USER MANUAL GSLV70PZTM LG

OWNER'S MANUAL FRIDGE & FREEZER Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH MFL71798879 Rev.00_081822 www.lg.com Copyright © 2021-2022 LG Electronics Inc. All Rights Reserved. Refer to the owner’s manual on LG website for more detailed information. global_main.book.book Page 1 Monday, May 16, 2022 8:26 AMTABLE OF CONTENTS This manual may contain images or content that may be different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS

The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’

described below. Safety Messages WARNING WARNING To reduce the risk of explosion, fire, death, electric shock, injury or scalding to persons when using this product, follow basic precautions, including the following: Technical Safety

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the This symbol is displayed to indicate matters and operations that can cause risk. Read the part with this symbol carefully and follow the instructions in order to avoid risk. WARNING This indicates that the failure to follow the instructions can cause serious injury or death. CAUTION This indicates that the failure to follow the instructions can cause the minor injury or damage to the product. global_main.book.book Page 3 Monday, May 16, 2022 8:26 AM4 SAFETY INSTRUCTIONS appliance. Cleaning and user maintenance shall not be made by children without supervision.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

• Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.

• This appliance is intended to be used in household and similar applications such as: - staff kitchen areas in shops, offices and other working environments; - farm houses and by clients in hotels, motels and other residential type environments; - bed and breakfast type environments; - catering and similar non-retail applications.

• This refrigerating appliance is not intended to be used as a built-in appliance.

• This appliance contains a small amount of isobutane refrigerant (R600a), but it is also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

• The refrigerant and insulation blowing gas used in the appliance require special disposal procedures. Consult with service agent or a similarly qualified person before disposing of them.

• Do not damage the refrigerant circuit.

• If the power cord is damaged or the hole of the outlet socket is loose, do not use the power cord and contact an authorized service centre. This symbol alerts you to flammable materials that can ignite and cause a fire if you do not take care. global_main.book.book Page 4 Monday, May 16, 2022 8:26 AM5 SAFETY INSTRUCTIONS ENGLISH

• Do not locate multiple portable outlet sockets or portable power supplies at the rear of the appliance.

• Securely plug the power plug in the outlet socket after completely removing any moisture and dust.

• Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the outlet socket.

• Keep ventilation openings, in the appliance enclosure or in the built- in structure, clear of obstruction.

• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

• Do not tilt the appliance to pull or push it when transporting.

• When positioning the appliance, ensure the supply cord is not trapped or damaged.

• Do not use mechanical devices or other means to accelerate the defrosting process.

• Do not use a hair drier to dry the inside of the appliance or place a candle inside to remove the odours.

• Do not use electrical appliances inside the refrigerator.

• Make sure not to get a body part such as a hand or foot stuck while moving the appliance.

• Disconnect the power cord before cleaning the appliance interior or exterior.

• Do not spray water or inflammable substances (toothpaste, alcohol, thinner, benzene, flammable liquid, abrasive, etc.) over the interior or exterior of the appliance to clean it.

• Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material.

• Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location. global_main.book.book Page 5 Monday, May 16, 2022 8:26 AM6 SAFETY INSTRUCTIONS Risk of Fire and Flammable Materials

• If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes. In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance is used should correspond to the amount of refrigerant used. The room must be 1 m² in size for every 8 g of R600a refrigerant inside the appliance.

• Refrigerant leaking out of the pipes could ignite or cause an explosion.

• The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance. Installation

• This appliance should only be transported by two or more people holding the appliance securely.

• Install the appliance on a firm and level floor.

• Do not install the appliance in a damp and dusty place. Do not install or store the appliance in any outdoor area, or any area that is subject to weathering conditions such as direct sunlight, wind, rain, or temperatures below freezing.

• Do not place the appliance in direct sunlight or expose it to the heat from heating appliances such as stoves or heaters.

• Be careful not to expose the rear of the appliance when installing.

• Install the appliance in a place where it is easy to unplug the power plug of the appliance.

• Be careful not to let the appliance door fall during assembly or disassembly.

• Be careful not to pinch, crush, or damage the power cable during assembly or disassembly of the appliance door.

• Be careful not to point the power plug up or let the appliance lean against the power plug.

• Do not connect a plug adapter or other accessories to the power plug. global_main.book.book Page 6 Monday, May 16, 2022 8:26 AM7 SAFETY INSTRUCTIONS ENGLISH

• Do not modify or extend the power cable.

• Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.

• This appliance is equipped with a power cord having an equipment- grounding conductor and a grounding power plug. The power plug must be plugged into an appropriate outlet socket that is installed and grounded in accordance with all local codes and ordinances.

• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.

• Do not plug the appliance into a multi socket adapter which does not have a power cable (mounted).

• The appliance should be connected to a dedicated power line which is separately fused.

• Do not use a multi socket outlet which is not properly grounded (portable). In case of using a properly-grounded multi socket outlet (portable), use the multi socket outlet with the current capacity of the power cord rating or higher and use the multi socket outlet only for the appliance.

• Dispose of all packaging materials (such as plastic bags and styrofoam) away from children. The packaging materials can cause suffocation. Operation

• Do not use the appliance for any purpose (storage of medical or experimental materials or shipping) other than any domestic household food storage use.

• If water penetrates electrical parts of the appliance, disconnect power plug and contact an LG Electronics customer information centre.

• Unplug the power plug during a severe thunderstorm or lightening or when not in use for a long period of time. global_main.book.book Page 7 Monday, May 16, 2022 8:26 AM8 SAFETY INSTRUCTIONS

• Do not touch the power plug or the appliance controls with wet hands.

• Do not bend the power cable excessively or place a heavy object on it.

• Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.

• Do not place hands or metallic objects inside the area emitting the cold air, cover or heat releasing grille on the back.

• Do not apply excessive force or impact to the back cover of the appliance.

• Be careful of nearby children when you open or close the appliance door. The door may bump the child and cause injury.

• Avoid the danger of children getting trapped inside the appliance. A child trapped inside the appliance can cause suffocation.

• Do not put animals, such as pets into the appliance.

• Do not place heavy or fragile objects, containers filled with liquid, combustible substances, flammable objects (such as candles, lamps, etc.), or heating devices (such as stoves, heaters, etc.) on the appliance.

• Do not place any electronic appliance (such as heater and mobile phone) inside the appliance.

• If there is a gas leakage (isobutane, propane, natural gas, etc.), do not touch the appliance or power plug and ventilate the area immediately. This appliance uses a refrigerant gas (isobutane, R600a). Although it uses a small amount of the gas, it is still combustible gas. Gas leakage during appliance transport, installation or operation can cause fire, explosion or injury if sparks are caused.

• Do not use or store flammable or combustible substances (ether, benzene, alcohol, chemical, LPG, combustible spray, insecticide, air freshener, cosmetics, etc.) near the appliance. global_main.book.book Page 8 Monday, May 16, 2022 8:26 AM9 SAFETY INSTRUCTIONS ENGLISH Disposal

• When discarding the appliance, remove the door gasket while leaving the shelves and baskets in place and keep children away from the appliance. CAUTION CAUTION To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: Installation

• After unpacking, check the appliance for any damage that may have occurred during transit.

• Wait for at least 3 to 4 hours in order to ensure the refrigerant circuit is fully efficient. Operation

• Do not touch frozen food or the metal parts in the freezer compartment with wet or damp hands. It may cause frostbite.

• Do not place glass containers, bottles or cans (especially those containing carbonated drinks) in the freezer compartment, shelves or ice bin that will be exposed to temperatures below freezing.

• The tempered glass on the front side of the appliance door or the shelves can be damaged by an impact. If it is broken, do not touch it with hands.

• Do not hang from the appliance doors, storage room, shelf or climb up into it.

• Do not store an excessive amount of water bottles or containers for side dishes on the door baskets.

• Do not open or close the appliance door with excessive force. global_main.book.book Page 9 Monday, May 16, 2022 8:26 AM10 SAFETY INSTRUCTIONS

• If the hinge of the appliance door is damaged or operates improperly, stop using the appliance and contact an authorized service centre.

• Prevent animals from nibbling on the power cable or water hose.

• Never eat frozen foods immediately after they have been taken out in the freezer compartment.

• Make sure not to get a hand or foot stuck upon opening or closing the appliance door or door in door. Maintenance

• This appliance is equipped with maintenance-free LED interior light. Do not remove cover or LED lamp in any attempt to repair or change it. Contact an LG Electronics customer information centre.

• Do not clean glass shelves or covers with warm water when they are cold. They may shatter if exposed to sudden temperature changes.

• Do not insert the shelves upside down. The shelves may fall.

• To remove frost from the appliance, contact an LG Electronics customer information centre.

• Dispose of the ice inside the ice bin in the freezer compartment during an extended power outage. global_main.book.book Page 10 Monday, May 16, 2022 8:26 AM11 INSTALLATION ENGLISH INSTALLATION Before Installation Dimensions and Clearances Too small of a distance from adjacent items may result in the degradation of freezing capability and increased electricity costs. Allow over 50 mm of clearance between the back of the appliance and the wall when installing the appliance. NOTE

• You can determine what type of appliance it is by looking at the label inside the appliance. Ambient Temperature
• The appliance is designed to operate within a limited range of ambient temperatures, depending on the climate zone.• The internal temperatures could be affected by the location of the appliance, the ambient temperature, the frequency of door opening and so on.• The climate class can be found on the rating label.* Australia, India, Kenya** Argentina NOTE

• The appliances rated from SN to T are intended to be used at an ambient temperature between 10 ºC and 43 ºC.- Size (mm) A913 B1 790 C735 D620 E691 F735 G1 180H1 635

Climate Class Ambient Temperature Range ºCSN (Extended Temperate)+10 - +32N (Temperate) +16 - +32ST (Subtropical) +16 - +38 / +18 - +38**T (Tropical) +10 - +43* / +16 - +43 / +18 - +43** global_main.book.book Page 11 Monday, May 16, 2022 8:26 AM12 INSTALLATION Accessories *1 This feature is only available on some models. Spanner A

Tube Connector and Clip

Tube Connector and Valve

Removing the Fridge and Freezer Door If your entrance door is too narrow for the appliance to pass through, remove the appliance doors and pass the appliance laterally. WARNING

• Disconnect the power cord, house fuse or circuit breaker before installing, removing the doors, or cleaning the appliance. Failure to follow these instructions may result in death, fire or electric shock. Removing the Freezer Door

The water supply line is connected to the top right part in the back of the appliance. Hold the water supply connection and gently push the collet to detach the water supply line. Unscrew the cover

Remove the screw from the hinge cover at the top of the appliance. Lift the hook, located at the bottom of the front side of the cover, with a flat-head screwdriver. Pull out the tube . Unscrew the ground wire . Disconnect all wire harnesses

• The number of wire harnesses may vary depending on the model.global_main.book.book Page 12 Monday, May 16, 2022 8:26 AM13 INSTALLATION ENGLISH

• When lifting the hinge free of the latch, be careful that the door does not fall forward. It is recommended that two or more people carry out the door removal and refitting. Lift the freezer door until it is free of the bottom hinge assembly. CAUTION

• Place the door on a non-scratching surface with the inner side facing up. Removing the Fridge Door

Disconnect all wire harnesses

• The number of wire harnesses may vary depending on the model. Rotate the hinge lever clockwise. Lift the top hinge free of the hinge lever latch

• When lifting the hinge free of the hinge lever latch, be careful that the door does not fall forward. It is recommended that two or more people carry out the door removal and refitting. Lift the fridge door until it is free of the bottom hinge assembly.global_main.book.book Page 13 Monday, May 16, 2022 8:26 AM14 INSTALLATION CAUTION

• Place the door on a non-scratching surface with the inner side facing up. Refitting the Fridge and Freezer Door Refit the doors in the reverse sequence of their removal once the appliance has been passed through all access doors. CAUTION

• Install the fridge door first. NOTE

• Disassembling/Assembling the water lines Collet Tube Insert line Clip• Gently insert the tube until only one of the tube’s lines is visible. Pull on the tube to make sure that it is tightly fastened.• If the water tube end is damaged, it should be trimmed to ensure it does not leak when refitted. Not straight Damaged Stretched Connecting the Water Line This feature is only available on some models. Water Supply Requirements Connect the appliance to a cold water supply with a maximum inlet water pressure not exceeding 1.0 MPa. A water pressure between 138kPa and 827kPa is recommended for the optimal operation of the water dispenser. If the refrigerator is installed in an area with low water pressure (below 138 kPa), you can install a booster pump to compensate for the low pressure.If a reverse osmosis water filtration system is connected to your cold water supply, the water pressure to the reverse osmosis system needs to be a minimum of 138 kPa. WARNING

• Unplug the appliance before carrying out any work on connecting the water line. Failure to do so may cause electric shock.• Only connect the water line to a cold water supply. Failure to do so may cause the water filter to malfunction. Water hammer (water banging in the pipes) in house plumbing can cause damage to appliance parts and can lead to water leakage or flooding.• Connect to potable water supply only.• Connecting the water line must only be installed by a qualified plumber and in accordance with local legislation and regulations governing water quality. NOTE

• This water line installation is not covered by the appliance warranty.CorrectIncorrectglobal_main.book.book Page 14 Monday, May 16, 2022 8:26 AM15 INSTALLATION ENGLISH Connecting Water to the Appliance

Unscrew the metal threaded collar nut at the back of the appliance and place it over one end of the water tube. Firmly push the water tube onto the water inlet valve and tighten up the collar nut. Connecting to the Water Tap This feature is only available on some models. Push the water tube into the hole of the tap connector supplied in the accessories. The pipe should be held firmly whilst the connector is pushed onto the pipe. Ensure that the rubber washer is fitted to the inside of the tap connector before screwing it onto the tap.• A separate connector or adaptor may need to be purchased if your tap fitting does not match the thread size of the connector provided. NOTE Only For Germany• Connect your appliance only to a water tap with a safety device (according to EN 1717) to avoid drinking water pollution through water backflow.• To be sure, please ask your installer. In case water tap is without backflow prevention valve (according to EN 1717), you have to use an extra backflow prevention valve compliant with German drinking water ordinance between water tap and water inlet hose. Checking the Water Connection

Turn on the water supply and switch on the appliance. Carefully check all fittings for possible leaks due to poorly fitted hoses. Press and hold the Water Filter button for three seconds. The new water filter has been activated. Place a cup under the water dispenser to verify that water is flowing through the appliance. Check the connecting tube and joints for leaks once again. Turning on the Power Connecting the Appliance After installing the appliance, connect the power plug into the outlet socket. Do not double up with other appliances on the same outlet. NOTE

• After connecting the power supply cord (or plug) to the outlet, wait 3 or 4 hours before you put food into the appliance. If you add food before the appliance has cooled completely, your food may spoil.global_main.book.book Page 15 Monday, May 16, 2022 8:26 AM16 INSTALLATION NOTE

• To turn off the appliance, disconnect the power plug from the socket outlet. Moving the Appliance for Relocation Preparing for Relocation

Remove all food from inside the appliance. Pull the power plug out, insert and fix it into the power plug hook at the rear or on top of the appliance. Tape parts such as shelves and the door handle to prevent from falling off while moving the appliance. Move the appliance with more than two people carefully. When transporting the appliance over a long distance, keep the appliance upright. After installing the appliance, connect the power plug into a mains outlet socket and switch it on.global_main.book.book Page 16 Monday, May 16, 2022 8:26 AM17 OPERATION ENGLISH OPERATION Before Use Notes for Operation

• Users should keep in mind that frost can form if the door is not closed completely or if the humidity is high during the summer.• Ensure there is sufficient space between food stored on the shelf or door basket to allow the door to close completely.• Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance.• If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance. Door Open Alarm The alarm sounds 3 times in 30 second intervals if the door is left open or not completely closed for 1 minute. NOTE

• Contact the LG Electronics customer information centre if the alarm sound continues even after closing all doors. High Temperature Alarm The high temperature alarm is a function that warns when the temperature of the freezer increases enough to be a problem. The freezer temperature display LED flashes and the alarm sounds.• This alarm sounds in the following cases:- When the appliance is turned on for the first time (therefore the freezer temperature is high).- When the freezer door is open for a long time or opens very frequently.- When the power goes out for a long period of time.- When larger amounts of hot food are placed into the freezer.• Turning off the Alarm- Press the Freezer button until the alarm stops ringing. Failure Detection The appliance can automatically detect problems during the operation. NOTE

• If a problem is detected, the appliance may not operate and an error code is displayed even when any button is pressed.• If an error code is indicated on the display, do not turn off the power. Immediately contact the LG Electronics customer information centre and report the error code. If you turn off the power, the repair technician from the our information centre may have difficulty finding the problem. Suggestion for Energy Saving
• For the most efficient use of energy, keep all inner parts (e.g. door bins, drawers and shelves) on their original location.• Ensure there is sufficient space between stored foods. This allows cold air to be circulated evenly and lowers electricity bills.• Store hot food only after it has cooled in order to prevent dew or frost.• When storing food in the freezer compartment, set the freezer temperature lower than the temperature indicated on the food.• Do not set the temperature of the appliance lower than needed.• Do not put food near the temperature sensor of the fridge compartment. Keep a distance of at least 3 cm from the sensor.global_main.book.book Page 17 Monday, May 16, 2022 8:26 AM18 OPERATION
• Note that a temperature rise after defrosting has a permissible range in the appliance specifications. If you wish to minimise the impact on the food storage due to a temperature rise, seal or wrap the stored food in several layers.• The automatic defrosting system in the appliance ensures that the compartment remains free of ice buildup under normal operating conditions. Storing Foods Effectively
• Food may freeze or spoil if stored at the wrong temperature. Set the refrigerator to the correct temperature for the food being stored.• Store frozen food or refrigerated food inside sealed containers.• Check the expiration date and label (storage instructions) before storing food in the appliance.• Do not store food for a long period of time if it spoils easily at a low temperature.• Do not place unfrozen food in direct contact with food that is already frozen. It could be necessary to reduce the quantity to be frozen if freezing every day is anticipated.• Place the refrigerated food or frozen food in each fridge or freezer compartment immediately after purchasing.• Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food.• Refrigerated foods and other food items can be stored on top of the vegetable drawer.• Avoid refreezing any food which has been completely thawed. Freezing any food which has been completely thawed again will lower its taste and nutrition.• Do not overfill the appliance. Cold air can not circulate properly if the appliance is overfilled.• Cool hot food before storing. If too much hot food is placed inside, the internal temperature of the appliance can increase and negatively affect other foods stored in the appliance.• If you set an excessively low temperature for food, it may become frozen. Do not set a temperature lower than the required temperature for the food to be stored correctly.• If there are chill compartments in the appliance, do not store vegetables and fruits with higher moisture content in the chill compartments as they may freeze due to the lower temperature.• In the event of a blackout, call the electricity company and ask how long it is going to last.- You should avoid door openings while the power is off.- When the power supply gets back to normal, check the condition of the food. Maximum Freezing Capacity

Express Freeze must be switched on for 7 hours before fresh products are placed in the freezer compartment.• To get better air circulation, insert all inner parts like baskets and shelves. NOTE

• The max freezing capacity of your appliance is stated on the rating label inside the fridge compartment.• To have the maximum freezing capacity, we recommend that you set the freezer temperature to the coldest temperature setting. Freezing the Maximum Amount of Food If large quantities of food are to be stored, all the freezer drawers should be taken out of the appliance and the food should be stacked directly on the freezer shelves in the freezer compartment. CAUTION

• To remove the drawers, first remove the food from drawers and then pull out the drawers carefully. Not doing so could cause injury or damage to the drawers.global_main.book.book Page 18 Monday, May 16, 2022 8:26 AM19 OPERATION ENGLISH NOTE

• The shape of each drawer may be different, insert in the right position. Two Star Compartment

• Two star (a) basket or drawer can be used to store ice and food from -12 °C to -18 °C for short periods.

• Two star frozen food compartments are suitable for storing pre-frozen food, storing or making icecream and making ice cubes.

• Two star compartments are not suitable for the freezing of fresh food. Food Storage Compartments Storing Food in the Fridge Compartment

• Shelf - Store refrigerated foods and other food items. - Store the foods with higher moisture content at the front of the shelf.

• Fridge Drawer - Stores fruits and vegetables to keep fresh for as long as possible.

• Door Basket - Store small packages of refrigerated foods, drinks and sauce containers. Storing Food in the Freezer Compartment

• Freezer Shelf - Stores frozen food such as meat, fish, and ice cream. - To freeze food items quickly, store the food on the left side of the top shelf. If you need to store more food, store it on the shelves in order starting from the top shelf. Food items will freeze most quickly in the zone.

• Freezer Drawer - Stores frozen food for longer storage. - The bottom drawer is not 2 star compartment according to new energy labeling regulation (EU) 2019/2016.

• Freezer Door Basket - Stores small packages of frozen food. Do not store ice cream or food which will be stored for a long period of time. - The two baskets at the bottom are not 2 star compartment according to old energy labeling regulation (EU) 2010/1060. NOTE

• For more information about other compartments, visit lg.com and download owner’s manuals. global_main.book.book Page 19 Monday, May 16, 2022 8:26 AM20 OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This feature is only available on some models. Control Panel global_main.book.book Page 20 Monday, May 16, 2022 8:26 AM21 OPERATION ENGLISH Dispenser Control Panel

Fridge Press this button repeatedly to select a desired temperature between 1 °C and 7 °C.

• The default fridge temperature is 3 °C. NOTE

• The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within the appliance.

The Non Plumbing icon is illuminated when the water dispenser tank is installed correctly.

Freezer Press this button repeatedly to select a desired temperature between -23 °C and -15 °C.

UV light is used to keep the water outlet clean. UV clean function runs automatically for 10 minutes every hour or can be manually activated at anytime. Press this button to activate it manually. NOTE

• This function will momentarily stop each time the Water button is pressed if it is in operation and will resume the function after 1 hour.

• This function runs automatically for 10 minutes every hour without pressing the Self Care button.

• When UV clean function is activated the LED on the dispenser control panel lights up.

UVnano is a compound word derived from the words UV and its unit, nanometer.

Wi-Fi This button allows the appliance to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the LG ThinQ application.

Express Cool This function can quickly cool a large amount of foods such as vegetable, fruit and so on.

• This function is enabled and disabled in turn each time you press the button.

• This function automatically terminates after a specific period has passed.

Express Freeze This function can quickly freeze a large amount of ice or frozen foods. global_main.book.book Page 21 Monday, May 16, 2022 8:26 AM22 OPERATION

• Press the Express Freeze button to activate the function for 20 hours. The function automatically shuts off after 20 hours.

• This function is enabled and disabled in turn each time you press the button.

• This function automatically terminates after a specific period has passed.

Ice On/Off Press and hold the Ice On/Off button for three seconds to turn the automatic icemaker On/Off.

Lock The lock function disables every other button on the display.

• To lock the control panel buttons, press and hold the Lock button for 3 seconds until indicator light turns on and the function is activated.

• To disable the function, press and hold the Lock button for 3 seconds until the indicator light turns off and the function is deactivated.

Replace the water filter when the indicator light turns on.

Press the Craft Ice button to set to 6 ICE

• To change the Craft Ice mode:

Craft Ice button and the current mode appears.

Craft Ice button repeatedly to select a desired Craft Ice mode.

3) After 5 seconds of idle time, the last mode set will be saved, and the display will return to normal.

Select the desired dispenser mode from the buttons on the dispenser control panel. Press the dispenser switch with a glass or other container to dispense cubed ice, water or crushed ice. NOTE

• For optimal food preservation, increasing or decreasing 1 °C from the default temperature is recommended for each compartment.

• The displayed temperature is the target temperature, and not the actual temperature inside the appliance.

• The actual temperature inside the appliance depends on the following factors: room temperature, the amount of food and how often the doors are opened, where the appliance is. Set the temperatures by considering these factors.

• If there is any finger or skin contacts to the control panel while cleaning it, the button function may operate.

• This appliance incorporates an earth connection for functional purposes only. global_main.book.book Page 22 Monday, May 16, 2022 8:26 AM23 OPERATION ENGLISH Ice and Water Dispenser Before Using the Ice and Water Dispenser *1 This feature is only available on some models. WARNING

• Fill with potable water only into icemaker or dispenser water tank.• Do not fill the water tank with drinks other than water or fill with hot water. CAUTION

• Keep children away from the dispenser to prevent children playing with or damaging the controls.• Throw away the first few batches of ice (about 20 cubes and 7 cups of water). This is also necessary if the appliance has not been used for a long time.• Clean the water dispensing system if they have not been used for 48 hours. Flush the water system connected to a water supply if water has not been drawn for 5 days.• To clean the water dispensing system, flush the water through the dispenser about 5 minutes and throw away the first few batches of ice.• Do not use a thin crystal cup or chinaware when dispensing water or ice. NOTE

• If you open the freezer door while water is being dispensed, the water dispensing will stop.• If you open the fridge door while water, cubed ice or crushed ice is being dispensed, dispensing will be paused. When you close the door, the selected item will continue to be dispensed.• If the cup rim is small, water may splash out of the glass or miss it completely.• Use a cup with a rim of over 68 mm in diameter when dispensing water, cubed ice or crushed ice.• When the ice maker produces smaller ice cubes, or the cubes become lumped together, the amount of water supplied to the ice maker may be low due to insufficient water in the water tank. If ice is not used frequently or the freezer set temperature is too warm, it may also lump together.• It is normal for milky / cloudy water to be dispensed after replacing the water filter. This air in the water will eventually clear and is safe to drink during this transition.• Check if the water dispenser tank has been placed on the appliance correctly. If it is not assembled correctly, water may leak from the tank into the appliance.• If there is an insufficient amount of water in the water dispenser tank, ice cube size and quantity may be affected and may result in no ice being made.• Wait at least 15 seconds before removing the water tank after having dispensed water or ice from the dispenser. Before Using the In-Door Icemaker This feature is only available on some models.The icemaker produces ice normally when approximately 48 hours have passed after the appliance is initially installed. CAUTION

• It is normal for milky or cloudy water to be dispensed after replacing the water filter. This air in the water will clear eventually and is safe to drink.• The first ice and water dispensed may include particles or odour from the water supply line or the water tank.• If discolored ice is dispensed, check the water tank and the water supply for a possible source. If the problem continues, contact the LG Electronics customer information centre. Do not use the ice or water until the problem is corrected.• Do not touch the ice outlet or the automatic icemaker with your hand or a tool.global_main.book.book Page 23 Monday, May 16, 2022 8:26 AM24 OPERATION CAUTION

• Dispense ice into a glass before filling it with water or other beverages. Splashing will occur if ice is dispensed into a glass that already contains liquid.

• Never use a glass that is exceptionally narrow or deep. Ice may jam in the ice passage, affecting the performance of the appliance.

• Keep the glass at a proper distance from the ice outlet. A glass held too close to the outlet may prevent ice from dispensing.

• Dispose of the ice inside the ice bin if you go on vacation or if an extended power outage occurs. Water from melting ice may drop from the dispenser onto the floor. global_main.book.book Page 24 Monday, May 16, 2022 8:26 AM25 SMART FUNCTIONS ENGLISH SMART FUNCTIONS LG ThinQ Application This feature is only available on models with Wi-Fi. The LG ThinQ application allows you to communicate with the appliance using a smartphone. LG ThinQ Application Features Communicate with the appliance from a smartphone using the convenient smart features.Smart Diagnosis• If you experience a problem while using the appliance, this smart diagnosis feature will help you diagnose the problem.Settings• Allows you to set various options on the appliance and in the application. NOTE

• If you change your wireless router, internet service provider, or password, delete the registered appliance from the LG ThinQ application and register it again.• The application is subject to change for appliance improvement purposes without notice to users.• Functions may vary by model. Before Using LG ThinQ Application

Check the distance between the appliance and the wireless router (Wi-Fi network).• If the distance between the appliance and the wireless router is too far, the signal strength becomes weak. It may take a long time to register or installation may fail. Turn off the Mobile data Cellular Data your smartphone. Connect your smartphone to the wireless router. NOTE

• To verify the Wi-Fi connection, check that the Wi-Fi indicator on the control panel is lit.• The appliance supports 2.4 GHz Wi-Fi networks only. To check your network frequency, contact your Internet service provider or refer to your wireless router manual. LG ThinQ is not responsible for any network connection problems or any faults, malfunctions, or errors caused by network connection.• If the appliance is having trouble connecting to the Wi-Fi network, it may be too far from the router. Purchase a Wi-Fi repeater (range extender) to improve the Wi-Fi signal strength.• The Wi-Fi connection may not connect or may be interrupted because of the home network environment.• The network connection may not work properly depending on the Internet service provider.• The surrounding wireless environment can make the wireless network service run slowly.• The appliance cannot be registered due to problems with the wireless signal transmission. Unplug the appliance and wait about a minute before trying again.global_main.book.book Page 25 Monday, May 16, 2022 8:26 AM26 SMART FUNCTIONS NOTE

• If the firewall on your wireless router is enabled, disable the firewall or add an exception to it.

• The wireless network name (SSID) should be a combination of English letters and numbers. (Do not use special characters.)

• Smartphone user interface (UI) may vary depending on the mobile operating system (OS) and the manufacturer.

• If the security protocol of the router is set to WEP , you may fail to set up the network. Please change it to other security protocols ( WPA2

recommended) and register the product again. Installing the LG ThinQ Application Search for the LG ThinQ application from the Google Play Store or Apple App Store on a smartphone. Follow instructions to download and install the application. Connecting to Wi-Fi The Wi-Fi button, when used with the LG ThinQ application, allows the appliance to connect to a home Wi-Fi network. The Wi-Fi indicator shows the status of the appliance’s network connection. The Wi-Fi indicator illuminates when the appliance is connected to the Wi-Fi network.

Initial Appliance Registration Run the LG ThinQ application and follow the instructions in the application to register the appliance.

Re-registering the Appliance or Registering Another User Press and hold the Wi-Fi button for 3 seconds to temporarily turn it off. Run the LG ThinQ application and follow the instructions in the application to register the appliance. NOTE

• To disable the Wi-Fi function, press and hold the Wi-Fi button for 3 seconds. The Wi-Fi indicator will be turned off. Open Source Software Notice Information To obtain the source code under GPL, LGPL, MPL, and other open source licenses that have the obligations to disclose source code, that is contained in this product, and to access all referred license terms, copyright notices and other relevant documents please visit https:// opensource.lge.com. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. This offer is valid to anyone in receipt of this information for a period of three years after our last shipment of this product. global_main.book.book Page 26 Monday, May 16, 2022 8:26 AM27 MAINTENANCE ENGLISH MAINTENANCE Cleaning General Cleaning Tips
• Performing manual defrosting, maintenance or cleaning of the appliance while food is stored in the freezer can raise the temperature of the food and reduce its storage life.• Regularly clean any surfaces that can come in contact with food.• When cleaning the inside or outside of the appliance, do not wipe it with a rough brush, toothpaste, or flammable materials. Do not use cleaning agents containing flammable substances. This may cause discolouration or damage to the appliance.- Flammable substances: alcohol (ethanol, methanol, isopropyl alcohol, isobutyl alcohol, etc.), thinner, bleach, benzene, flammable liquid, abrasive, etc.• After cleaning, check if the power cable is damaged. Cleaning the Exterior
• When cleaning the outside air vents of the appliance by means of vacuuming, then the power cord should be unplugged from the outlet to avoid any static discharge that can damage the electronics or cause an electric shock. Regular cleaning of the rear and side ventilation covers is recommended to maintain reliable and economical operation of the unit.• Keep the air vents on the exterior of the appliance clean. Blocked air vents can cause fire or appliance damage.• For the appliance exterior, use a clean sponge or soft cloth and a mild detergent in warm water. Do not use abrasive or harsh cleaners. Dry thoroughly with a soft cloth. Do not use contaminated cloths when cleaning the stainless steel doors. Always use a dedicated cloth and wipe in the same direction as the grain. This helps reduce surface staining and tarnishing. Cleaning the Interior
• When removing a shelf or drawer from inside the appliance, remove all stored foods from the shelf or drawer to prevent injury or damage to the appliance. Otherwise, injury may occur due to the weight of stored foods.• Detach the shelves and drawers and clean them with water, and then dry them sufficiently, before replacing them.• Regularly wipe the door gaskets with a wet soft towel.• Door basket spills and stains should be cleaned as they can compromise storage ability of the basket and could even be damaged.• Never clean the shelves or containers in the dishwasher. The parts may become deformed due to the heat.• The automatic defrosting system in the appliance ensures that the compartment remains free of ice buildup under normal operating conditions. Users do not need to defrost it manually. Cleaning the Condenser Cover Use a vacuum cleaner with a brush to clean the condenser cover and vents. Do not remove the panel covering the condenser coil area.We recommend that this be done every 12 months to maintain operating efficiency.global_main.book.book Page 27 Monday, May 16, 2022 8:26 AM28 TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Customer Care and Service Contact an LG Electronics customer information centre.• To find information on LG authorized service centre, visit our website at www.lg.com.• Only qualified service personnel from LG authorized service centre should disassemble, repair, or modify the appliance.• The minimum warranty period of this refrigerating appliance is 24 months.• Spare parts referenced in Regulation EU 2019/2019 are available for 7 years (only door gaskets are available for 10 years).• To purchase spare parts, contact an LG Electronics customer information centre or our website at www.lg.com. NOTE

• Regulation EU 2019/2019, valid from 1st March 2021, is related to the Energy Efficiency classes by Regulation EU 2019/2016.
• For more information about the energy efficiency of the appliance, visit https://ec.europa.eu and search using the model name (valid from 1st March 2021).
• Scan the QR code on the energy label supplied with the appliance, which provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference and all other documents supplied with the appliance (valid from 1st March 2021).
• The model name can be found on the rating label of the appliance.• This product contains a light source of energy efficiency class G.global_main.book.book Page 28 Monday, May 16, 2022 8:26 AMРЪКОВОДСТВО ЗА ЕКСПЛОАТАЦИЯ ХЛАДИЛНИК И

bg_main.book.book Page 24 Thursday, March 3, 2022 1:03 PM25 ЕКСПЛОАТАЦИЯ

bg_main.book.book Page 28 Thursday, March 3, 2022 1:03 PM29

el_main.book.book Page 19 Thursday, March 3, 2022 11:26 AM20

el_main.book.book Page 21 Thursday, March 3, 2022 11:26 AM22

Express Cool el_main.book.book Page 23 Thursday, March 3, 2022 11:26 AM24

el_main.book.book Page 28 Thursday, March 3, 2022 11:26 AM29

mk_main.book.book Page 13 Thursday, March 3, 2022 1:17 PM14

Express Cool mk_main.book.book Page 22 Thursday, March 3, 2022 1:17 PM23

mk_main.book.book Page 27 Thursday, March 3, 2022 1:17 PM28

Desligue todas as cablagens

environment/take-back-recycling/global-network- to recycle LG products in your country”. Eliminação do seu aparelho usado
