41125 - Food Processor WestBend - Free user manual and instructions

Product Type	Stand Mixer
Brand	WestBend
Model	41125
Power	120 V AC, 60 Hz
Large Bowl Capacity	4 quarts (approx. 3.8 L)
Small Bowl Capacity	1.5 quarts (approx. 1.4 L)
Included Accessories	2 beaters, 2 dough hooks
Speed Setting	Variable with indicator light
Usage	Stand only (do not use as hand mixer)
Bowl and Accessories Cleaning	Dishwasher safe
Motor Base and Stand Cleaning	Wipe with a damp cloth
Safety	Unplug before cleaning; do not immerse
Warranty	1 year limited
Replacement Parts	Available at westbend.com
Usage Area	USA and Canada only

Frequently Asked Questions - 41125 WestBend

How to attach the mixer to the stand?

Press and hold the release lever on the back of the support base. Place the mixing head onto the base so that the metal pin fits into the notch. Make sure the mixer is securely attached before use.

How to choose the right mixing speed?

Always start at a low speed to avoid splattering, then gradually increase. Use the rotary dial to set the speed; a red light illuminates next to the selected setting. Refer to the mixing guide in the manual for specific operations.

Can I use the mixer by hand without the stand?

No, this model is designed for stand use only. Do not attempt to use it as a hand mixer.

What are the bowl capacities?

The large bowl has a capacity of 4 quarts (approx. 3.8 L) and the small bowl 1.5 quarts (approx. 1.4 L). Do not fill bowls more than half full to avoid splattering.

How to clean accessories and bowls?

Wash beaters, hooks and bowls in hot soapy water with a soft cloth, rinse and dry. They are dishwasher safe. Do not use abrasive pads. Do not soak metal accessories for a long time.

What if the mixer does not work?

Check that the speed dial is set to a position other than OFF, the appliance is plugged into a 120 V AC outlet, and the head is properly locked. If the problem persists, contact West Bend customer service.

How to safely remove the beaters?

Turn off and unplug the appliance. Press the beater release button on the side of the mixing head, then remove the beaters. Do not pull without pressing the button.

Can I knead yeast dough with this mixer?

Yes, use the dough hooks for yeast doughs. Do not exceed 4 measures of flour per recipe and do not mix a hook with a beater.

What is the warranty on this product?

The product is warranted for 1 year against defects in parts and workmanship from the original purchase date. The warranty is valid only in the USA and Canada. Contact customer service for repairs.

Where can I find replacement parts?

Order replacement parts directly at www.westbend.com, or contact customer service at [phone] or by email at [e-mail].

USER MANUAL 41125 WestBend

Register this and other West Bend® Housewares products through our website: www.westbend.com

Important Safeguards. 2

Precautions For Use Around Children 2

Electricity Precautions 3

Assembling your Stand Mixer 4

Using Your Stand Mixer 4

Mixing Guide 5

Cleaning Your Stand Mixer 5

Mixing Tips 5

Warranty. 6

SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE

IMPORTANT SAFEGUARDS

CAUTION

To prevent personal injury or property damage, read and follow all instructions and warnings.

When using electrical appliances, basic safety precautions should always be followed including the following:

• Read all instructions, including these important safeguards and the care and use instructions in this manual.
• Do not use appliance for other than intended use.
• Do not place on or near a hot gas or electric burner, or a heated oven.
• The use of accessory attachments not recommended by West Bend® Housewares may cause injuries.
• Do not attempt to repair this appliance yourself.
• For household use only.

CAUTION

To prevent burns or other personal injuries to children, read and follow all instructions and warnings.

PRECAUTIONS FOR USE AROUND CHILDREN

• Always supervise children.
• Do not allow children to operate or be near the mixer, as contact with moving parts may cause injury.
• Do not allow cord to hang over any edge where a child can reach it. Arrange cord to avoid pulling, tripping or entanglement.

CAUTION

To prevent electrical shock, personal injury or property damage, read and follow all instructions and warnings.

ELECTRICITY PRECAUTIONS

• To protect against electric shock, do not immerse cord, plugs, or other electric parts in water or other liquids.
• Do not operate any appliance with a damaged cord or plug.
• Do not operate when the appliance is not working properly or when it has been damaged in any manner. For service information see warranty page.
• Do not use this appliance outdoors.
• Always switch appliance to OFF and unplug the appliance from outlet and allow to cool before putting on or taking off parts and before cleaning.
• Avoid contacting moving parts. Keep hands, hair, clothing, spatulas and other utensils away from beaters during operation to reduce the risk of injury to persons, and/or damage to the mixer.
• Remove beaters from mixer before washing.
• Do not leave appliance unattended while it is operating.
• Your appliance has a short cord as a safety precaution to avoid pulling, tripping or entanglement. Position the cord so that it does not hang over the edge of the counter, table or other areas or touch hot surfaces.
• While use of an extension cord is not recommended, if you must use one, make sure the cord has the same or higher wattage as the appliance (wattage is stamped on the underside of the mixer head). To avoid pulling, tripping or entanglement, position the extension cord so that it does not hang over the edge of the counter, table or other areas or touch hot surfaces.
• Use an electrical outlet that accommodates the polarized plug on the appliance. On a polarized plug, one blade of the plug is wider than the other. If the plug does not fit fully into the outlet or extension cord, reverse the plug. If the plug still does not fit fully, contact a qualified electrician. Do not alter the plug.
• Do not use an outlet or extension cord if the plug fits loosely or if the outlet or extension cord feels hot.
• Keep the cord away from moving parts of the appliance during operation.

SAVE THESE INSTRUCTIONS

Your mixer requires some assembly before using. Do not plug cord into electrical outlet until after mixer is assembled and ready for operation.

1. To attach mixer to stand, press and hold down mixer release lever located on the back of the mixer stand. Position mixer head on stand so metal pin on underside of mixer fits into groove on mixer stand. Make sure mixer is securely attached to stand before using. NOTE: Mixer should not be used as a hand mixer. It must always be used on the stand.
2. Place turntable onto platform of stand, aligning extension on underside into correct opening for the size bowl being used, Small or Large. Lip on underside of bowl will fit into groove on turntable.
3. To insert beaters or dough hooks, press the lock release button located on side of mixer stand, lift mixer head up until it stops. The beater or dough hook with the round collar fits into the round socket of the mixer head. The beater with the hexagon collar fits into the hexagon socket of the mixer head. Insert beaters by pushing shaft into socket, turning slightly if needed until they lock in place. Beaters must be inserted into correct socket, as they are not interchangeable.

1. Make sure speed control dial is set at the OFF position and mixer is securely attached to the stand before using. NOTE: Mixer should not be used as a hand mixer. Use only on stand.
2. Position turntable according to size bowl being used. Position bowl onto turntable.
3. Insert beaters or dough hooks into correct sockets.
4. Add ingredients to bowl as recipe directs. Plug cord into a 120 volt, AC electrical outlet only. Turn speed control dial to start mixing. Always begin mixing at a lower speed setting to prevent spattering, then increase to desired speed for mixing task. Speed setting can be adjusted during operation by turning dial forward and back. Use mixing guide as reference by aligning speed setting with indicator line. A red light will illuminate next to the setting that was selected. If you need to scrape the bowl during use, always turn mixer off, scrape then continue mixing.

5. When mixing is complete, turn speed control dial to OFF position and unplug cord from electrical outlet. Press the lock release button and lift mixer head up until it stops. Press the beater/hook release button located on side of mixer head and remove the beaters/hooks. NOTE: Do not try to pull the beaters/hooks out of the mixer head without pressing the beater release button as damage to the mixer head could occur.

6. A small amount of smoke and/or odor may occur upon heating due to the release of manufacturing oils – this is normal.

MIXING GUIDE

MIXING TASK EXAMPLE
Knead Use to knead dough
Stir Use to begin mixing
Fold Use to gently blend ingredients
Blend Use to blend two or more ingredients
Mix Use to mix ingredients to form a smooth batter
Beat Use to mix prepackaged cake mixes
Cream Use to cream butter or shortening and sugar
Mash Potatoes Use to mash cooked potatoes
Whip Cream Use to prepare whipped cream
Whip Desserts Use to prepare fluffy desserts
Frosting Use to prepare frostings
Egg Whites Use to whip egg whites

1. Turn mixer OFF and unplug cord from electrical outlet before cleaning.
2. With beaters or hooks removed, wipe mixer, stand and turntable with a damp cloth and dry.
3. Wash beaters, hooks and bowls in hot soapy water with a soft cloth, rinse and dry. Beaters, hooks and bowls may be cleaned in an automatic dishwasher.

NOTE: Do not use any abrasive scouring pads or cleansers on bowls, beaters or hooks as scratching can occur. Also, do not allow beaters or hooks to soak in water for extended periods of time (several hours or overnight) to prevent damage to metal finish.

MIXING TIPS

• Use beaters for all mixing/whipping tasks. Use dough hooks only for the preparation of yeast doughs.
• Maximum capacity of the Large mixing bowl is 4 quarts; the Small mixing bowl is 1 12 quarts. Do not fill bowls more than half full with ingredients.
• Do not exceed using 4 cups of flour in a recipe.
• Begin mixing at lowest speed, and then increase to higher speed to prevent spattering.
• Turn mixer off and use a rubber spatula to scrape side of bowl as needed. Do not scrape bowl while mixer is running. Should an object, such as a spatula fall into the bowl while mixing, immediately turn mixer off. Unplug, then remove object.
• Do not attempt to use a dough hook with a beater, as damage to mixer will occur.

PRODUCT WARRANTY

Appliance 1 Year Limited Warranty

West Bend® Housewares, LLC warrants this appliance from failures in the material and workmanship for 1 year from the date of original purchase, provided the appliance is operated and maintained in conformity with the West Bend® Housewares, LLC Instruction Manual. Any failed part of the appliance will be repaired or replaced without charge at West Bend® Housewares, LLC discretion. This warranty applies to indoor household use only.

The West Bend® Housewares, LLC warranty does not cover any damage, including discoloration, to any non-stick surface of the appliance. The West Bend® Housewares, LLC warranty is null and void, as determined solely by West Bend® Housewares, LLC, if the appliance is damaged through accident, misuse or abuse, scratching, overheating, or if the appliance is altered in any way or if used outside of an indoor household setting.

This warranty gives you specific legal rights. You may also have other rights, which may vary from state to state.

THIS WARRANTY IS IN LIEU OF ALL IMPLIED WARRANTYES, INCLUDING WARRANTYES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, PERFORMANCE, OR OTHERWISE, WHICH ARE HEREBY EXCUSED. IN NO EVENT SHALL WEST BEND® HOUSEWARES, LLC BE LIABLE FOR ANY DAMAGES, WHETHER DIRECT, IMMEDIATE, INCIDENTAL, FORESEEABLE, CONSEQUENTIAL, OR SPECIAL, ARISING OUT OF OR IN CONNECTION WITH ITS APPLIANCE.

If you think the appliance has failed or requires service within its warranty period, please contact the West Bend® Housewares Customer Service Department at [phone] or e-mail us at [e-mail]. Return shipping fees are non-refundable. Hand-written receipts are not accepted. West Bend Housewares, LLC is not responsible for returns lost in transit.

Valid only in USA and Canada

REPLACEMENT PARTS

Replacement parts may be ordered direct from West Bend® Housewares, LLC by ordering online at www.westbend.com: Replacement Parts. Or you may call or e-mail the service department at the number/e-mail address listed above, or by writing to us at:

West Bend Housewares, LLC

Attn: Customer Service

P.O.Box 2780

West Bend, WI 53095

Be sure to include the catalog/model number of your appliance (located on the bottom/back of the unit) and a description and quantity of the part you wish to order. Along with this include your name, mailing address, Visa/MasterCard number, expiration date and the name as it appears on the card. Checks can be made payable to West Bend Housewares, LLC Call Customer Service to obtain purchase amount. Your state's sales tax and a shipping/processing fee will be added to your total charge. Please allow two (2) weeks for delivery.

This manual contains important and helpful information regarding the safe use and care of your new West Bend® Housewares, LLC product. For future reference, attach dated sales receipt for warranty proof of purchase and record the following information:

Date purchased or received as gift:

Where purchased and price, if known:

Item Number and Date Code (shown bottom/back of product):

WEST BEND HOUSEWARES
