| Product type | Air compressor |
| Brand | Metabo |
| Model | Power 28020 W OF |
| Main usage | Compressed air production for professional pneumatic tools |
| Supply voltage | 230 V ~ 50 Hz |
| Rated input power | 1.50 kW (S3) |
| Rated current | 6.0 A |
| Protection class | IP 20 |
| Maximum pressure | 8 bar (116 psi) |
| Tank capacity | 20 L |
| Suction flow rate | 220 l/min |
| Effective flow rate | 120 l/min |
| Rotation speed | 2850 min⁻¹ |
| Number of cylinders | 1 |
| Safety valve | Yes (spring-loaded, triggers in case of overpressure) |
| Pressure gauges | 2 (tank pressure and working pressure) |
| Pressure regulator | Yes (adjustable) |
| Compressed air connection | Quick coupling (regulated compressed air) |
| Air filter | Yes, cleanable (every 50 h, replace every 250 h) |
| Carrying handle | Yes (foldable on some models) |
| Frost protection | Store frost-free (minimum operating temperature: > 5 °C) |
| Regular maintenance | Daily condensate drain, air filter cleaning |
| Safety | Automatic shut-off in case of overpressure, overheating protection, emergency stop via switch |
| Spare parts | Available at www.metabo.com |
| Standards | CE, compliance with EU directives |
Frequently Asked Questions - Power 28020 W OF METABO
How to drain condensation water from the tank?
Drain condensation water daily via the condensate outlet (3) located under the tank. Ensure the device is switched off and depressurized before operation.
What is the maximum pressure of the device?
The maximum pressure is 8 bar (116 psi). Do not exceed this value; the safety valve triggers in case of overpressure.
How to clean the air filter?
Disconnect the device and depressurize it. Remove the air filter housing (10), clean the filter with compressed air or soapy water. Reassemble after drying. Replace the filter every 250 hours of operation.
What to do if the compressor does not start?
First check the mains supply, cable, plug, and fuse. If voltage is too low, use an extension cord of sufficient diameter. If the motor has overheated, switch it off using the switch (9), let it cool for 10 minutes, then restart.
Can I use the compressor outdoors?
Yes, but only with an extension cord suitable for outdoor use. Protect the device from rain and moisture. Do not use it in an explosive atmosphere.
What is the minimum storage temperature?
The minimum storage and operating temperature is 5 °C. Below that, condensation water may freeze and damage the device. Store it frost-free.
How to transport the compressor?
Use the carrying handle (11) or the crane hook (12) if equipped. Never pull the device by the hose or power cable.
Where to find spare parts?
Spare parts are available from the Metabo representative. Check the addresses on www.metabo.com where you can also download the parts list.
Which tools can I connect to this compressor?
You can connect any professional pneumatic tool whose maximum operating pressure does not exceed the set working pressure (max. 8 bar). Use a suitable hose and respect the pressure indicated on the tool.
What to do in case of an air leak at the condensate outlet?
Make sure the condensate outlet (3) is properly closed. If the leak persists, check the seal of the drain screw and replace it if necessary. For leaks at the non-return valve, have it checked by a specialized workshop.
