P960001MSATA - External hard drive Tripp Lite - Free user manual and instructions

Product Type	mSATA SSD to SATA Adapter
Brand	Tripp Lite
Model	P960-001-MSATA
Supported Disk Formats	mSATA SSD
Interface	SATA III (backward compatible with SATA I/II)
Maximum Transfer Rate	Up to 6 Gbps
Form Factor	2.5 inches (6.35 cm)
Dimensions (approx.)	100 x 70 x 9.5 mm
Weight (approx.)	40 g
Power Supply	Via SATA connector (self-powered)
Housing Material	Metal and plastic
Package Contents	P960-001-MSATA Adapter, mounting hardware, screwdriver, user manual
Warranty	1 year limited
Features	Ready to use, no software or drivers required, enhanced protection for hot-swap bay use
System Requirements	mSATA drive, host device with SATA port
Maintenance	Clean with a dry, lint-free cloth; avoid liquids
Safety	Handle SSDs with an antistatic wrist strap; discharge static electricity before handling
Repairability	Replacement parts not available individually; contact Tripp Lite support

Frequently Asked Questions - P960001MSATA Tripp Lite

Do I need to format the mSATA SSD before use?

Yes, if the SSD is not yet formatted, you must use your operating system's Disk Management utility to format it (NTFS, exFAT, etc.) before you can copy files to it.

Is this adapter compatible with all mSATA SSDs?

It is compatible with most standard mSATA SSDs, but check the dimensions and 6-pin connector. It supports SATA I/II/III speeds.

How do I install my SSD in the adapter?

Remove the cover, insert the nuts into the slots, plug the SSD at an angle into the mSATA connector, then secure it with the provided screws. Replace the cover and connect the adapter to the SATA port.

Can I disconnect the adapter without turning off the computer?

It is strongly recommended to eject the device via the system before disconnecting it, especially when used externally, to avoid data loss.

What is the maximum transfer speed?

The adapter supports speeds up to 6 Gbps (SATA III), but the actual speed will depend on the performance of your SSD and host interface.

Can I use this adapter with an external USB enclosure?

Yes, the adapter converts the mSATA SSD to a standard 2.5-inch SATA format, which can then be used in an external enclosure or SATA dock.

How do I protect my SSD against static electricity?

Use an antistatic wrist strap (such as Tripp Lite's P999-000) or touch a grounded metal surface before handling the SSD. Avoid touching the connectors.

What does the one-year warranty cover?

The one-year limited warranty covers defects in materials and workmanship. It does not cover accidental damage, normal wear and tear, or unauthorized modifications.

What should I do if my computer does not recognize the adapter?

Check that the SSD is properly inserted, the adapter is well connected to the SATA port, and the SSD is formatted. Try another SATA port or another computer to isolate the issue.

Does this adapter work with M.2 SATA SSDs?

No, this adapter is specifically designed for mSATA SSDs, not M.2. The connectors and dimensions are different.

USER MANUAL P960001MSATA Tripp Lite

mSATA SSD to 2.5" SATA Enclosure Adapter

Model: P960-001-MSATA

Español 7 • Français 13 • Русский 19

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge protector—a \$100 value!

www.tripplite.com/warranty

Manufacturing Excellence

1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support

Copyright © 2016 Tripp Lite. All rights reserved.

Product Features

• Access an mSATA SSD drive with a standard SATA computer
• Use an mSATA SSD drive with an external source, such as a SATA drive enclosure or docking station
• Enclosed housing provides added protection when used in applications requiring more durability, such as hot-swap drive bays or external docking stations
  • Supports data transfer rates up to 6 Gbps (SATA I/II/III)
• Plug-and-play; no software or drivers required

System Requirements

• mSATA Drive
• SATA Host Device

Package Contents

• P960-001-MSATA
• Mounting Hardware
• Screwdriver
• Owner's Manual

Installation

Notes:

• SSD drives are sensitive to static electricity and must be handled properly, so as not to risk data loss. Always handle your SSD drive with caution by wearing an anti-static strap (Such as Tripp Lite P999-000) when transporting it, or by touching a grounded metal surface to discharge yourself of static electricity prior to picking up the drive.
• If your drive has not been formatted yet, you will first need to format it using your computer's Disk Management utility in order to copy and access files.
• Prior to unplugging the enclosure adapter, make sure to properly eject the drive from your computer to avoid any potential data loss.

Installation

1. Remove the cover from the P960-001-MSATA unit to expose the SSD drive tray and mSATA connector.
2. Insert the included nuts into the corresponding slots on the board.
3. Connect your drive by inserting it into the mSATA connector. Keep the drive at a low angle to minimize stress on the connector.
4. Using the included screws, secure the drive by screwing it into the nuts.
5. When the drive is fully installed, place the cover back on to protect the drive from dust and other contaminants.
6. Connect the unit to the SATA port on your computer.
7. Your drive is now ready for use.

Warranty and Product Registration

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

PRODUCT REGISTRATION

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Warranty and Product Registration

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
