| Product Type | USB 3.1 Gen1 Hub |
| Brand | Tripp Lite |
| Model | U460-004-2A2CB (Black) |
| Input Connector | USB-C Male (attached cable) |
| Output Connectors | 2x USB-A Female + 2x USB-C Female |
| Maximum Transfer Rate | Up to 5 Gbps |
| Power Supply | USB Bus-Powered (shared 1.5A total) |
| Power per USB-A Port | Up to 900 mA |
| Power per USB-C Port | Up to 1.5A |
| Compatibility | USB 3.1 Gen1, backward compatible with USB 2.0 and 1.x |
| Number of Connectable Devices | Up to 4 USB devices simultaneously |
| Operating Temperature | 0 to 45 °C |
| Operating Humidity | 10 to 85% RH, non-condensing |
| Storage Temperature | -10 to 70 °C |
| Storage Humidity | 5 to 90% RH, non-condensing |
| Warranty | 3-year limited |
| Maintenance and Cleaning | Wipe with a soft, dry cloth. Do not use liquids or abrasive products. |
| Safety | Use with USB-compliant devices. Do not expose to moisture or shocks. |
| Spare Parts and Repairability | Not user-serviceable. Contact an authorized Tripp Lite service center. |
| General Information | Compact and portable design with attached USB-C cable. No driver required. |
Frequently Asked Questions - U4600042A2CB Tripp Lite
User questions about U4600042A2CB Tripp Lite
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your USB Hub in PDF format for free! Find your manual U4600042A2CB - Tripp Lite and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. U4600042A2CB by Tripp Lite.
USER MANUAL U4600042A2CB Tripp Lite
USB Type-C and USB-C are trademarks of USB Implementers Forum
Español 5 • Français 9 • Русский 13
WARRANTY REGISTRATION
Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support
Copyright © 2020 Tripp Lite. All trademarks are the sole property of their respective owners.
Package Contents
- U460-004-2A2C (white) or U460-004-2A2CB (black)
- Owner's Manual
Optional Accessories
• U322-Series USB 3.0 A/B Device Cables
• U326-Series USB 3.0 Micro-B Device Cables
• U420-003 USB 3.1 Gen 1 USB-C Cable (M/M), 3 ft.
- U422-003 USB 3.1 Gen 1 USB-C to USB 3.0 Type-B Cable (M/M), 3 ft.
- U426-003 USB 3.1 Gen 1 USB-C to USB 3.0 Micro-B Cable (M/M), 3 ft.
Product Features
- Connects up to 4 USB devices at the same time
- Portable bus-powered design with built-in cable perfect for travel—fits comfortably in purse, backpack or laptop bag
• Each USB-A port supports up to 900mA of power; each USB-C port supports up to 1.5A*
• Supports data transfer rates up to 5 Gbps - Backward compatible with previous USB generations
- Plug-and-play—no software, drivers or external power supply required
*All 4 ports share up to 1.5A of bus power. See your devices' documentation for details on what they support. Higher-powered devices will need their own external power supply.
Installation
- Connect the USB-C plug to the USB-C port on your laptop, tablet or other device.
- Connect up to 2 USB devices to the USB-A hub ports.
- Connect up to 2 USB devices to the USB-C hub ports.
Specifications
| Input Connectors | |
| USB USB-C (Male) | |
| Output Connectors | |
| USB | (x2) USB-A (Female)(x2) USB-C (Female) |
| Environmental | |
| Operating Temperature | 32 to 113°F (0 to 45°C) |
| Operating Humidity | 10% to 85% RH,Non-Condensing |
| Storage Temperature 14 | to 158°F (-10 to 70°C) |
| Storage Humidity 5% to | 90% RH,Non-Condensing |
Warranty and Product Registration
3-YEAR LIMITED WARRANTY
Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. Tripp Lite's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from Tripp Lite or an authorized Tripp Lite service center. Products must be returned to Tripp Lite or an authorized Tripp Lite service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.
Warranty and Product Registration
EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, Tripp Lite is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
