Performance 463229021 - Grill plate CHAR BROIL - Free user manual and instructions
Find the device manual for free Performance 463229021 CHAR BROIL in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | 6-Burner Gas Grill |
| Brand | CHAR BROIL |
| Model | Performance 463229021 |
| Fuel | Propane (LPG) with 20 lb cylinder |
| Number of Main Burners | 6 |
| Side Burner | Yes |
| Sear Burner | Yes (depending on model) |
| Ignition | Electronic (AAA and AA batteries) and match |
| Material of Firebox and Lid | Porcelain-coated steel |
| Material of Cooking Grates | Stainless steel or porcelain |
| Dimensions (L x W x H) | Approximately 152 cm x 76 cm x 117 cm |
| Weight | Approximately 45 kg |
| Maximum Side Shelf Capacity | 10 lb (4.5 kg) |
| Cooking Functions | Direct, indirect, rotisserie cooking |
| Grease Collection System | Removable drip tray |
| Safety | Regulator safety device, mandatory leak test |
| Maintenance | Regular cleaning of burners and surfaces |
| Warranty (stainless steel burner) | 5 years (perforation, manufacturing defect) |
| Warranty (firebox and lid) | 2 years |
| Warranty (other parts) | 1 year |
| Compatible Accessories | GearTrax™ (rotisserie kit, etc.) |
| Country of Manufacture | China |
Frequently Asked Questions - Performance 463229021 CHAR BROIL
What type of gas to use with this grill?
This grill is designed to operate exclusively with propane (LPG). Use a 20 lb (approximately 9 kg) cylinder equipped with a Type 1 valve with overfill prevention device.
How to light the grill?
Open the lid, open the gas cylinder valve, push and turn the ignition burner knob to HIGH, then press the electronic ignition button. If the burner does not light within 5 seconds, turn off the gas, wait 5 minutes and try again.
What to do in case of gas smell?
Immediately shut off the gas supply at the cylinder, extinguish any open flame, open the lid and evacuate the area. If the smell persists, move away and call the fire department or your gas supplier. Do not create sparks.
How to clean the burners?
Turn off the gas and remove the grates and burner covers. Disconnect the burner tubes, clean the inside of the tubes with a stiff wire or brush, and brush the outside. Check that each orifice is clear. Regularly inspect for spider webs.
Why does the grill heat poorly (max 250-300°F)?
This indicates that the regulator safety device has been activated. To reset: close all knobs and the cylinder valve, disconnect the regulator, wait 30 seconds, reconnect, slowly open the cylinder valve, then light the grill.
Can I use charcoal or briquettes in this gas grill?
No, this grill is designed for gas use only. Adding charcoal, briquettes, or lava rocks can reduce combustion, increase fire risks, and void the warranty.
How to store the grill?
Clean the cooking grates. If the gas cylinder is connected, store the grill outdoors in a dry, well-ventilated area. If you wish to store it indoors, disconnect and remove the gas cylinder and store it outdoors, out of reach of children.
What is the warranty of this grill?
The stainless steel burner is warranted for 5 years against perforation and manufacturing defects. The firebox and lid are warranted for 2 years, and other parts for 1 year. The warranty is valid for the original purchaser in the United States and Canada. Keep your receipt.
How to check for gas leaks?
Perform a leak test outdoors, with no open flame. Prepare a solution of water and mild soap, brush it over the connections (valve, regulator, hose) and open the cylinder valve. If bubbles appear, there is a leak: turn off the gas and tighten the connections or replace defective parts.
What accessories are compatible with this model?
This grill is compatible with Char-Broil's GearTrax™ accessory line, including rotisserie kits, racks, etc. Visit charbroil.com for the full list. All accessories must be approved by the manufacturer.
