USER MANUAL GHSSANPOS300 GMB Gaming

GEMBIRD EUROPE B.V. http://www.gembird.eu All brands and logos are registered trademarks of their respective owners GHS-SANPO-S300 USB 7.1 SURROUND GAMING HEADSET WITH RGB BACKLIGHT Features Gaming headset with rotating microphone boom

7.1 virtual audio channel sound

Adjustable headband and comfortable large ear cushions RGB rainbow LED light effect Suitable for use with most (gaming) desktops and laptops Practical in-line volume control Specifications Interface: 2 pcs x 3.5 mm plug (input + mic); USB-AM for backlight power Driver unit: 50 mm Impedance: 32 Ohms ±10% Frequency response: 20 - 20000Hz Sensitivity: 105 dB ± 5 dB S.P.L at 1 kHz Max. power: 30 mW Microphone: electret, omni-directional; frequency response: 20 - 16000 Hz; sensitivity: -52 dB ± 5dB Cord length: 2.2 m Net weight: 0.37 kg USB power: 5 V DC up to 0.1 A3 GEMBIRD EUROPE B.V. http://www.gembird.eu All brands and logos are registered trademarks of their respective owners GHS-SANPO-S300 USB 7.1 SURROUND GAMING HEADSET WITH RGB BACKLIGHT

GEMBIRD EUROPE B.V. http://www.gembird.eu All brands and logos are registered trademarks of their respective owners GHS-SANPO-S300 USB 7.1 SURROUND GAMING HEADSET WITH RGB BACKLIGHT

GEMBIRD EUROPE B.V. http://www.gembird.eu All brands and logos are registered trademarks of their respective owners GHS-SANPO-S300 USB 7.1 SURROUND GAMING HEADSET WITH RGB BACKLIGHT

The receipt must clearly list the date of purchase and the part number, in addition it should be printed. Keep the receipt for the entire warranty period since it is required for all warranty claims. During the warranty period the defective items will be credited, repaired or replaced at the manufacturer's expense. Work carried out under the warranty neither extends the warranty period nor starts a new warranty period. The manufacturer reserves the right to void any warranty claim for damages or defects due to misuse, abuse or external impact (falling down, impact, ingress of water, dust, contamination or break). Wearing parts (e.g. rechargeable batteries) are excluded from the warranty. Upon receipt of the RMA goods, Gembird Europe B.V. reserves the right to choose between replacement of defective goods or issuing a credit note. The credit note amount will always be calculated on the basis of the current market value of the defective products. Gembird Europe B.V. Wittevrouwen 56, 1358CD Almere, The Netherlands www.gembird.nl/service [e-mail]
