Product Type	RS232 Serial Data Line Surge Protector
Brand	Tripp Lite
Model	DB9
Nominal Clamping Voltage	18 volts (pins 1-9 and chassis)
Maximum Surge Current	340 amperes
Component Response Time	Less than 1 picosecond
Connectors	Reversible DB9 male/female with thumbscrews
Protected Interfaces	RS232 (9-pin serial ports)
Protection Type	Transient Overvoltage (lightning, electrostatic discharge, ground surges)
Installation	Directly on equipment; attach green ground wire to chassis
Recommended Cable Distance	Less than 12 inches (30 cm) between protector and equipment
Warranty	Limited Lifetime (repair or replacement)
Country of Manufacture	China
Weight (estimated)	Approximately 50 g
Dimensions (estimated)	5 x 3 x 2 cm
General Information	Protects network equipment on data lines; does not protect the opposite end of the cable

Frequently Asked Questions - DB9 Tripp Lite

How to install the Tripp Lite DB9 surge protector?

Make sure the equipment is powered off and unplug the cable. Connect the DB9 directly to the equipment port. Attach the green ground wire to the equipment chassis. Reconnect the cable to the other side of the DB9. To reverse the orientation, remove the thumbscrews, reverse the connector, and retighten the screws.

What types of ports are protected by the DB9?

The Tripp Lite DB9 protects 9-pin RS232 serial ports, both male and female, with its reversible connector.

Does the DB9 protect both ends of the cable?

No, the DB9 only protects the equipment on the side where it is installed. For full protection, it is recommended to install a protector at each end of the cable.

How to reverse the orientation of the DB9 connector?

Unscrew the thumbscrews, remove the connector, rotate it 180 degrees to change from male to female (or vice versa), then retighten the screws.

What is the nominal clamping voltage of the DB9?

The nominal clamping voltage is 18 volts, protecting pins 1 through 9 as well as the chassis.

What is the warranty of the Tripp Lite DB9 surge protector?

The DB9 comes with a limited lifetime warranty against defects in materials and workmanship. If you encounter a problem, contact Tripp Lite for a free replacement or repair.

Can I use the DB9 with a UPS (Uninterruptible Power Supply)?

Yes, but make sure the UPS is not plugged into the output of a surge suppressor, as that would void the warranty. The DB9 protects the data line; for complete protection, also use a surge suppressor on the power supply.

Does the DB9 protect against lightning?

Yes, the DB9 protects against transient AC currents generated by lightning, as well as electrostatic discharge and ground surges.

What is the difference between the DB9 and the DB25?

The DB9 protects 9-pin serial ports (RS232), while the DB25 protects 25-pin ports (RS232, pins 1-8 and 20). The DB25-ALL protects all 25 pins.

Where should I attach the ground wire of the DB9?

Attach the green ground wire directly to the chassis of the protected equipment. This ensures proper grounding for optimal protection.

USER MANUAL DB9 Tripp Lite

Tested To Comply With FCC Standards FOR HOME OR OFFICE USE

Data Shield ^™ by Tripp Lite Network Dataline Surge Suppressors are designed to protect data and communications equipment against AC transients caused by lightning, electrostatic discharge and ground surges that can enter equipment from the signal lines or chassis ground.

Data Shield by Tripp Lite Network Dataline Surge Suppressors described here protect networked equipment using 100Base-T, 10Base-T, 10Base-2 and Ethernet, Token Ring, RS232, RS422, parallel, dial-up modems, fax, ISDN, DDS, T-1 and other communication interfaces.

Tripp Lite World Headquarters 1111 W. 35 ^th Street, Chicago, IL 60609 USA [phone] • www.tripplite.com

Note: Follow these instructions to ensure proper operation and prevent damage to this device and its connected equipment.

Copyright © 2008 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners.

INSTALLATION

1. Make sure the computer, network device or other equipment is logged OFF the network (if applicable). Turn OFF power to the equipment.
2. Disconnect the cable from the equipment to be protected.
3. Connect the Data Shield by Tripp Lite Network Dataline Surge Suppressor directly to the equipment. DB9 and DB25 models are reversible, to work with male or female ports. To change gender, remove the thumbscrews, reverse their direction and re-install.
4. Attach the green ground wire on the surge suppressor directly to the protected equipment's chassis. (Except DB9 and DB25 models.)
5. Reconnect the cable to the Data Shield by Tripp Lite Network Dataline Surge Suppressor.

NOTE!

The Data Shield by Tripp Lite Network Dataline Surge Suppressor must be properly grounded and positioned as close as possible to the equipment to be protected. For best results, it is required that the length of the signal line and ground wire (if equipped) between the surge suppressor and the protected equipment be kept as short as possible, not to exceed 12 inches (12"). It is best to install the surge suppressor directly to the equipment, as noted above.

NOTE!

Installing a typical Data Shield by Tripp Lite Network Dataline Surge Suppressor is equivalent to adding approximately three feet (3') of typical data communication cable to a segment.

CAUTION!

The Data Shield by Tripp Lite Network Dataline Surge Suppressor does not protect the equipment on the opposite end of the cable. Normally, protection at both ends is recommended.

CAUTION!

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

CAUTION!

When properly installed, the Data Shield by Tripp Lite Network Dataline Surge Suppressor will only protect against surges on the dataline portion of your installation. Simultaneous AC surge suppression/power protection in the form of an ISOBAR ^® surge suppressor or Tripp Lite UPS system is strongly recommended for complete system/network protection and can also extend Ultimate Lifetime Insurance coverage to connected equipment.

SPECIFICATIONS

All surge suppressors listed have component response times of less than 1 picosecond.

Model: Description:		Nominal Clamping Voltage:	Peak Pulse Current:
DRS232	RJ45/RJ11 protector for 100Base-T4, RS232 on twisted Pair (wires 1-8) or ISDN “S/T” interfaces. Supplied with a 4” RJ45 patch cable.	18 volts, protecting wires 1-8	1340 amps
DNET1	RJ45 100Base-T, 10Base-T, Token Ring, RS422, AS400/Sys3x protector for NICs, hubs, routers, etc. Supplied with 4” RJ45 patch cable.	7.5 volts, protecting wires 1-8	750 amps
DSUT1CSU	RJ45/RJ11 protector for nonspan powered T-1 equipment, digital data service CSUs/DSUs, ISDN “U” interfaces or other digital lines. Supplied with 4” RJ45 patch cable.	60 volts, protecting wires 1-8	200 amps
DTEL2	RJ45/RJ11 for modems, answering and fax machines. Supplied with 4” RJ11 patch cable.	260 volts, protecting center 4 wires (2 CO-lines)	250 amps
DB9	Serial DB9 RS232 protector for male or female ports of data terminal and computing equipment including PCs, modems, etc. (Any male or female 9-pin port). Male/Female genders are reversible with reversible thumbscrews.	18 volts, protecting pins 1-9 and chassis	340 amps
DB25	Serial DB25 RS232 protector (wires 1-8, 20) for male or female ports of data terminal & computing equipment including PCs, printers, modems, etc. Male/Female genders are reversible with reversible thumbscrews.	18 volts, protecting pins 1-8, 20 and chassis 340 amps
DB25-ALL	DB25-ALL: Serial DB25 RS232 protector (pins 1-25) for any 25-pin male or female DTE/DCE ports. Male/Female genders are reversible with reversible thumbscrews.	18 volts, protecting pins 1-25 and chassis	340 amps
D10B2	10Base-2 thin coax protector (BNC m/f). Also protects IBM 3270 and CCTV lines.	7.5 volts, protecting center, shield and chassis	750 amps
DCATV	Coaxial protector for TVs, VCRs, pro video supplied by CATV (“F” m/f).	7.5 volts, protecting center and shield conductors	750 amps

Call Tripp Lite Customer Support at [phone] for additional applications.

FCC Part 68 Notice (United States Only)

If your Modem/Fax Protection causes harm to the telephone network, the telephone company may temporarily discontinue your service. If possible, they will notify you in advance. If advance notice isn't practical, you will be notified as soon as possible. You will be advised of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper operation of your equipment. If it does, you will be given advance notice to give you an opportunity to maintain uninterrupted service. If you experience trouble with this equipment's Modem/Fax Protection, please call Tripp Lite Technical Support at [phone] for repair/warranty information. The telephone company may ask you to disconnect this equipment from the network until the problem has been corrected or you are sure the equipment is not malfunctioning. There are no repairs that can be made by the customer to the Modem/Fax Protection. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs. (Contact your state public utility commission or corporation commission for information.)

LIFETIME LIMITED WARRANTY

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for its lifetime. If the product should prove defective in material or workmanship within that period, seller will repair or replace the product, at its sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35 ^th Street, Chicago, IL 60609. Seller will pay return shipping charges.

The warranties of all TRIPP LITE Surge Suppressors are null and void if they have been connected to the output of any UPS system.

The warranties of all TRIPP LITE UPS Systems are null and void if a surge suppressor has been connected to its output receptacles.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

TRIPP LITE; 1111 W. 35th Street; Chicago, IL 60609

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any specific application.

Regulatory Compliance Identification Numbers

For the purpose of regulatory compliance certifications and identification, your Data Shield by Tripp Lite product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information. When requesting compliance information for this product, always refer to the series number. The series number should not be confused with the marking name or model number of the product.

Tripp Lite follows a policy of continuous improvement. Product specifications are subject to change without notice. Made in China.
