USER MANUAL ProClean 8110 Full Inox CECOTEC

1. Parts and components 47

4. Cleaning and maintenance 55

5. Technical specications 56

6. Disposal of old electrical appliances 56

7. Technical support and warranty 56

1. Door safety lock system

2. Combination/Grill

- Take the product out of the box. If the microwave has a protective lm, tear it off before starting operation. Check carefully if there is any damage, and if there is, immediately notify the Technical Support Service of Cecotec. - The product must be placed on a at, stable and dry place and kept away from corrosive materials, heat and humidity, such as gas burners or water. - To ensure enough ventilation, minimum distances have to be kept: - From the back part to the wall: 10 cm. - From the side to the wall: 5 cm. - Free distance from the top surface: 20 cm. - From the microwave to the ground: 85 cm. - The product must be placed, at least, at 5 m from the TV, Radio or antenna. - The product must be placed in such way that the plug is accessible and must ensure an effective grounding in case of leakage in order to avoid electric shocks. - The microwave door must be closed in order to operate. - In case there is any manufacturing rests in the microwave cavity or on the heating elements,PROCLEAN 9110 FULL INOX

ENGLISH leave the microwave open to ensure good ventilation. In such case, it is recommended to heat a glass of water at high power for several times.

Control panel Fig.3 Before cooking Connect appliance to power outlet. Once it is connected, the LED light will ash 3 times and will show 1:00. Select a function. Time/weight knob Cooking time and food weight can be increased or decreased during operation, depending on the mode, by turning the Time/Weight knob. Pause/Cancel - Before operation: Press once in order to reset settings and return to to initial stage. - During operation: Press once in order to interrupt operation or press twice in order to cancel pre-set cooking program. Reminder Once the pre-set cooking process is over, it will say END on the LED display panel and the microwave will beep 3 times. Press Pause/Cancel button or open the microwave door in order to stop the alarm, if not, the alarm will sound at an interval of 3 minutes. Instant cooking From the initial position, press the Start button, the microwave will automatically operate at high power for 1 minute. Cooking time can be increased or decreased during operation by turning the Time/Weight knob. Clock/timer setting Use the Defrost/Clock button to set the time (by holding down the button for 3 seconds) and to set the Defrost mode (press once).PROCLEAN 9110 FULL INOX

ENGLISH Example: Setting clock at 12:30 Steps Display 1 After powering up, the display panel shows the colon sign. 1:00 2 Hold down the Defrost/Clock button for 3 seconds. 1:00 3 Turn the Time/Weight knob to set the exact hour. 12:00 4 Press the Defrost/Clock button once. 12:00 5 Turn the Time/Weight knob to set the exact number of minutes. 12:30 6 Press the Defrost/Clock button once again to conrm the selected time or wait for 5 seconds, time will be set automatically. Microwave cooking Use this function in order to cook or heat food. Press the On button and select on the LED display panel between: 100P-80P-60P-40P-20P. High power 100 % microwave power. Perfect for fast and efcient cooking. Medium-High power 80 % microwave power. Perfect for medium express cooking. Medium power 60 % microwave power. Perfect for steaming food. Medium-Low power 40 % microwave power. Perfect for defrosting food. Low power 20 % microwave power. Perfect for keeping food warm. - Microwave function can be set up to 60 minutes. - Cooking or heating time may be changed during operation. It is recommended to turn or stir food at least once during the process. Press the Start button once to resume operation. - If food is removed before the pre-set time, make sure you press Pause/Cancel once in order to stop operation and avoid the microwave from operating automatically and empty when closed. - When operating at maximum power, the microwave will automatically lower power after a certain time in order to lengthen the appliance’s shelf life.PROCLEAN 9110 FULL INOX

ENGLISH Example: Cooking at P80 for 10 minutes. Steps Display 1 After powering up, the display panel shows: 1:00 2 Select the desired microwave power by pressing the On button consecutively. 80P 3 Turn the Weight/Time knob to select the desired cooking time. 10:00 4 Press the Start button to start operation. The LED will display the countdown. Grill and Combination Press once the Grill/Combi button in order to select grill or combination function. The LED display panel will show 3 modes, turn the Weight/Time knob to select the desired one: G (Grill) Only heating elements will be energised during operation. Perfect for cooking sausages, pork, chicken wings… C.1 Combines 30 % microwave operation and 70 % grill operation. C.2 Combines 55 % microwave operation and 45 % grill operation. Example: Grilling food on C.2 mode for 10 minutes. Steps Display 1 After powering up, the display panel shows the colon sign. 1:00 2 Press the Grill/Combi button to select the mode. C.2 3 Set the cooking time by turning the Time/Weight knob. 10:00 4 Press the Start button once to resume operation. Defrost Function designed to defrost different types of food. Press the Defrost/Clock button once and turn the Weight/Time knob to select the Defrost mode:PROCLEAN 9110 FULL INOX

ENGLISH d.1 Perfect for defrosting meat (0.1 kg-2.0 kg) d.2 Perfect for defrosting poultry (0.2 kg-3.0 kg) d.3 Perfect for defrosting sh/seafood (0.1 kg-0.9 kg) When the LED displays the desired programme, press the Defrost/Clock button again and turn the Time/Weight button to set the weight of the food to be defrosted. Press the Start button to start the process. - It is highly recommended to turn over food during operation on order to obtain a uniform effect. - Usually defrosting will need longer time than cooking food. - If the food can be cut by knife, the defrosting process can be considered completed. - Microwave radiation penetrates around 4 cm into most foods. - Defrosted food should be used as soon as possible. It is not recommended to freeze or put back in the fridge again. Example: Defrosting 0.5 kg of chicken Steps Display 1 After powering up, the display panel shows the colon sign. 1:00 2 Press the Defrost/Clock button to set the food defrost type. 3 Press the Defrost/Clock button to set the weight. d.2 4 Turn the Defrost/Clock knob to set food weight.

5 Press the Start button once to resume operation. 6 During the defrosting process, an alarm will sound in order to remind you to turn over the food. Turn over food, close the door and press the Start button again to resume the defrosting process. Auto cooking The microwave has 8 default programmes, select the most appropriate one according to thePROCLEAN 9110 FULL INOX

ENGLISH food type and weight. Press the Auto Cooking button consecutively, the LED display panel will show different programmes. Use the Weight/Time knob to select one of the following: Display Food Dish A.1 Popcorn Perfect for cooking 85 g of popcorn. A.2 Reheat Perfect for reheating from 0.2 to 1 kg of food. A.3 Liquids Perfect for heating 250 ml of liquid. Liquid must be between 5 ºC and 10 ºC. Do not seal the liquid container. A.4 Pizza Perfect for heating 1 or 2 pizza slices. A.5 Potato Perfect for cooking potato cubes (5 mm height and width), 0.45-0.65 kg maximum. Place potato cubes on a large tray or container and cover it with a thin lm to prevent water loss. A.6 Frozen dinner Perfect for heating cooked food. A.7 Rice Perfect for cooking 0.1-0.5 kg of rice. A.8 Vegetables Perfect for cooking 0.1-0.5 kg of vegetables. - Before cooking or heating food, its temperature must be about 20-25 ºC. Higher or lower temperature of the food before cooking would require increasing or decreasing cooking time. - Food’s temperature, weight and shape will strongly inuence the microwave effect on the cooking process. Adjust time in order to obtain the best result. Example: Cooking 0.5 kg of rice Steps Display 1 After powering up, the display panel shows:

ENGLISH 2 Press the Auto Cooking button to set cooking mode. A.7 3 Set food weight by turning the Time/Weight knob.

4 Press the Start button to start operation. The LED will display the countdown. Automatic start This function allows you to set cooking program and time, so at the pre-set time, the pre-set programme will automatically start operating. In order to activate this mode:

Example: It is 12:30 and you want to programme the microwave at 80 P, for 9 minutes and 30 seconds at 14:20. Steps Display 1 After powering up, the display panel shows: 1:00

1.1 Hold down the Defrost/Clock

button for 3 seconds. 1:00

1.2 Set hour by turning Time/

button again to conrm the hours. 12:00

1.4 Set the minutes by turning

button to conrm the set time or wait for 5 seconds for the microwave to set it automatically. 12:30 2 Set the cooking programme and cooking time.

2.1 Select power by pressing the

set the cooking time.

button for 3 seconds. 3 Set the time you expect cooking to start and repeat steps 1.2, 1.3, 1.4. 4 Press the Defrost/Clock button to conrm the selected cooking programme. Now the program has been activated and operation will start at 14.20. 5 You may check the pre-set starting time by pressing the Defrost/Clock button. Multi-sequence cooking In order to obtain the best result, some recipes require of different steps. This function allows you to personalise and to combine your cooking processes. Example: It is 12:30, you want to program the microwave at P 80 for 9 minutes and 30 seconds at 14.20. Steps Display 1 Select 100 P microwave for 3 minutes.

1.1 Press the On button to select

the desired power level. 100P

1.2 Set the cooking time by

to select the Grill mode.

2.2 Set the cooking time by

turning the Time/Weight knob. 9:00 3 Press the Start button to start operation. - When the microwave function is nished, grilling function will operate automatically. - Maximum 4 sequences can be set at a time. If more sequences are required, repeat stated steps.PROCLEAN 9110 FULL INOX

ENGLISH Safety child lock Security system that blocks control panel to ensure small children do not use the appliance without supervision. - To activate lock: Hold the Pause/Cancel button for 3 seconds. - To deactivate lock: Hold the Pause/Cancel button for 3 seconds. Microwave cooking tips - Food arrangement: Place the thickest food parts towards the edge of the glass tray. If possible, do not overlap food. - Watch cooking time: Cook for the shortest amount of time at rst, and add more minutes in case it is necessary. Over-cooking may result in smoke and burns. - Cover food while cooking: Covering the food you are going to cook avoids spattering and allows for a more even cooking. - Flip or stir food once during the cooking process. - Respect pre-heating time. Pre-heating time specied on the food’s label must not be exceeded.

The device, as well as food rests, must be cleaned and removed regularly. - The device, as well as food rests, must be cleaned and removed regularly. - Disconnect the power cord from the wall socket before cleaning. Do not immerse the product in water or any other uid during cleaning. - Failure to maintain the product in clean conditions could lead to surface deterioration and could adversely affect the product’s shelf life, resulting in possible hazard. - Never use strong detergents, abrasive powder or metal brush to clean any part of the product. - Do not remove the wave guide. - When the microwave has been used for a long time, some strong odours may arise from inside. To eliminate these odours, follow one of the below methods: - Place several lemon slices in a cup and heat them at high power for 2 or 3 minutes. - Place a cup of red tea inside the microwaves and heat it at high power for 2 or 3 minutes. - Place orange peels inside the microwaves and heat it at high power for 1 minute. - Use a dampened soft cloth to clean enclosures, door, interior walls and the door frame.PROCLEAN 9110 FULL INOX

Product reference: 01544 Product: ProClean 9110 Full Inox Microwave power: 1000 W Grill power: 1000 W Voltage and frequency: 230 V, 50 Hz Capacity: 30L Made in China | Designed in Spain

6. DISPOSAL OF OLD ELECTRICAL APPLIANCES

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), species that old household electrical appliances must not be disposed of with the normal unsorted municipal waste. Old appliances must be collected separately, in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation to dispose of the appliance correctly. Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

7. TECHNICAL SUPPORT AND WARRANTY

This product is under warranty for 2 years from the date of purchase, as long as the proof of purchase is submitted, the product is in perfect physical condition, and it has been given proper use, as explained in this instruction manual. The warranty will not cover the following situations: The product has been used for purposes other than those intended for it, misused, beaten, exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault attributable to the customer. The product has been disassembled, modied, or repaired by persons, not authorised by the ofcial Technical Support Service of Cecotec. Faults deriving from the normal wear and tear of its parts, due to use. The warranty service covers every manufacturing defects of your appliance for 2 years, based on current legislation, except consumable parts. In the event of misuse, the warranty will not apply. If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact Cecotec Technical Support Service at [phone].PROCLEAN 9110 FULL INOX
