AT7800U - Toaster AEG - Free user manual and instructions

Product type	Toaster
Brand	AEG
Model	AT7800U
Capacity	2 slices
Power	900 W (estimated)
Power supply	230 V ~ 50 Hz
Display	LCD
Functions	Defrost, bun warmer, browning control (7 levels), pause (Check), stop (Cancel), extra-high lift
Crumb tray	Removable
Cord storage	Under the appliance
Bun warmer	Integrated
Body material	Plastic with metal slots
Cleaning	Wipe with a damp cloth, do not immerse
Safety	Automatic shut-off at end of cycle, do not cover, do not leave unattended
Included accessories	Bun warmer

Frequently Asked Questions - AT7800U AEG

How to adjust the browning of the bread?

Press the Browning control buttons A or V to set the intensity from 1 to 7 before starting the cycle.

How to use the Defrost function?

To toast frozen bread, press the Defrost button (B) before lowering the start lever.

How to interrupt the toasting cycle?

Press the Cancel button (A) to stop immediately. You can also press Check (C) to temporarily suspend the cycle (the bread rises, you have 10 seconds to resume by lowering the lever).

How to use the bun warmer?

Place the bun warmer (J) on top of the toaster, press the Bun warmer button (E), then lower the lever. Caution: the rack is hot!

How to clean the toaster?

Unplug the appliance and let it cool. Empty the crumb tray (C) and wipe the exterior surfaces with a slightly damp cloth. Never use abrasive products and do not immerse the appliance in water.

What to do if the toaster does not turn on?

Check that the power cord is properly plugged into a working outlet. If the cord is damaged, contact a qualified professional to replace it.

Can I toast small bread rolls?

Yes, use the integrated bun warmer (J). Press Bun warmer (intensity 2), then start. Turn the rolls halfway through if needed.

How to store the power cord?

The cord is stored under the appliance, in a compartment designed for this purpose (N). Wind it carefully after each use.

Does the toaster stop automatically?

Yes, once the bread is toasted to the chosen intensity, the appliance turns off automatically and the bread rises. You can also use the extra-high lift by lifting the lever.

Can I toast frozen bread?

Yes, use the Defrost function (B) before starting the cycle. The toaster will automatically adjust the cooking time.

USER MANUAL AT7800U AEG

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

Visit our website to:

Get usage advice, brochures, trouble shooter, service information: www.aeg.com/webselfservice

Register your product for better service: www.registeraeg.com

Buy Accessories and Consumables for www.aeg.com/shop

CUSTOMER CARE AND SERVICE

When contacting Service, ensure that you have the following data available:

• Model Number
• PNC number
• Serial number

The information can be found on the rating plate.

ENGLISH

Thank you for choosing an AEG product. In order to ensure the best results, always use original AEG accessories and spare parts. They have been designed especially for your product. This product is designed with the environment in mind. All plastic parts are marked for recycling purposes.

COMPONENTS

A. Toasting slot
B. Outer housing
C. Crumb tray
D. Defrost button
E. Bun warmer button
F. LCD Display
G. Check button

H. Cancel button
1. Browning control button()
J.Browning control button()
K. Start lever
L. Bun warming rack for warming up buns and rolls
M. Power cord and plug
N. Cord storage (on the underside of the toaster)

Picture page 2

GETTING STARTED

Before you start using the toaster, place it in an area with good ventilation such as a stove vent hood that is turned on or an open window. Set the browning setting to 8 and turn the toaster on without any bread in it. Repeat for a total of 2 to 3 times as this will help remove any odors that can occur during the first few uses.
2 How to use the toaster. Plug the cord into the mains. Insert bread. Press the browning control button (A or V) to adjust the browning level (1-7). Press down the start lever. The LCD display will show the process time and starts to count down.
3 When the bread has reached the desired degree of browning, the toaster switches off automatically and the bread is lifted up.

FEATURES AND CLEANING

4 Operating features: to interrupt toasting, press the Cancel button (A). To toast frozen bread, press the Defrost button (B). Press the Check button (C) to pause toasting. The bread is lifted up and the toasting will pause (press down the start lever within 10 seconds to resume toasting). Press and hold the Cancel button (A) for two seconds to turn off the LCD display.
5 To warm buns, rolls, or other bread, use the bun warmer rack. Place the bun warmer rack on top of the appliance. Press the bun warmer button (D) (browning setting 2) and then start the toaster by pressing down the start lever. Once finished, turn the bread over and repeat if necessary.

Caution - Do NOT touch the rack since it becomes very hot during use!

6 Cleaning and care: unplug the toaster and allow it to cool down. Empty the crumb tray. Wipe the outer surfaces with a slightly moist cloth. Never use caustic or abrasive cleaners, and never immerse the machine in liquid!

Enjoy your new AEG product!

SAFETY ADVICE

Read the following instruction carefully before using machine for the first time.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

www.aeg.com

4

• Keep the appliance and its cord out of reach of children less than 8 years.
• The appliance may only be connected to a power supply whose voltage and frequency comply with the specifications on the rating plate!
• Never use or pick up the appliance if
• the supply cord is damaged,
• the housing is damaged.
• The appliance must only be connected to an earthed socket. If necessary an extension cable suitable for 10 A can be used.
• If the appliance or the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person, in order to avoid hazard.
  Always place the appliance on a flat, level surface.
• The appliance must be switched off and the mains plug withdrawn each time after use, before cleaning and maintenance.
• The appliance and accessories become hot during operation. Use only designated handles and knobs. Allow to cool down before cleaning or storage.
• The mains cable must not come into contact with any hot parts of the appliance.
• do not immerse the appliance in water or any other liquid.
• Crumbs can burn, clean crumb tray regularly. Never use the appliance without crumb tray.
• Do not reach into the toasting slot with your fingers or metal utensils. There is a risk of injury and damaging the appliance.
• Bread can burn. Do not use the toaster underneath or near inflammable objects (e.g. curtains). The toaster must not be left unattended while running.
• Do not use or place the appliance on a hot surface or near source of heat.
• Do not cover the toasting slot when toasting.
• This appliance is not intended to be operated by means of an external timer or separate remote control system.
• This appliance is intended for domestic use only. The manufacturer cannot accept any liability for possible damage caused by improper or incorrect use.

DISPOSAL

This symbol on the product indicates that this product contains a battery which shall not be disposed with normal household waste.

This symbol on the product or on its packaging indicates that the product may not be treated as household waste. To recycle your product, please take it to an official collection point or to an AEG service center that can remove and recycle the battery and electric parts in a safe and professional way. Follow your country's rules for the separate collection of electrical products and rechargeable batteries.

AEG reserves the right to change products, information and specifications without notice.
