Ribera Pro G20111 - Juicer G3 Ferrari - Free user manual and instructions

Product Type	Juice extractor (electric citrus press)
Brand	G3 Ferrari
Model	Ribera Pro G20111
Power Supply	220-240 V ~ 50/60 Hz
Power	350 W
Dimensions (approx.)	25 x 20 x 30 cm
Weight (approx.)	1.5 kg
Fruit Type	Citrus fruits (oranges, grapefruits, lemons, etc.)
Main Functions	Dual cone pressing (large and small), anti-drip spout, pressing arm, filter grid
Activation	By pressing fruit onto the cone
Materials	ABS plastic, stainless steel for filter grid
Juice Container Capacity	Approximately 1 L (estimation)
Cable Length	Approximately 1 m (estimation)
Safety	Automatic shut-off in case of overheating (motor protection), cable stored in base
Maintenance and Cleaning	Removable parts hand washable (water and mild detergent); do not use dishwasher; motor unit wiped with a damp cloth
Spare Parts and Repairability	Spout, cones, filter grid and container available from after-sales service; repair by authorized center
Usage	Domestic and indoor; do not use continuously for more than 5 minutes
Warranty	2 years (standard)

Frequently Asked Questions - Ribera Pro G20111 G3 Ferrari

How to use the Ribera Pro G20111 juice extractor?

Assemble the container, filter grid and the appropriate cone (small for lemons, large for oranges). Place a container under the anti-drip spout. Cut the fruit in half, place it on the cone and lower the pressing arm. The juice flows automatically.

What types of fruits can be pressed with this appliance?

This appliance is designed for all citrus fruits: oranges, grapefruits, lemons, limes, clementines, etc. Do not use it for non-citrus fruits (apples, carrots).

Can the parts be washed in the dishwasher?

No, the removable parts (container, filter grid, cones) must be washed by hand with a non-abrasive sponge and dish soap. Do not use the dishwasher.

How to clean the motor unit?

Unplug the appliance. Wipe the motor unit with a slightly damp cloth. Never immerse the motor unit in water or any other liquid.

What to do if the appliance stops during use?

The appliance may overheat after 5 minutes of continuous use. Let it cool down for at least 5 minutes before using it again. If the problem persists, contact the after-sales service.

How to store the power cord?

After use, wind the cord into the cavity provided for this purpose in the base of the appliance (under the motor unit).

What to do if the anti-drip spout does not work?

Make sure the spout is in the open position (tilted down) during pressing. After use, switch it to the closed position to avoid drips. If it remains stuck, clean it with warm water.

Is the appliance suitable for children?

It can be used by children over 8 years old under adult supervision. Children should not play with the appliance. Keep it out of reach of children under 8 years old.

Where to find spare parts for the Ribera Pro G20111?

Spare parts (cones, filter grid, container, spout) are available from the G3 Ferrari after-sales service or on authorized spare parts websites. Use only original parts.

What is the electrical power of the appliance?

The appliance operates on 220-240 V ~ 50/60 Hz with a power of 350 W.

USER MANUAL Ribera Pro G20111 G3 Ferrari

Technical model: JE-651F

Exterior view of a stainless steel coffee maker with a black lid and 'GFERRARI' branding (no other text or symbols visible)

Spremiagrumi

Citrus juicer

RIBERA PRO

ITA: INDICE

Simbologia.... p. 2

Safety instructions.... p. 7

General information.... p. 9

G20111 p. 9

Operating the unit.... p. 9

After juicing....p. 10

Cleaning.... p. 10

Technical features.... p. 10

Waste of electric and electronic equipment (WEEE

Directive).... p. 22

PORTUGUESE......p. 10

ESPAÑOL....p. 14

FRANCAIS p. 18

CLASSI DI PROTEZIONE / PROTECTION CLASSES

ATTENZIONE RISCHIO DI SCOSSE ELETTRICHE NON ESPORRE A PIOGGIA E UMIDITA'

WARNING ELECTRIC SHOCK RISK DO NOT EXPOSE TO RAIN OR MOISTURE

ATTENZIONE: NON APRITE L'APPARECCHIO. ALL'INTERNO NON VI SONO COMANDI MANIPOLABILI DALL'UTENTE NE' PARTI DI RICAMBIO. PER TUTTE LE OPERAZIONI DI SERVIZIO RIVOLGERSI AD UN CENTRO DI ASSISTENZA AUTORIZZATO.

This symbol warns the user that un-insulated dangerous voltage inside the system may cause an electrical shock. Do not open the case.

Class II Appliance symbol. The double insulated electrical appliance is one which has been designed in such a way that it does not require a safety connection to electrical earth/ground.

Caution: this symbol reminds the user to read carefully the important operations and maintenance instructions in this owner's guide.

AVVERTENZE DI SICUREZZA

DOPO LA SPREMITURA

ENGLISH: SAFETY INSTRUCTIONS

The following are important notes on the installation, use and maintenance; save this instruction manual for future reference; use the equipment only as specified in this guide; any other use is considered improper and dangerous; therefore, the manufacturer cannot be held responsible in the event of damages caused by improper, incorrect or unreasonable use.

Before use, ensure the equipment is undamaged; if in doubt, do not attempt to use it and contact the authorized service center; do not leave packing materials (i.e. plastic bags, polystyrene foam, nails, staples, etc.) within the reach of children as they are potential sources of danger; always remember that they must be separately collected. Make sure that the rating information given on the technical label are compatible with those of the electricity grid; the installation must be performed according to the manufacturer's instructions considering the maximum power of the appliance as shown on the label; an incorrect installation may cause damage to people, animals or things, for which the manufacturer cannot be considered responsible thereof.

If it is necessary to use adapters, multiple sockets or electrical extensions, use only those that comply with current safety standards; in any case do not exceed the power consumption limits indicated on the electrical adapter and / or extensions, as well as the maximum power shown on multiple adaptor.

Do not leave the unit plugged; better to remove the plug from the mains when the device is not in use. Always disconnect from power supply if you leave it unattended.

Cleaning operations should be carried out after unplugging the unit.

If the unit is out of order and you do not want to fix it, it must be made inoperable by cutting power cord.

• Do not allow the power cord to get closer to sharp objects or in contact with hot surfaces; do not pull it to disconnect the plug.
• Do not use the appliance in the event of damage to the power cord, plug, or in case of short circuits; to repair the product only address an authorized service center.
• Do not handle or touch the appliance with wet hands or bare feet. Do not expose the appliance to harmful weather conditions such as rain, moisture, frost, etc.. Always store it in a dry place.
• This appliance can be used by children of 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they received supervision or instruction concerning use of the appliance in a safe way and understand hazards involved; children shall not play with the appliance; cleaning and user maintenance shall not be made by children without supervision.
• Children must not play with the appliance.
• Keep the appliance and its cord out of reach of children less than 8 years.
  If the power cord is damaged, or in case of failure and / or malfunction do not tamper with the unit. The reparation must be done by manufacturer or by service center authorized by the manufacturer in order to prevent any risk. Failure to comply with the above may compromise the unit safety and invalidate the warranty.
• This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments; by clients in hotels, motels and other residential type environments; farm houses, bed and breakfast type environments.
• The appliance is not intended to be operated by means of an external timer or separate remote-control system.

• Before every use, unroll the power cord.

• Use original spare parts and accessories only.

• Do not subject the product to strong impacts, serious damages may result.
• Do not use near or under flammable materials (like curtains), heat, cold spots and steam.

GENERAL INSTRUCTIONS

Before using the unit for the first time, carefully wash the parts that come in touch with food such as the arm, filter, container, juicer spout and cones.

Before operating the juicer, make sure to place it on a flat and stable surface with no heat sources nearby. Assemble all parts properly before use.

Always place a container under the spout when operating.

To avoid the overheating of the motor, do not use the appliance for more than 5 minutes continuously, then wait at least 5 minutes before operating.

Never leave the appliance unattended while it is running.

Disconnect the electric plug from the socket after each use.

Do not immerse the motor unit in water or other liquids; clean it with a damp cloth.

G20111 DESCRIPTION

A) Arm B) Double juicing cone, small and big
C) Filter D) Container
E) Spout F) Motor body G) Base with power cord housing

OPERATING THE UNIT

• Unroll the power cord from the base (G). Insert the juice container (D) in its housing.
• Place filters and juicing cones correctly.
• Make sure that the spout (E) is in the open position.
• Place a glass or a container under the spout.
• Connect the electric plug to the power outlet.
• Cut a citrus in half and place it on the juicing cone.
• Press over the citrus with the proper arm (A).

This appliance is suitable to squeeze any type of citrus. It is equipped with two cones (B): a big one with a wider base for large fruits like oranges and grapefruit and a smaller one suitable for lemons or small oranges.

AFTER JUICING

• Close the spout (E) to prevent juice dripping inside the container (D).
• Remove the glass with the juice.
• Remove the filters (C) and the plastic container (D) for cleaning them.
• Roll the cable on the slot under the base (G).

CLEANING - Unplug the unit from the electrical outlet.

Some parts (such as the container, filters or juicing cones) can be treated like normal dishes. Wash them under tap water. For a more accurate cleaning, use a soft sponge and dishwashing detergents.

Plastic parts are not dishwasher-safe.

Clean the motor unit with a damp cloth. Do not immerse the motor unit in water or other liquids.

Also the food presser is dismountable for easier cleaning.

TECHNICAL FEATURES

• Power supply: AC 220-240V\~50/60Hz. Power: 350W
• Dripping-safe spout, pressing arm
• Automatic juicing by pressing the cone
- 2 cones, large and small.
• Stainless steel Filter and housing

PORTUGUES: ADVERTÊNCIAS

The product is made of non-biodegradable and potentially polluting substances if not properly disposed of; other parts can be recycled. It’s our duty to contribute to the ecological health of the environment following the correct procedures for disposal. The crossed out wheelie bin symbol indicates the product complies with the requirements of the new directives introduced to protect the environment (2002/96/EC, 2003/108/EC, 2002/95/EC, 2012/19/EC) and must be properly disposed at the end of its lifetime. If you need further information, ask for the dedicated waste disposal areas at your place of residence. Who does not dispose of the product as specified in this section shall be liable according to the law.

To find the nearest service center, please call the telephone number 0541 694246, fax number 0541 756430 or contact us at [e-mail] asking for the service centers supervisor.

Appliance is conform to the pertinent European regulation and is therefore marked with the CE mark.

www.g3ferrari.it TREVIDEA S.r.l.

TREVIDEA S.R.L. – Strada Consolare Rimini – San Marino n. 62 – 47924 – RIMINI (RN) - ITALY

MADE IN CHINA
