Product type Battery charger for Li-Ion batteries
Brand Hilti
Model C 4/12-50
Weight 0.35 kg
Nominal output voltage 10.8 V
Output power 50 W
Power supply 100-127 V or 220-240 V AC, depending on national version
Compatible battery type Hilti 10.8 V Li-Ion batteries
Status display 2 LEDs (LED 1 and LED 2) indicating charging, fault, temperature
Main functions Fast charging, overheat and undervoltage protection, automatic shut-off at end of charge
Maintenance and cleaning Disconnect before cleaning; use a damp cloth; brush the ventilation slots
Safety Double insulation, short-circuit protection, shut-off if battery is too hot/cold
Spare parts and repairability Repair exclusively by Hilti customer service; use original parts
Warranty Manufacturer's warranty (contact your local Hilti partner)
General information Indoor use only; operating temperature: avoid frost and excessive heat

Frequently Asked Questions - X-IE-GSP HILTI

How to charge a battery with the Hilti X-IE-GSP charger?
Plug the charger into a suitable power outlet. LED 1 lights up green. Insert the Hilti Li-Ion battery into the charger until it clicks into place. Charging starts automatically. LED 2 flashes green during charging. Once the battery is fully charged, both LEDs are lit green.
What to do if LED 1 flashes red and LED 2 is off?
This means the battery is too hot or too cold and cannot be charged. Let the battery cool down or warm up to room temperature. The charger will automatically switch to the charging process once the correct temperature is reached.
Can I charge other types of batteries with this charger?
No, this charger is designed exclusively for Hilti Li-Ion batteries with a nominal voltage of 10.8 V. Using other batteries may cause a fire or damage the charger.
How to clean the Hilti X-IE-GSP charger?
Always unplug the charger before cleaning. Use a slightly damp cloth to clean the housing. For the ventilation slots, use a dry, soft brush. Do not use silicone-based cleaners.
What to do if the charger LEDs remain off?
First, check that the power outlet is powered. If the LEDs remain off, the charger is probably defective. Contact Hilti customer service for repair.
What is the weight of the charger?
The charger weighs 0.35 kg.
What is the output voltage of the charger?
The nominal output voltage is 10.8 V.
Can I use an extension cord with the charger?
Yes, but only use an extension cord approved for outdoor use if necessary. Make sure it is in good condition and suitable for the charger's power.
How to know if the battery is fully charged?
When the battery is fully charged, LED 1 and LED 2 on the charger are lit green. You can also check the charge status on the battery itself using its built-in LEDs.
Where can I find spare parts for the charger?
Original spare parts and accessories are available from your local Hilti Store or at www.hilti.group. For repairs, contact Hilti customer service.
