USER MANUAL U4600033AG Tripp Lite

to USB-A Hub with Gigabit

Ethernet and Charging*

Models: U460-003-3AG, U460-003-3AG-C,

U460-003-3AGB-C

USB Type-C and USB-C are trademarks of USB Implementers Forum

• Only U460-003-3AG-C and U460-003-3AGB-C have charging capability

Espanol 8 • Français 14 • Pycckn 20

WARRANTY REGISTRATION

Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing!

triplite.com/warranty

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

Copyright © 2020 Tripp Lite. All rights reserved.

Package Includes

• U460-003-3AG, U460-003-3AG-C, or U460-003-3AGB-C
• Owner's Manual

Optional Accessories

• N201-Series Cat6 Gigabit Snagless Patch Cables
  U322-Series USB 3.0 A/B Device Cables
  U326-Series USB 3.0 Micro-B Device Cables
• U420-003 USB 3.1 Gen 1 USB-C Male/Male Cable - 3 ft.

Product Features

• Portable design with built-in cable is perfect for travel and stowing in a laptop bag
• USB-A hub ports support data transfer rates up to 5 Gbps
• (U460-003-3AG-C and U460-003-3AGB-C) Dedicated BC 1.2 compliant USB port provides up to 1.5A of fast charging power to mobile devices
• Ethernet port supports true 10/100/1000 Mbps networks speeds
• (U460-003-3AG-C and U460-003-3AGB-C) USB-C charging port for charging your device; supports power input up to 20V 3A (60W)
• Plug-and-Play - No software or drivers required

Installation

Note: When the unit is connected to the USB-C port on your computer and to a network via Cat5e/6 cabling, a network connection will be automatically established. If no connection is made, you can manually establish one by going to your computer's network settings page. For example, on a Mac you would navigate to the Network section found in System Preferences, click the 'Assist Me' button to get to the Network Setup Assistant, then follow the prompts to establish a connection

1. Connect the unit's USB Type-C connector to the USB-C port on your laptop, tablet or other device.
2. Connect up to three USB devices to the USB-A hub ports on the unit.
3. Connect the unit's RJ45 port to a network using a UTP cable (such as Tripp Lite's N201-Series Cat6 cables).
4. (U460-003-3AG-C and U460-003-3AGB-C) Charge your device by connecting the USB-C charger to the adapter's USB-C port.

Specifications

Input Connectors
USB USB-C (Male)
Charging USB-C (Female)
Output Connectors
USB-A USB-A (Female) x 3
Ethernet RJ45 (Female)
Environmental
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature	14°F to 158°F (-10°C to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
USB-C Charging Port*	Supports up to 20V 3A (60W) Input
USB Battery Charging (BC) 1.2 Port*	Provides up to 5V 1.5A (7.5W) Output

• U460-003-3AG-C and U460-003-3AGB-C only

Warranty and Product Registration

3-YEAR LIMITED WARRANTY

Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. Tripp Lite's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from Tripp Lite or an authorized Tripp Lite service center. Products must be returned to Tripp Lite or an authorized Tripp Lite service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO WARRANTYES, EXPRESS OR IMPLIED, INCLUDING WARRANTYES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, Tripp Lite is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and Product Registration

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

Warranty and Product Registration

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Manufacturing

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

7

19-05-297 93-3745_RevC

1111 W. 35th Street, Chicago, IL 60609 EE UU tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 EE UU tripplite.com/support

13

19-05-297 93-3745_RevC

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

19

19-05-297 93-3745_RevC

PykoBODCTBO N0Ib30BaTeJia

KoHcEHTpaTOp USB 3.1 Gen 1 USB-CTM

/ USB-A с поport Gigabit Ethernet u

B03M0XH0CTbIO 3apYdkn*

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

OxpaHareTcA ABTopckm npabom © 2020 Tripp Lite. Iepeneuatka 3anpeuaetc.

KoMnJIeKT nOcTaBKn

U460-003-3AG,U460-003-3AG-CnU460-003-3AGB-C
PykoBOdCTBO n0lb30BaTeJra

OnuHaJIbHbIe KOMnKeKtYuOuIe

Be3pa3pbIBhbIe coeINHITbIbIe Ka6eIi Cat6 Gigabit cepnn N201
Ka6eIi IyctpoBc pa3bemamn USB 3.0 A/B cepnn U322
- Ka6eIi nI pOdkHoueHn yCtpoiCTB c pa3bemamn USB 3.0 Micro-B cepnn U326
Ka6eIb U420-003 cpa3beMaMn USB 3.1 Gen 1/USB-C (uTeKepe/teKeep), dInHa 0,9 M

XapakTepnCTnKn npOdyKta

• IopTaTINBHaJ KOHCTpyKcIa CBMOHTnPOBaHHbIM Ka6eJIeM, INdeaIbHO IOxOJaUaIyI NcNoJIb30BaHnB DOpORe IJeTKO NOMEuaIOUaIcB CymKe IJr HOYt6yKa
• IopTbI KOHcEHTpaTopa USB-A noIDepKINBaIOr ckOpocTN nepeDaUN daHHbIX do 5Γ6nt/c
  ·(U460-003-3AG-Cn U460-003-3AGB-C) BbIeJIeHbI USB-nOpT, COOTBeTCTByIOUs Tpe6ObaHnM BC 1.2, o6ecneuBaET MoIHOCTb Do 1,5 A B peXIMe 6blcTpoJ 3apJKn MO6NJbHbIX yCTpO'CTB
• Iopr Ethernet noIepxmbaet ceTbe cKopoctn 10/100/1000 M6nt/c
  ·(U460-003-3AG-Cn U460-003-3AGB-C) 3apaHbI npT USB-C noDxoHIT nla 3apAKn yCTpOietBa, noDpeKnBaIOe Ro BXoHoe nTaHne do 20 B/3 A (60BT)
  -Подкlioчene no texhonoRn Plug-and-play 6e3 Heo6xOIMocTn ИспьзOBaHЯ KaKOro-lIb60 nporpaMMHOrO obecneueHЯ ИлДраиВеров

yctahOBka

IpimeeHne. Ecn daHoe yctpoiCTBO noKIOueHO K npTy USB-C KOMnbTepa N K cetu che3 Ka6enn Cat5e/6, To ceteBoe coeINHeHne yCTaHaBnBaETcA BtOMaTnueckn. Ipn OTCyTCTBn COeINHeHn OHO moKet 6bITb yCTaHOBNeHo BpyHyTO C tPaHnCbI cTeBbIX HAcTpoE KOMNbIePepa. HanpImep, Ha yctpoiCTBe Mac cneJeT nepeiTn B pa3dEn Network ("Cetb") B MeHIO System Preferences ("IpaAMeTpbl CnCTeMbI"), Haxatb Ha KNOpKy 'Assist Me' ("Tpe6yeTcN nomOuB") dJa BbI3OBA yTInNTbl Network Setup Assistant ("PomouHK hAcTpoiKn cTeBbIX napaMeTpOB"), a 3aTeM cIeDobAtb NOdka3KaM dJa UCTaHOBJIeHn CoeINHeHn.

1. Поблочиразьем USB Type-C устpoиства К поту USB-C сбого потунв Horо комьютета, паншета ил другогу устpoиства.
2. ПодключITE до Трex USB-устов К потам USB-A концentpaTopa.
3. Поdkлочи Te npT RJ45 nepexoHnka K cetn C nomoьko Ka6eJy UTP (HaNPmep, Ondoro n3 npednaeraMbIX komnaHnei Tripp Lite ka6eJy Cat6 cepnn N201).
4. (U460-003-3AG-C n U460-003-3AGB-C) 3apynte cboe yctpoiCTBO, coeHHNB ero npT dIy 3apydkn USB-C c nopTom USB-C nepexoHnka.

TexHnueckneXapaKTepeNCTNUKN

PnpyaIyAeMaaTIOO XEETOTIE.
