USER MANUAL WS90211JM Atag

SAFETY Please read the separate safety instructions prior to use. Extraction systems Depending on the type, the cooker hoods can be connected in one of two ways:

1. To a duct. To a duct, the cooking vapours

extracted by suction are carried outside, once the grease particles have been filtered. This is the best method.

2. Recirculation hood. As a recirculation

hood, the grease particles and the smell in the extracted vapours are filtered. The air that has been sucked in is not carried outside but recirculates in the kitchen. In this case you must have a carbon filter fitted. Attention! The carbon filter needs to be ordered separately.EN 6 USE Controls PUSH Switching the extraction on and off Turn the rotating disk clockwise to switch on and increase the extraction speed. Turn counter-clockwise to decrease or switch off the extraction speed. The illumination around the edge of the rotating disk switches on to indicate the selected extraction speed.

• L1 lit: speed 1 (minimum).

• L1 + L2 + L3 + L4 lit in flashing mode: speed 4 (intensive). Lasting for 5 minutes, then the hood is placed automatically at speed 2.

• L1 + L2 + L3 + L4 off: motor off. Switching the lighting on and off Push the rotating disk to switch on and off the lighting.

L2L3 L4EN 7 USE Filters’ Saturation Control The hood is equipped with a device that indicates when it is required to perform the filter maintenance.

• The saturation control device of the grease filter is always active.

• The saturation control device of the carbon filter is turned off by default. To activate the saturation control device of the carbon filter, proceed as follows:

• Push the rotating disk for more than 5 seconds. The illumination around the rotating disk lights completely (flashing) and a beep will be heard. The saturation control device of the charcoal filter is activated. To deactivate the saturation control device of the carbon filter, proceed as follows:

• Push the rotating disk for more than 5 seconds. The illumination L1 and L2 around the rotating disk light (flashing) and a beep will be heard. The saturation control device of the charcoal filter is deactivated. Grease filter saturation indicator L1 + L2 flash when you have to perform maintenance of the grease filter. Activated charcoal filter saturation indicator L3 + L4 flash when you have to perform maintenance of the activated charcoal filter. Reset of the filter saturation signal

• After filter maintenance, switch on the hood.

• Push the rotating disk for more than 5 seconds. You will hear a long beep confirming the reset. Note: In case of simultaneous signaling (grease filter and activated charcoal filter saturation), you must repeat the reset twice.EN 8 Cleaning Attention! Before performing any maintenance operation, isolate the hood from the electrical supply by switching off at the connector and removing the connector fuse. Or if the appliance has been connected through a plug and socket, then the plug must be removed from the socket. The cooker hood should be cleaned regularly (at least with the same frequency with which you carry out maintenance of the fat filters) internally and externally. Do not use abrasive products. Do not use alcohol! Attention! Failure to carry out the basic cleaning recommendations of the cooker hood and replacement of the filters may cause fire risks. Therefore, we recommend oserving these instructions. The manufacturer declines all responsibility for any damage to the motor or any fire damage linked to inappropriate maintenance or failure to observe the above safety recommendations. Cooker hood Clean the cooker hood with soapy water and a soft cloth. Then wipe with clean water to rinse. Do not use aggressive cleaning agents such as soda. The cooker hood paintwork will stay looking nice if you wax it occasionally. Stainless steel canopy hoods Do not use any sort of scourer. Treat with a stainless steel care product and polish with the structure of the stainless steel. Metal grease filters These must be cleaned once a month (or when the filter saturation indication system – if envisaged on the model in possession – indicates this necessity) using non aggressive detergents, either by hand or in the dishwasher, which must be set to a low temperature and a short cycle. The openings must be placed downwards to let the water run out of the filters. The cleaning agents will make the aluminium filter turn dull, this is normal. MAINTENANCEEN 9 Grease filters Removing the grease filters Switch off the electricity! Remove the plug from the socket or switch the electricity off at the mains. Pull the grease filter towards you and tilt it downwards at the front. Carbon filter Replacing the carbon filter The carbon filter must always be used if the cooker hood is not ducted. Disassembly Remove the carbon filter by turning the twist locks on the front 90°. Carefully remove the filter. Assembly First hook the carbon filter on the metal tab on the back of the hood and then secure the front, with the two twist locks, by turning them a quarter turn. Note:

• The regenerable activated carbon filter can be washed by hand or in the dishwasher at a maximum temperature of 65 °C. The washing cycle must be done without other dishes and without dishwasher detergent. Do not use any cleaning agents!

• Remove excess water. Be careful to avoid damaging the filter. Let the filter dry in the oven for at least 1 hour at a maximum temperature of 80 °C. After a maximum of 3 years (or when the filter is damaged), the filter will need to be replaced. It is important that the grease filters and the regenerable activated carbon filter are properly dried before installation. MAINTENANCEEN 10 INSTALLATION The functioning:

• More noise is produced when a carbon filter is used than when the cooker hood is used with an exhaust vent.

• A carbon filter functions optimally at a lower motor speed. For this reason, avoid the boost function. Dispose of the old carbon filter properly, with non-recyclable waste. Lighting This hood is fitted with a light system. This light system has to be replaced by an authorized technician. Do not attempt to replace it by yourself. The lamp in this household appliance is only suitable for illumination of this appliance. The lamp is not suitable for household room illumination.EN 11 General This appliance should be connected to the power supply by a recognized fitter who is familiar with, and works according to the correct safety regulations. This appliance meets the European requirements. Important that you know:

• The minimum distance between the supporting surface for the cooking vessels on the gashob and the lowest part of the range hood must be not less than 65 cm. For use with an electric, ceramic or induction hob, this distance must be at least 55 cm.

• If the cooker hood is to be fitted to an existing duct no other appliances, such as a geyser or heater, may be connected to that same duct.

• Consider local regulations with respect to the ventilation of gas appliances.

• The shorter the duct, and the fewer the bends in it, the better the cooker hood will work.

• Before you start drilling check that there are no installation cables present.

• The connecting pipe for the cooker hood has a diameter of 120 or 150 mm. It is best also to use a flue pipe of the same diameter.

• The installation material supplied with this range hood is designed for fixing to reinforced concrete or masonry walls. For some types of walls you may need special plugs and screws. INSTALLATIONEN 12 INSTALLATION Connection Electrical connection This appliance is a Class I appliance and must be earthed. Make sure the supply voltage ratings correspond with those stated on the appliance data plate. The connection to the mains is carried out as follows: BROWN = phase L BLUE = phase N GREEN/YELLOW = Earth This canopy hood has been provided with a power plug. When installing the hood, make sure that this plug remains accessible. We recommend installing the wall socket out of view, behind the chimney cover. Attention: If you want to make a fixed connection, ensure that a multi-pole switch with a distance between contacts of 3 mm is installed in the supply cable. max 125 cmEN 13 APPENDICE Disposal Disposal of appliance and packaging By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The local authorities can provide you with the relevant information. The packaging of this appliance is recyclable. It could have been made from:
