USER MANUAL MO125236 Emerio

1. This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

2. Children shall not play with the appliance.

3. Cleaning and user maintenance shall not be made by

children unless they are older than 8 and supervised.

4. Keep the appliance and its cord out of reach of children less

5. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

6. The door or the outer surface may get hot when the

appliance is operating.

7. WARNING: If the surface is cracked, switch off the appliance

to avoid the possibility of electric shock.

8. Before the appliance is used, the main body as well as any

attachment fitted should be checked thoroughly for any defects.

9. Protect against electrical shock, do not immerse cord, plug

or body in water or any other liquid.

10. Always plug the appliance into an earthed plug socket.

11. Unplug from power outlet when not in use and before

cleaning. Allow to cool completely before putting on or taking off parts.

12. While using the oven, do not apply water to the glass door,

otherwise the door may get broken.

13. Do not operate the appliance with a damaged cord or plug- 3 -

or after the appliance malfunctions, or has been damaged in any manner. Return appliance to the distributor (or any authorized service facility) for examination, repair or adjustment.

14. The use of accessory attachments not recommended by us

15. Do not use outdoors.

17. Do not place the appliance on or near heat sources such as

a gas or electric burner.

18. Caution must be taking hard when putting in or removing

food out from appliance.

19. Do not leave the appliance unattended while in use and

remove the plug from wall socket after use.

20. Do not position or operate the appliance close to or

underneath any wall-cupboards or hanging objects such as curtains or any inflammable materials, and do not position any objects on top of the appliance.

21. Warning: When in use, the oven is hot! Never touch the hot

surfaces and the glass door. Use handles or knobs.

22. The oven can’t be put into the water or washed with water.

23. This product is for household use only.

24. The appliance should be stood on a level, stable and clean

surface while it is in use.

25. This appliance is not intended to be operated by means of

an external timer or separate remote-control system.

26. When operating the oven, keep at least four inches of free

space on all sides (except back side) of the oven to allow for adequate air circulation. And the rear surface of appliances shall be placed against wall.

27. The oven must be placed against a wall. Regarding the

information pertaining to the cleaning of the appliance, please refer to the below paragraph of the manual.- 4 -

Caution, hot surface. WARNING!! Please do not touch surface while in use. The temperature of accessible surfaces may be high when the appliance is operating.

29. Do not cover any part of the oven with metal foil. This may

cause overheating of the oven.

30. Do not place any of the following materials in the oven:

cardboard, plastic, paper, or anything similar. Do not store any materials, other than manufacturer’s recommended accessories, in this oven when not in use.- 5 - MO-125236 EN

BEFORE USE Remove all packaging materials from the appliance. Clean the appliance according to the section “HOW TO CLEAN” below. Make sure the appliance is unplugged. Before initial use, it is recommended that you run the oven with the function “ ” for approximately 15 minutes to eliminate the remaining packing residue and odor. NOTE: Initial start-up operation may result in slight smell and smoke. It is due to the burning of protective substance applied to the heating elements. This is normal and harmless. OPERATION

1. Place the appliance on a flat and heat resistant surface. Make sure that there is enough ventilation around

2. Insert the power plug into the socket.

3. Slide the wire rack with food into the slot of the appliance. And then slide the baking tray under the wire

rack to collect the dripping oils. You can also directly put food on the baking tray itself. Choose your desired

rack position according to the food height and type.

4. Close the oven door, and turn the function knob to choose the desired function “ ” (The top element will

heat.), “ ” (The bottom element will heat.), or “ ” (Both top and bottom elements heat simultaneously.). Turn the temperature knob to choose the desired temperature.

5. Close the oven door. Turn the big hotplate knob “ ” and/or small hotplate knob “ ” to choose the

desired heating level from 1/ 2/ 3/ MAX. The bigger numeral stands for higher heating level. The big and/or small hotplate will work. To turn the hotplate(s) off, just turn the hotplate knob(s) to the position “OFF”.

6. When using both hotplates and the oven at the same time the power consumption will be 3200 watt. This

will demand that you use the product with a home fuse of 16 ampere. If the home is using a 10 ampere fuse we don't recommend to use all functions at the same time.

7. The inner lamp, helping you check the food status, automatically shines on when the oven is working. This

oven has no timer, you should always switch off the oven manually by turning the function knob to the position “OFF” when the proper time has passed. Note: The corresponding indicator light shines on when the oven / hotplate is working.

15-25 WARNING：Food should not touch the heating elements. This table is for reference only, always keep an eye on the baking process. Note:

1. For the best taste, preheating is recommended.

2. Try to place the food on the backing tray evenly.

3. Wire rack should be positioned with the indentations pointing down.

4. The weight of the food which is put on the baking tray/wire rack cannot be over 3.5kg.

Caution: Always use extreme care when removing baking tray, wire rack or any hot container from a hot oven. Always use an oven mitt when removing hot items from the oven.

1. Unplug the supply cord from the power outlet.

2. Let the appliance cool down completely.

3. Clean the housing with a damp, lint-free cloth. DO NOT IMMERSE THIS APPLIANCE INTO WATER.

4. Clean the door, the inside walls with wet and dry cloth. Do not use abrasive detergents.

5. Wash the wire rack and baking tray in hot soapy water. Rinse and dry.

6. Only Wire rack and tray handle can be cleaned in a dishwasher.

Before delivery our devices are subjected to rigorous quality control. If, despite all care, damage has occurred during production or transportation, please return the device to your dealer. In addition to statutory legal rights, the purchaser has an option to claim under the terms of the following guarantee: For the purchased device we provide 2 years guarantee, commencing from the day of sale. If you have a defective product, you can directly go back to the point of purchase. Defects which arise due to improper handling of the device and malfunctions due to interventions and repairs by third parties or the fitting of non-original parts are not covered by this guarantee. Always keep your receipt, without the receipt you can’t claim any form of warranty. Damage caused by not following the instruction manual, will lead to a void of warranty, if this results in consequential damages then we will not be liable. Neither can we hold responsible for material damage or personal injury caused by improper use if the instruction manual is not properly executed. Damage to accessories does not mean free replacement of the whole appliance. In such case please contact our service department. Broken glass or breakage of plastic parts is always subject to a charge. Defects to consumables or parts subjected to wearing, as well as cleaning, maintenance or the replacement of said parts are not covered by the warranty and are to be paid.

25-35 MIN LAMMKOTELETT

25-35 MIN FISCHFILETS

25-35 MIN LAMMKOTLETTER

6. The door or the outer surface may get hot when the

appliance is operating.

7. WARNING: If the surface is cracked, switch off the appliance

to avoid the possibility of electric shock.
