Brand Continental Edison
Model CEHDI6450VB9
Category Decorative hood
Installation type Extraction or recirculation
Dimensions (W x D x H) 60 x 50 x 80 cm (adjustable)
Weight Approximately 12 kg
Power supply 220-240 V ~ 50 Hz
Maximum motor power 62 W
Lighting 2 x 2 W LED (non-replaceable)
Number of speeds 3 (low, medium, high)
Maximum airflow 283.3 m³/h
Maximum noise level 61 dB(A)
Energy efficiency class C
Filters supplied 1 metal grease filter + 2 charcoal filters (optional)
Filter maintenance Grease filter: monthly cleaning; charcoal filter: annual replacement
Minimum distance gas hob 80 cm
Minimum distance electric hob 70 cm
Warranty 2 years (according to legislation)

Frequently Asked Questions - CEHDI6450VB9 CONTINENTAL EDISON

How to install the hood in extraction mode?
For installation in extraction mode, connect the extraction duct (diameter 150 mm) to the air outlet of the hood and direct it outside. Make sure the duct is as short and straight as possible (max 2.50 m). Do not connect the duct to a ventilation system type VMC or to a flue.
How to install the hood in recirculation mode?
In recirculation mode, the hood does not require an extraction duct. Install the supplied charcoal filters (turn them clockwise until they click). The air is filtered and then recirculated into the room. Replace the charcoal filters at least once a year.
How to clean the grease filters?
Clean the metal grease filter every month. Use a cloth soaked in warm soapy water or a mild household detergent. Never use metal scouring pads or abrasive products. You can also wash it in the dishwasher.
What to do if the hood vibrates strongly?
Strong vibration may come from a stuck turbine, a poorly fixed motor, or incorrect wall mounting. Turn off the appliance, check the fixings, and call a professional if necessary.
How to replace the LED bulb?
The LED bulbs in your hood are not user-replaceable. In case of failure, contact a qualified professional for replacement.
The suction power is weak, what to do?
First check if the grease filters are clogged; clean them if necessary. Also make sure the extraction duct is not blocked or too long. If the problem persists, consult a professional.
What is the minimum distance between the hood and the hob?
For gas hobs, the minimum distance is 80 cm; for electric hobs, it is 70 cm. Respect these distances to avoid any risk of fire or overheating.
The hood suddenly stops after a storm, is this normal?
Yes, an electrostatic discharge (lightning) can cause the appliance to stop. Turn off the hood, unplug it for one minute, then plug it back in. This poses no danger.
How to recycle the hood at end of life?
Do not dispose of the appliance with household waste. Take it to a collection point for waste electrical and electronic equipment (WEEE). The packaging is recyclable.
Where to find the complete user manual?
You can download the PDF manual for free on the site notice-facile.com by searching for the model CEHDI6450VB9 from Continental Edison.
