Product Type	USB-C to VGA Adapter
Brand	Tripp Lite
Model	U444-06N-VGA-AM (White), U444-06N-VB-AM (Black), U444-06N-VGA-RA (right-angle)
Input Connector	USB Type-C (male)
Output Connector	VGA (female)
Maximum Video Resolution	1920 x 1200 @ 60 Hz (includes 1080p)
Data Rate	Up to 5 Gbps (USB 3.1 Gen 1)
VGA Transfer Rate	6.75 Gbps (2.25 Gbps per channel)
Compatibility	Devices with USB Type-C port supporting DisplayPort Alt Mode
External Power	Not required (bus-powered via USB-C port)
Operating Temperature	0 to 45 °C
Operating Humidity	10 to 85% RH (non-condensing)
Storage Temperature	-10 to 70 °C
Storage Humidity	5 to 90% RH (non-condensing)
Warranty	3-year limited
Installation	Plug-and-play, no driver required
Package Contents	Adapter, quick start guide
Care and Cleaning	Clean with a soft, dry cloth. Do not use liquids or aerosols.
Safety	Use in a dry, clean environment. Do not expose to moisture or extreme temperatures.
Spare Parts and Repairability	Not user-serviceable. If defective, contact Tripp Lite support for warranty replacement.

Frequently Asked Questions - U44406NVBAM Tripp Lite

What type of device is the U44406NVBAM?

It is a USB-C to VGA adapter that allows connecting a device with a USB Type-C port (supporting DisplayPort Alt Mode) to a VGA monitor.

What video resolutions are supported?

The adapter supports a maximum resolution of 1920 x 1200 @ 60 Hz, including 1080p.

Does the adapter require driver installation?

No, it is plug-and-play. No driver is required for operation.

Which devices are compatible?

All devices with a USB Type-C port supporting DisplayPort Alt Mode (smartphones, tablets, Ultrabooks, computers).

Does the adapter work with a Mac?

Yes, it works with Macs equipped with a USB Type-C port compatible with DisplayPort, such as recent MacBook and MacBook Pro.

What is the recommended maximum VGA cable length?

Tripp Lite recommends using a quality VGA cable, but the standard maximum length for 1080p resolution is about 15 meters.

Can the adapter be used with a DVI or HDMI monitor?

No, it is designed specifically for VGA monitors. For DVI or HDMI, a different adapter is needed.

What models are available?

The models are: U444-06N-VGA-AM (white), U444-06N-VB-AM (black), and U444-06N-VGA-RA (right-angle connector).

How to clean the adapter?

Use a soft, dry cloth. Do not use liquids, aerosols, or abrasive products.

What to do if the adapter does not work?

Check that the source device supports DisplayPort Alt Mode. If defective, contact Tripp Lite support for a replacement under the 3-year limited warranty.

USER MANUAL U44406NVBAM Tripp Lite

Models: U444-06N-VGA-AM (White), U444-06N-VBAM (Black), U444-06N-VGA-RA (Right Angle)

Español 8 • Français 14 • Русский 20

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a \$100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support

Copyright © 2018 Tripp Lite. All rights reserved.

Product Features

• Supports USB DisplayPort Alternate Mode for transmitting video signals to a VGA-enabled monitor via the USB Type-C™ (USB-C™) port on your smartphone, tablet, Ultrabook or computer
  • Supports video resolutions up to 1920 x 1200 @ 60 Hz, including 1080p
  • Supports VGA transfer rates of 6.75 Gbps (2.25 Gbps per channel)
• USB 3.1 Gen 1 supports data transfer rates up to 5 Gbps
• Compatible with USB Type-C devices that support USB DisplayPort Alternate Mode
• U444-06N-VGA-RA features a right-angle USB-C connector for confined or hard-to-reach spaces
• Plug-and-Play adapter—no drivers required

USB Type-C ^™ and USB-C ^™ are trademarks of USB Implementers Forum.

Package Contents

• U444-06N-VGA-AM (White), U444-06N-VB-AM (Black) or U444-06N-VGA-RA (Right Angle)
• Quick Start Guide

System Requirements

• USB Type-C (USB-C) device that supports USB DisplayPort Alternate Mode
  • VGA-enabled monitor

Installation

1. Connect the adapter's USB Type-C connector to the USB Type-C port on your smartphone, tablet, Ultrabook or computer.
2. Connect the adapter's VGA port to a monitor using a VGA cable (such as Tripp Lite's P502-Series cables).
3. The video image will appear on the add-on monitor. Customize how video is displayed on the add-on monitor using your device's display settings.

Specifications

Connectors
USB USB Type-C (Male)
Display VGA (Female)
Video
Maximum Resolution 1920 x	1200 @ 60 Hz, including 1080p
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature 14° to 158°F (-10° to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
External Power Supply No

Warranty and Product Registration

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and Product Registration

PRODUCT REGISTRATION

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Warranty and Product Registration

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support
