Product Type	3-in-1 multifunction appliance: grill, raclette, and fondue
Brand	Klarstein
Model	Entrecôte
Item Number	10034138, 10035419
Power Supply	220-240 V ~ 50/60 Hz
Power	1100 W
Approx. Dimensions	40 x 30 x 20 cm (estimated)
Approx. Weight	3 kg (estimated)
Number of Raclette Pans	8
Number of Fondue Forks	8
Grill Plate Material	Non-stick coating
Fondue Pot Capacity	Indicated by MAX fill line
Temperature Control	Adjustable thermostat with indicator light
Functions	Grilling, raclette, fondue
Care and Cleaning	Plate and pans washable with soapy water; base wiped with a damp cloth
Safety	No automatic shut-off; hot surfaces; do not immerse base
Spare Parts and Repairability	Contact manufacturer Chal-Tec GmbH for parts
Intended Use	Household use only
Recycling Information	Do not dispose of with household waste; take to a collection point
Warranty	See manufacturer's conditions

Frequently Asked Questions - Entrecôte Klarstein

How to start the appliance for the first time?

Before first use, heat the appliance empty for 10 minutes. Some smoke may be emitted, ventilate the room. Allow to cool, then clean the plate and pans.

What is the power of the appliance?

The appliance has a power of 1100 W under a voltage of 220-240 V ~ 50/60 Hz.

Can I use metal utensils on the plate?

No, avoid hard or sharp objects to not scratch the non-stick coating. Use wooden or silicone utensils.

How to clean the grill plate?

Wash the plate and pans with warm soapy water, rinse and dry. The base must never be immersed in water, clean it with a damp cloth.

Does the appliance turn off automatically?

No, the appliance does not have automatic shut-off. You must unplug it after use and never leave it unattended.

Can I make fondue with this appliance?

Yes, place the fondue pot in the center of the cooking plate and use the fork holder. Do not exceed the MAX fill line.

What to do if the red indicator light does not turn on?

Check that the appliance is plugged in and the thermostat is turned to a setting. If the problem persists, contact after-sales service.

What types of food can I grill?

You can grill meat, fish, seafood, and vegetables. Cut food into thin slices for even cooking.

How to adjust the cooking temperature?

Turn the thermostat knob to select the desired temperature. The red indicator light turns on and off to maintain the temperature.

Is the appliance suitable for children?

The appliance can be used by children aged 8 and above under supervision. Surfaces become very hot: risk of burns.

USER MANUAL Entrecôte Klarstein

QR code image containing encoded data, no visible human-readable text

INHALTSVERZEICHNIS

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Unit 6 Riverside Business Centre

Brighton Road

Shoreham-by-Sea

BN43 6RE

United Kingdom

Dear Customer,

Congratulations on purchasing this device. Please read the following instructions carefully and follow them to prevent possible damages. We assume no liability for damage caused by disregard of the instructions and improper use. Scan the QR code to get access to the latest user manual and more product information.

QR code image containing encoded data, no visible human-readable text

CONTENT

Safety Instructions 10

Product Overview 11

Use and Operation 11

Cleaning and Care 13

Hints on Disposal 13

Producer 13

TECHNICAL DATA

Item number 10034138, 10035419
Power supply 220-240 V ~ 50/60 Hz
Power consumption 1100 W

SAFETY INSTRUCTIONS

• Children are not aware of the dangers of electrical appliances. Never leave the appliance unattended during use. Therefore always keep the appliance outside the reach of children.
• The appliance is only suitable for household use. Never use the appliance outdoors.
• Certain parts of the appliance may become hot during use. Refrain from touching these areas so as not to burn yourself.
• Make sure that the appliance and the power cable never come into contact with hot devices such as hotplate or naked flames.
• Do not allow the power cable to hang down over the edge of the sink, worktop or table.
• Make sure your hands are dry when you touch the appliance, the power cable or the plug.
• Never submerge the appliance in water or another liquid.
• The appliance needs to dissipate its heat in order to prevent fire. Therefore it is vital to make sure that the appliance has sufficient clearance on all sides and cannot come into contact with flammable materials. The appliance may not be covered up.
• Do not use the appliance near explosives or fl ammable materials.
• Do not use a metal scouring pad to clean the appliance. Fragments of metal could come loose and touch the appliance's electrical parts causing it to short circuit.
• Always switch the appliance off if: it malfunctions while you are using it, before you start maintenance, if you fit or remove accessories and if you unplug the appliance.
• Only use an extension cord that is in good condition.
• Never switch the appliance off by pulling the cable.
• Always engage a recognised, trained service engineer if the appliance or the cable is damaged, malfunctions
  • have occurred and/or the appliance requires repairs.
• Carrying out your own or having inexpert repairs carried out can cause considerable danger for the user.
• We accept no liability for damage caused by incorrect usage or the ignoring of the regulations in this manual.
• When the appliance is not in use and before cleaning, unplug the appliance from the outlet.
  • Children should be supervised to ensure that they do not play with the appliance.
  • Children should be supervised to ensure that they do not play with the appliance.
• This device may be only used by children 8 years old or older and persons with limited physical, sensory and mental capabilities and / or lack of experience and knowledge, provided that they have been instructed in use of the device by a responsible person who understands the associated risks.

CAUTION

Risk of burns! The temperature of accessible surfaces may be high when the appliance is operating. Do not touch them.

PRODUCT OVERVIEW

1	Fondue forks (8)	4	Raclette Pans (8)
2	grill plate	5	thermostat regulator
3	fondue pot	6	Fondue fork holder

USE AND OPERATION

Before first use

• Before using for the first time, operate the appliance for 10 minutes without any food. This in order to remove the "new" scent. A small amount of smoke may also be noticeable. Ventilate the room during this period.
• Let de grill plate and the mini pans cool down en clean them (see chapter Cleaning and Care).

Operation

1 Place the grill plate on the appliance and make sure that it is firmly seated.
2 If you want to prepare fondue, place the fondue pot in the middle of the grill plate and place the fondue fork holder over the fondue pot.
3 Switch on the appliance and heat the raclette by turning the thermostat knob to the MAX position. The red control light will illuminate. We recommend that you apply a layer of cooking oil to the grill plate. If fondue pot and grill plate are used, the raclette should be preheated for approx. 5 minutes.

Note: If you are using the raclette for the first time, there may be a slight smell and smoke. This should disappear after a few minutes and is normal.

4 When the appliance is preheated, put the ingredients in the raclette pans, on the grill plate and in the fondue pot.
5 Place the raclette pans on the heating base under the grill plate.

Note: Do not preheat the pans and do not overfill the pans. When making fondue, do not fill the fondue pot with ingredients beyond the MAX filling line.

6 Turn the thermostat knob to set the desired temperature.
7 During cooking, the red control light turns on and off to maintain the set temperature. Use the forks supplied to hold the ingredients in the fondue pot.
8 After use, turn the appliance off and unplug it from the wall outlet. The red control lamp goes out.

Cooking tips

• To cook more evenly and quickly, cut raw meat into thin slices or small pieces. Always cook raw meat on the grill or stone plate and never in pans.
• Turn meat, fish, seafood and vegetables regularly when grilling. Cook the meat thoroughly.
• For more flavour, marinate meat and vegetables before cooking when using the grill plate. Be careful as marinated foods fry faster. Never use oil or marinated ingredients on the stone plate as this can change the nat

CLEANING AND CARE

• Before cleaning the appliance, always make sure that the plug has been removed from the supply socket. Allow the appliance to cool down before cleaning.
• The grill pan and the mini pans can be washed in hot soapy water. Rinse and dry thoroughly. Never use hard or sharp objects on the non-stick baking surface. The surface can be damaged easily by scratching.
• You can clean the exterior with a damp cloth and dry afterwards. Never immerse the appliance in water. Do not use abrasive cleaners, these can cause damage to the material.

DISPOSAL CONSIDERATIONS

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

If there is a legal regulation for the disposal of electrical and electronic devices in your country, this symbol on the product or on the packaging indicates that this product must not be disposed of with household waste. Instead, it must be taken to a collection point for the recycling of electrical and electronic equipment. By disposing of it in accordance with the rules, you are protecting the environment and the health of your fellow human beings from negative consequences. For information about the recycling and disposal of this product, please contact your local authority or your household waste disposal service.

MANUFACTURER & IMPORTER (UK)

Manufacturer:

Chal-Tec GmbH, Wallstrasse 16, 10179 Berlin, Germany.

Importer for Great Britain:

Chal-Tec UK limited

Unit 6 Riverside Business Centre

Brighton Road

Shoreham-by-Sea

BN43 6RE

United Kingdom
