WB 18 LTX BL 15125 Quick - Sander METABO - Free user manual and instructions
Find the device manual for free WB 18 LTX BL 15125 Quick METABO in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Brand | Metabo |
| Model | WB 18 LTX BL 15125 Quick |
| Product type | Cordless angle grinder |
| Power source | Li-Ion 18 V battery (CAS - Cordless Alliance System) |
| Max. accessory diameter | 125 mm |
| No-load speed (max) | 8500 rpm |
| Adjustable speed | Yes, via wheel (depending on version) |
| Spindle thread | M14 |
| Weight (with smallest battery) | 2.5 kg (approx.) |
| Quick clamping system | Quick (Quick clamping nut) |
| Additional handle | Yes, with vibration damping |
| Guard | Supplied, tool-free adjustable |
| Dust filter | Yes, removable and cleanable |
| Battery capacity indicator | Yes, on battery (depending on version) |
| Anti-restart safety | Yes (on paddle-switch models) |
| Deadman function | Yes (on paddle-switch models) |
| Spindle lock | Yes, for accessory change |
| Main functions | Grinding, sanding, brushing, cutting |
| Maintenance | Regularly clean the ventilation slots and dust filter |
| Repairability | Repairs by authorized Metabo electrician |
| Spare parts | Available at www.metabo.com |
Frequently Asked Questions - WB 18 LTX BL 15125 Quick METABO
What accessories can I use with the Metabo WB 18 LTX BL 15125 Quick angle grinder?
You can use grinding wheels, cup wheels, cutting wheels, wire brushes, abrasive discs, and diamond core bits, provided they are original Metabo or CAS-compatible and comply with the maximum dimensions (diameter 125 mm).
How do I change the grinding disc?
Before any change, remove the battery. Lock the spindle using button (5). For the Quick system, tighten the Quick clamping nut by hand clockwise. To loosen, press the spindle lock button while the wheel is still turning slightly; the nut loosens automatically.
Which battery is compatible?
Use only Metabo or CAS (Cordless Alliance System) Li-Ion 18 V batteries, for example models 5.5 Ah (LiHD), 8.0 Ah (LiHD), or 10.0 Ah (LiHD).
How do I adjust the rotation speed?
If your model is equipped with an adjustment wheel (15), turn it to select the speed: low for sanding, medium for brushing, high for grinding and cutting.
What should I do if the machine stops automatically?
This is the electronic safety shutdown: the machine detects a stall or overcurrent. Turn it off, then restart normally. Avoid jamming the tool in the workpiece.
How do I clean the angle grinder?
Remove the battery. Regularly clean the ventilation slots with dry air or a vacuum. The dust filter (13) can be removed and cleaned with compressed air.
Can I use a guard for cutting?
Yes, but you must use the appropriate guard: type C (combined) for grinding and cutting, type B for grinding only. Never use an unsuitable guard, as this may lead to loss of control.
How do I transport the Li-Ion battery safely?
Li-Ion batteries are subject to dangerous goods regulations (UN 3480/3481). Use a certified Metabo packaging, protect the contacts against short circuits (adhesive tape), and only ship batteries that are intact and leak-free.
What is the function of the tether (anti-drop protection)?
The tether (18) secures the machine with a strap to prevent falls from height. It is compatible with certain paddle-switch models and LiHD 5.5 Ah and 10.0 Ah batteries.
How do I recycle the angle grinder at end of life?
Do not dispose of the device or batteries with household waste. Take them to an appropriate collection point (store, recycling center). Follow local guidelines and WEEE regulations (Directive 2012/19/EU).
