Product type	DLP Projector
Native resolution	WXGA (1280 x 800)
Brightness	3600 lumens (estimated)
Contrast	Not specified
Power supply	AC 100-240 V, 50/60 Hz
Power consumption	Normal mode: 280 W (estimated), standby: < 0.5 W
Weight	2.5 kg (estimated)
Dimensions (W × D × H)	300 × 220 × 100 mm (estimated)
Lens	Manual zoom, manual focus
Keystone correction	Automatic and manual (vertical/horizontal)
Video inputs	VGA, HDMI (×2), Composite video
Audio inputs/outputs	Audio input (stereo), audio output
Connectivity	USB-A (Memory Viewer), USB-B (USB Display), LAN (RJ45), RS-232
Built-in speaker	Yes, mono
Main features	Digital zoom, freeze, timer, closed captioning, Colorboard, image mode
Security	Key lock, PIN code, Kensington slot
Maintenance	Cleanable air filter, lamp replacement
Supplied accessories	Power cord, remote control (without batteries), quick start guide, VGA cable
OSD menu languages	26 languages including French, English, German, etc.
Warranty	2 years (projector), 1 year/1000 h (original lamp)

Frequently Asked Questions - LightPro IN1036 INFOCUS

How to turn on the LightPro IN1036 projector?

Plug in the AC power cord. The POWER indicator lights red. Press the POWER button on the control panel or remote control. The indicator turns green and the fan starts. If a PIN code is set, enter it.

How to adjust keystone correction?

Press the KEYSTONE key on the remote control. Use the arrow keys ▲▼◄► to correct vertical/horizontal distortion, or adjust angles individually via Corner correction.

How to replace the projector lamp?

Turn off the projector and unplug the power cord. Let it cool for 1 hour. Open the lamp compartment (see manual). Remove the old lamp and insert the new one. Reset the lamp counter via the Factory settings menu.

How to clean the air filter?

Turn off the projector and unplug it. Remove the filter (located at the front). Clean it with a vacuum or lukewarm water (let it dry completely). Put it back and reset the filter counter via the Filter counter menu.

How to use the USB Display function?

Connect a USB-A to USB-B cable between your computer and the USB-B port on the projector. Select the USB Display input source from the INPUT menu. Your PC screen will be projected.

How to set a security PIN code?

Go to the Extended menu > Security. Enable Logo PIN code protect. Enter a 3-digit code using the arrow keys. Confirm. The projector will ask for this code at each power-on.

How to change the OSD menu language?

Press MENU, go to the Extended tab, select Language. Choose from 26 languages (French available). Confirm with OK.

How to adjust the volume or mute?

Use the VOLUME + and VOLUME - keys on the remote control. To mute, press MUTE. Press again to restore sound.

How to use the digital zoom?

Press D.ZOOM + or D.ZOOM - on the remote control. Use the arrow keys ▲▼◄► to select the area to enlarge. Press any other key to exit zoom mode.

How to connect a PC via VGA?

Connect a VGA cable between the PC's VGA output and the COMPUTER IN port on the projector. Select the VGA source via the VGA button on the remote control or the INPUT menu.

USER MANUAL LightPro IN1036 INFOCUS

Copyright © 2021 InFocus

Copyright © 2020 by InFocus Corporation

https://infocus.com/support/contact/

Pour les modèles IN1029, IN1039, IN1049, IN1059, IN1024, IN1034, IN1044, IN1026, IN1036, IN1046

Terminaux

1 Port HDMI

IN1024, IN1034, IN1044

Taille d'écran			Distance de projection
			Standard 4:3 Compatible 16:9
Taille d'écran(pouce)	Largeur(m)	Hauteur(m)	Large	Télé	Large	Télé
30" 0.6100.457 0.8	121.347 0.8	85 1.467
60" 1.2190.9141.63	30 2.702 1.7	76 2.944
80" 1.6261.2192.17	8 3.610 2.3	73 3.933
100" 2.032 1.524	2.728 4.523	2.972 4.927
150" 3.048 2.2864	1146.8204.4	827.430
200" 4.0643.048 5	514 9.1416	0089.959
250" 5.080 3.810	6.92911.486	7.549 12.513
300" 6.0964.572 8	358 13.855	9.10615.094

IN1026

Taille d'écran			Distance de projection
			Standard 4:3 Compatible 16:9
Taille d'écran(pouce)	Largeur(m)	Hauteur(m)	Large	Télé	Large	Télé
30" 0.6460.4040.94	42 1.137	0.969 1.169
60" 1.2920.8081.91	0 2.299	1.963 2.363
80" 1.723 1.077 2	554 3.073	2.626 3.159
100" 2.154 1.346	3.199 3.848	3.289 3.956
150" 3.231 2.0194	811 5.785	4.946 5.946
200" 4.308 2.6926	423 7.721	6.602 7.937
250" 5.385 3.365	8.035 9.658	8.259 9.927
300"	6.462	4.039	9.647	11.595	9.916	11.917

IN1046, IN1039, IN1059

Taille d'écran			Distance de projection
			Standard 4:3 Compatible 16:9
Taille d'écran(pouce)	Largeur(m)	Hauteur(m)	Large	Télé	Large	Télé
30" 0.6460.4040.81	2 1.347 0	835 1.384
60" 1.2920.8081.63	0 2.702 1	675 2.777
80" 1.723 1.077 2	178 3.610	2.239 3.711
100" 2.154 1.346	2.728 4.523	2.804 4.648
150" 3.231 2.0194	114 6.820	4.228 7.009
200" 4.308 2.6925	520 9.150	5.673 9.405
250" 5.385 3.365	6.936 11.498	7.129 11.817
300" 6.4624.039 8	367 13.869	8.599 14.255

IN1036, IN1029, IN1049

Taille d'écran			Distance de projection
			Standard 4:3 Compatible 16:9
Taille d'écran(pouce)	Largeur(m)	Hauteur(m)	Large	Télé	Large	Télé
30" 0.6460.4040.87	2 1.053 0	896 1.082
60" 1.2920.8081.76	9 2.129 1	818 2.188
80" 1.723 1.077 2	365 2.845	2.431 2.924
100" 2.154 1.346	2.962 3.563	3.044 3.662
150" 3.231 2.0194	455 5.356	4.578 5.505
200" 4.308 2.6925	947 7.149	6.113 7.348
250" 5.385 3.365	7.440 8.943	7.647 9.191
300" 6.4624.039 8	932 10.736	9.181 11.035

Pour les modèles IN1029, IN1039, IN1049, IN1059, IN1024, IN1034, IN1044, IN1026, IN1036, IN1046

Pour les modèles IN1029, IN1039, IN1049, IN1059, IN1024, IN1034, IN1044, IN1026, IN1036, IN1046

Pour les modèles IN1029, IN1039, IN1049, IN1059, IN1024, IN1034, IN1044, IN1026, IN1036, IN1046

Pour les modèles IN1029, IN1039, IN1049, IN1059, IN1024, IN1034, IN1044, IN1026, IN1036, IN1046
