

This product is fitted with CE:1363 plug and fuse Imported by Shine-Mart Ltd, RM3 8SB

Information on waste Disposal for Consumers of Electrical & Electronic Equipment.

This mark on a product and/or accompanying documents indicates that when it

is to be disposed of, it must be treated as Waste

Electrical & Electronic Equipment, (WEEE).

Any WEEE marked products must not be mixed with general household waste,

but kept separate for the treatment, recovery and recycling of the materials use

For proper treatment, recovery and recycling; please take all WEEE marked waste to usual oral authority. Civis waste site

waste to your Local Authority Civic Waste site,

Where it will be accepted free of charge. If customers dispose of Waste Electrical & Electronic Equipment correctly, they

If customers dispose of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable resources and preventing any potential negative

reflects upon human health and the environment, of any hazardous materials that

the waste may contain.
