USER MANUAL Sweet Pot HWI0005 OREGON SCIENTIFIC

The Sweet Pot Aroma Diffuser

Instruction Manual HWI0005

PARTS

Line drawing of a birdcage with a steaming top (no text or symbols)

1. Glass Cover
2. Water tank Cover
3. Max Water Level Line
4. Water Tank
5. LED Light (inside)
6. Unit Base
7. Power/Mist Mode Button
8. Light Control Button
9. Silicone O-Ring
10. Ultrasonic Vibration Plate
11. Air Outlet
12. Unit Bottom
13. DC Power Jack
14. Ventilation Hole
15. USB to DC power cord

1 2 15

11 3 4 10 5 9 6 8 7 14 Φ 12 13

FEATURES

Strong mist output even with USB power. Elegant glass cover delivers the aromatic luxury feels to your home.

1. Water Capacity: 80 mL (2.82 fl oz)
2. Suggested Room Size: 200 sq ft (19 sq meter)
3. Continuous Operation: 4 hours Intermittent Operation: 8 hours,

30-second intervals

1. Light Mode: Rotating, solid color, OFF (Design1) Bright, Dim, OFF (Design 2)
2. Automatic safety shut-off
3. Power: USB Power Adapter (Optional), UL approved

CARE & MAINTENANCE

Always remove the power cord before cleaning. Only use the power cord that is supplied with the unit.

When not in use, empty the water from the side of the tank, avoiding Air Outlet. Dry with a soft cloth to avoid mineral buildup.

To remove possible buildup, gently use a cotton swab dipped in white vinegar to wipe out the inside.

Note: The Ultrasonic Vibration Plate should not come in contact with any hard or sharp objects.

Do not use strong cleaning agents.

Essential oil should not come in contact with the exterior surface of the unit

Diagram showing six stages of a bottle and glass bottle with labeled parts and directional arrows indicating process flow.

INSTRUCTIONS FOR USE

1. Remove Glass Cover and Water Tank Cover. (FIG 1)

2. Pour tap water (80 mL) into the water tank up to Maximum Water Level Line. Add a few drops of your choice of essential oil (not included) directly into Water Tank. (FIG 2)

3. Replace the Water Tank Cover and Glass Cover. (FIG 1)

4. Plug the adapter end of USB Power Cord into DC Power Jack input on Unit Bottom. Plug USB end of Power Cord into USB Port or Power Adapter. (FIG 3)

5. Button Functions: (FIG 4)

Left Side - Light Control Button:

1^st push rotating color (Design 1) / 1^st push bright white light(Design 2)
2^nd push maintains solid color (Design 1) / 2^nd push dim white light (Design 2)
3 ^rd push turns lights off (Both Design 1 and Design 2)

Right Side - Power/Mist Mode Button:

1 ^st push continuous
2^nd push intermittent
3 ^rd push turns unit OFF completely
The unit will automatically turn off when water level becomes too low.

Use only 100% natural essential oil.

Line drawings of three different types of household appliances: a birdcage, a funnel, and a blender (no text or symbols present)

FIG 1

FIG 2

FIG 3

FIG4

EU DECLARATION OF CONFORMITY

Hereby, the manufacturer Oregon Scientific, declares that the equipment type: The Sweet Pot Aroma Diffuser (HWI0005) is in compliance with the Directive 2014/30/EU. The full text of the EU declaration of conformity is available at the following Internet address: www.oregonscientific.com

DISPOSAL INFORMATION FOR USERS

Pursuant to and in accordance with Article 14 of the Directive 2012/19/EU of the European Parliament on waste electrical and electronic equipment (WEEE), and pursuant to and in accordance with Article 20 of the Directive 2013/56/EU of the European Parliament on batteries and accumulators and waste batteries.

The barred symbol of the rubbish bin shown on the equipment indicates that, at the end of its useful life, the product must be collected separately from other waste.

Please note that the batteries/rechargeable batteries must be removed from the equipment before it is given as waste. To remove the batteries/accumulators refer to the specifications in the user manual. Therefore, any products that have reached the end of their useful life must be given to waste disposal centers specializing in separate collection of waste electrical and electronic equipment, or given back to the dealer when purchasing a new WEEE, pursuant to and in accordance with Article 14 as implemented in the country.

The adequate separate collection for the subsequent start-up of the equipment sent to be recycled, treated and disposal of in an environmentally compatible way contributes to preventing possible negative effects on the environment and health and optimizes the recycling and reuse of components making up the apparatus.

Abusive disposal of the product by the user involves application of the administrative sanctions according to the laws in force.

The Sweet Pot Aroma Diffuser

Instruction Manual HWI0005

PARTS

Line drawing of a birdcage with a lid and steam rising from its top (no text or symbols)

1. Glass Cover
2. Water tank Cover
3. Max Water Level Line
4. Water Tank
5. LED Light (inside)
6. Unit Base
7. Power/Mist Mode Button
8. Light Control Button
9. Silicone O-Ring
10. Ultrasonic Vibration Plate
11. Air Outlet
12. Unit Bottom
13. DC Power Jack
14. Ventilation Hole
15. USB to DC power cord

1 2 15

11 3 4 10 5 9 6 8 7 14 Φ 12 13

FEATURES

Strong mist output even with USB power. Elegant glass cover delivers the aromatic luxury feels to your home.

1. Water Capacity: 80 mL (2.82 fl oz)
2. Suggested Room Size: 200sq ft (19 sq meter)
3. Continuous Operation: 4 hours

Intermittent Operation: 8 hours,

30-second intervals

1. Light Mode: Rotating, solid color, OFF (Design 1)

Bright, Dim, OFF (Design 2)

1. Automatic safety shut-off
2. Power: USB Power Adapter (Optional), UL approved

CARE & MAINTENANCE

Always remove the power cord before cleaning. Only use the power cord that is supplied with the unit.

When not in use, empty the water from the side of the tank, avoiding Air Outlet. Dry with a soft cloth to avoid mineral buildup.

To remove possible buildup, gently use a cotton swab dipped in white vinegar to wipe out the inside.

Note: The Ultrasonic Vibration Plate should not come in contact with any hard or sharp objects.

Do not use strong cleaning agents.

Essential oil should not come in contact with the exterior surface of the unit

Illustration of five different types of laboratory glassware or containers, including a barrel, beaker, funnel, and beaker with a spoon (no text or symbols present)

INSTRUCTIONS FOR USE

1. Remove Glass Cover and Water Tank Cover. (FIG 1)
2. Pour tap water (80 mL) into the water tank up to Maximum Water Level Line. Add a few drops of your choice of essential oil (not included) directly into Water Tank. (FIG 2)
3. Replace the Water Tank Cover and Glass Cover. (FIG 1)
4. Plug the adapter end of USB Power Cord into DC Power Jack input on Unit Bottom. Plug USB end of Power Cord into USB Port or Power Adapter. (FIG 3)
5. Button Functions: (FIG 4)

Left Side - Light Control Button:

1" push rotating color (Design 1) / 1" push bright white light(Design 2)
2^nd push maintains solid color (Design 1) / 2^nd push dim white light (Design 2)
3 ^rd push turns lights off (Both Design 1 and Design 2)

Right Side - Power/Mist Mode Button:

1 ^st push continuous
2 ^rd push intermittent
3 ^rd push turns unit OFF completely
The unit will automatically turn off when water level becomes too low.

1. Use only 100% natural essential oil.

Diagram showing three stages of a birdcage with internal components and directional arrows indicating flow or movement (no text or symbols)

FIG 1

FIG 2

FIG 3

FIG4

FCC STATEMENT

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio / TV technician for help.

TEILE

Line drawing of a birdcage with a lid and steam rising (no text or symbols)

Technical diagram of a birdcage with labeled parts 1, 2, and 15

11 3 4 10 5 9 6 8 7 14 12 13

EIGENSCHAFTEN

Diagram showing six different types of laboratory glassware or containers, including a bottle, beaker, funnel, cylinder, and container with a spoon.

BEDIENUNGSANLEITUNG

Three-step diagram showing a birdcage, funnel, and lid with directional arrows indicating movement (no text or symbols)

ABB.1

ABB.2

ABB.3

Line drawing of a birdcage with a lid and steam rising from its top (no text or symbols)

Technical diagram of a birdcage with labeled parts 1, 2, and 15

11 3 4 10 5 9 6 8 7 14 高C1 12 13

PIÈCES

Diagram showing five stages of a bottle and container with labeled parts and directional arrows indicating process flow.

MODE D'EMPLOI

1ère pression continue

2ème pression intermittente

UE DÉCLARATION DE CONFORMITÉ

Line drawing of a birdcage with a lid and steam rising (no text or symbols)

Diagram showing six stages of a bottle and container with labeled parts and directional arrows indicating process flow.

ISTRUZIONI PER L'USO

Line drawing of a birdcage with smoke rising from its top (no text or symbols)

Technical diagram of a birdcage with labeled parts 1, 2, and 15

11 3 4 10 5 9 6 8 7 14 12 第C1 13

PIÈCES

MODE D'EMPLOI

Diagram showing three stages of a birdcage and a container with arrows indicating movement (no text or symbols)

FIG.1

FIG.2

FIG. 3

Line drawing of a birdcage with a lid and spout, emitting steam (no text or symbols)

Technical diagram of a birdcage with labeled parts 1, 2, and 15

11 3 4 10 5 9 6 8 7 14 12 13

功能特點 保養及維護

Diagram showing a sequence of bottle-shaped containers with different internal structures and packaging steps, likely illustrating a chemical or industrial process.

使用方法

Line drawing of a birdcage with vertical ribs and a lid, showing two directional arrows (no text or symbols)

Line drawing of a laboratory setup with a beaker, dropping funnel, and liquid droplets (no text or symbols)

Simple line drawing of a funnel and a container with directional arrows (no text or symbols)

FIG 2

Technical diagram of a circular component with internal fan and terminal elements, no readable text or symbols

FIG 3

美の儀

Utsushii

糖果罐香熏加湿器

使用说明书 HWI0005

产品零部件

Line drawing of a birdcage with a lid and steam rising from its top (no text or symbols)

Technical diagram of a birdcage with labeled parts 1, 2, and 15

11 3 4 10 5 9 6 8 7 14 12 13

功能特点 保养及维护

Illustration of six different types of spray bottles and containers, arranged in a row (no text or symbols)

使用方法

Line drawing of a birdcage with vertical ribs and a lid, showing upward and downward arrows (no text or symbols)

Line drawing of a laboratory setup with a beaker, dropping funnel, and liquid (no text or symbols)

Simple line drawing of a funnel and a cylindrical container with upward and downward arrows (no text or symbols)

FIG 2

R R R R 7000

FIG 3
